southpaw enterprises, inc.
Instruction Sheet - Bubble Tube with
Ping Pong Insert and Padded Platform #303104
Take time to familiarize yourself with the use and maintenance of this equipment before using. Please file
this Instruction Sheet in an accessible location. The Instruction Sheet must be read and familiar to anyone
who is using Southpaw Enterprises Equipment.
IMPORTANT: Please check equipment immediately for any damage that may have resulted during shipping.
If any damage has occurred, please contact Southpaw Enterprises, Inc. immediately.

MATERIALS LIST

-Wooden Platform
-White vinyl-covered Pad
-6" Acrylic Tube
-2" Acrylic Tube
-6 Colored Ping Pong Balls
-Allen Wrench
-4 Screws

A. INSTRUCTIONS FOR ASSEMBLY

Remove small lid on top of the wooden Platform. Place Bubble Column on top of the wooden slats
positioning the holes in the acrylic base over the pre-drilled holes on the slats and the air hose
pointed toward the front of the Platform (i.e. opposite the side where the electrical plugs are located).
Tighten screws with Allen Wrench. Connect hose fittings from the base of the Bubble Column to the
fitting on the underside of platform. Push together until you hear a "snap."
USE DISTILLED WATER ONLY TO FILL BUBBLE COLUMN
Column takes just under 5 gallons of distilled water. Pour entire contents of Algae Preventer Solu-
tion when you fill the column. DO NOT OVERFILL. When pouring water into the Column plug the
unit in so the air pump is running. This will let you know the maximum water level when the unit is
running. To add water, either remove the entire lid or just the small plug in the middle of the lid and
use the funnel to control spillage. Before putting the covers on the platform you can adjust the air-
flow to the tube that controls the speed of the ping balls by turning the white pinch valve on the air
hose leading to the tube.

B. LED SETTINGS

The Unit comes pre-set from the factory with the M3 setting. A Remote Control is provided if you
want to change the setting. Changes should be made by the Therapist ONLY.
-REMOTE OPERATION-Explanation of Controls
-Pinch Valve
-LED Remote Control
-Funnel
-Allen Wrench
-Bubble Column Drain Hose
-Algae Preventer Solution
-Security Bracket
Store these instructions along with the enclosed maintenance checklist in
a safe place. You may also access them on our website.
-Instruction Sheet
-Security Bracket Instruction Sheet
-Maintenance Checklist
®
