southpaw enterprises, inc.
Instruction Sheet
Featherweight Platform Swing 420110
Featherweight Bucket Swing
Deluxe Featherweight Kit
Take time to familiarize yourself with the use and maintenance of this equipment before using. Please file this
Instruction Sheet in an accessible location. The Instruction Sheet must be read and familiar to anyone who is
using Southpaw Enterprises Equipment.
IMPORTANT: Please check equipment immediately for any damage that may have resulted during shipping. If
any damage has occurred, please contact Southpaw Enterprises, Inc. immediately.

MATERIALS LIST:

1 - Featherweight Swing Frame with padded board
1 - Platform Cover or Bucket Cover (both with the Deluxe Kit)
1 - Instruction Sheet

PUTTING THE COVER / BUCKET ON THE SWING:

Lift the swing by the top snap in order to determine the correct
orientation of the swing.
Place the frame, upside down, on the floor or on a table.
Place the platform cover (flat, shown) or bucket cover
(dimensional) inside the platform swing frame, with the soft sur-
face facing down.
Bring the edge of the cover around the frame from the inside
and fasten the two halves of the zipper (See fig. 1) NOTE: As
pictured
(see fig. 2), start each zipper only about 3" until all four zippers
are started. Then zip them all the way.
Once all the zippers have been zipped, you must secure the
zipper tab in the hook-and-loop closure. First, while holding the
zipper tab up, lay the "fuzzy", or loop, piece down against the
zipper. (see fig. 3). Next, lay the zipper tab on top of the loop
fabric, and press the "scratchy", or hook fabric on top of the zip-
per tab (see fig. 4). This locks the zipper in place so that it can-
not unzip. Doing this step properly is critical for the safety
of you clients.
See reverse
for important
safety and use
instructions
Warning: Failure to properly install a forged
steel eyebolt (1/2" or 5/8") may result in serious
420115
injury or death.
about the installation of the forged steel
eyebolt, please contact Southpaw Enterprises
420120
Customer Service at 1-800-228-1698.
Fig. 3
®
If you have any questions
Fig. 1
Fig. 2
Fig. 4
