Grid-connected PV Inverter
SUN-70K-G03
SUN-90K-G03
User Manual
R
SUN-75K-G03
SUN-80K-G03
SUN-110K-G03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUN-70K-G03 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Deye SUN-70K-G03

Summary of Contents for Deye SUN-70K-G03

  • Page 1 Grid-connected PV Inverter SUN-70K-G03 SUN-75K-G03 SUN-80K-G03 SUN-110K-G03 SUN-90K-G03 User Manual...
  • Page 2 1. Introduction - 1 - ………………………………………………………… 1.1 Appearance introduction - 1 - …………………………………………… 1.2 Parts list - 2 - ………………………………………………………… 2. Safety warnings and instructions - 3 - ………………………………………… 2.1 Safety signs - 3 - ……………………………………………………… 2.2 Safety instructions - 3 - ……………………………………………………...

  • Page 3: About This Manual

    1.1 Appearance Introduc�on On-grid inverter can convert solar panel DC power into AC power which can directly input to the grid. Its appearance is shown below. These models contain SUN-70K-G03, SUN-75K-G03, SUN-80K-G03, SUN-90K-G03, SUN-100K-G03, SUN-110K-G03. The following is collec�vely referred to as “inverter”.
  • Page 4 1.2 Parts list Please check the following table, to see whether all the parts are included in the package： Nomal Alarm Enter Down Moun�ng stainless steel Grid-�ed PV String Inverter Wall moun�ng bracket x 1 screws M4×12 DC+/DC- Plug connectors Stainless steel an�-collision including metal terminal Wrench x 1...
  • Page 5 2. Safety warnings and instruc�ons Improper use may result in poten�al electric shock hazards or burns. This manual contains important instruc�ons that should be followed during installa�on and maintenance. Please read these instruc�ons carefully before use and keep them for future reference. 2.1 Safety signs Safety symbols used in this manual, which highlight poten�al safety risks and important safety informa�on, are listed as follows:...
  • Page 6 Shock Hazard: When PV module is exposed to sunlight, the output will generate DC voltage. Prohibit touching to avoid shock hazard. Shock Hazard: While disconnect the input and output of the inverter for maintenance, please waits for at least 5 mins un�l the inverter discharge the remnant electricity. High Temperature Hazard: Local temperature of inverter may exceed 80℃...
  • Page 7 3. Opera�on Interface 3.1 Interface View Pic 3.1 Front panel display 3.2 Status Indicator The inverter panel has 4 indicators, the le� one is dc output indicators, green indicates normal DC input. Beside is the AC indicator, green indica�ng normal ac connec�on. Beside the AC indicator is the opera�ng indicator, green indica�ng normal output.
  • Page 8 3.3 Bu�ons There are four bu�ons on the inverter panel：Above is Up and increase bu�on（UP）, Below is down and decrease bu�on（DOWN）， Le� is ESC bu�on（ESC）, Right is Enter bu�on（ENTER）. Achieving below func�ons by the four bu�ons： ● Page turning (use UP and DOWN bu�on） ●...
  • Page 9 4. Product installa�on 4.1 Select installa�on loca�on To select a loca�on for the inverter, the following criteria should be considered: WARNING: Risk of fire ● Do not install the inverter in areas containing highly flammable materials or gases. ● Do not install the inverter in poten�ally explosive atmospheres. ●...
  • Page 10 ● Install on a wall or strong structure capable of bearing the weight. ● Install ver�cally with a maximum incline of +/-15°. If the mounted inverter is �lted to an angle greater than the maximum noted, heat dissipa�on can be inhibited, and may result in less than expected output power.
  • Page 11 ≥500mm ≥500mm Pic 4.3 Installa�on Gap 4.2 Inverter of inverter Pic 4.4 Mou�ng bracket dimensions - 09 -...
  • Page 12 4.3 Inverter Installa�on The inverter should be mounted in a ver�cal posi�on. The steps of moun�ng are as follows 1. For brick walls, the posi�on of the holes should be suitable for the expansion bolts. 2. Make sure the bracket is horizontal and the moun�ng holes are in the correct points. Drilling the holes on the wall according the marks.
  • Page 13 5 Electrical Connec�on 5.1 DC input terminal connec�on 1. Switch the Grid Supply Main Switch(AC)OFF. 2. Switch the DC lsolator OFF. 3. Assemble PV input connector to the inverter. Safety Hint: When using PV modules, please ensure the PV+ & PV- of solar panel is not connected to the system ground bar.
  • Page 14 The steps to assemble the DC connectors are listed as follows: a) Strip off the DC wire about 7mm, disassemble the connector cap nut (see picture 5.3). Pic 5.3 Disassemble the connector cap nut b) Crimping metal terminals with crimping pliers as shown in picture 5.4. Pic 5.4 Crimp the contact pin to the wire c) Insert the contact pin to the top part of the connector and screw up the cap nut to the top part of the connector.
  • Page 15 d) Finally insert the DC connector into the posi�ve and nega�ve input of the inverter, shown as picture 5.6 Pic 5.6 DC input connec�on Warning: Sunlight shines on the panel will generate voltage, high voltage in series may cause danger to life. Therefore, before connec�ng the DC input line, the solar panel needs to be blocked by the opaque material and the DC switch should be 'OFF', otherwise, the high voltage of the inverter may lead to life- threatening condi�ons.
  • Page 16 AC wire produc�on method is the same as that of 5.2.1. AC wire installa�on method: 1) Remove the 8 fixing screws on the AC junc�on box of the inverter as shown in Pic 5.7. A�er removing the junc�on box, you can see the terminals of the inverter. The default is 5 digits as shown in Pic 5.8.
  • Page 17 Pic 5.11 Pic 5.11 Tighten the AC junc�on box 5.2.3 Recommended current protector specifica�ons Inverter Rated voltage Rated output power（KW） Current protection device（A） SUN-70K-G03 SUN-75K-G03 SUN-80K-G03 SUN-90K-G03 SUN-100K-G03 SUN-110K-G03 Table 5.3 Recommended current protector specifica�ons...
  • Page 18 5.3 Connec�on of the ground line Good grounded is important for resist the surge voltage shock and improve EMI's performance. So before the connec�on of AC, DC, communica�on connec�ons, inverter needs to ground first. For a single system, just ground the PE cable; For mul�ple machine systems, all PE cables of the inverter need to be connected to the same grounding copper platoon to ensure the equipotent connec�on.
  • Page 19 Phone GPRS Router Web Server WIFI Pic 5.13 Internet monitoring solu�on 5.4.1 Installa�on of datalogger When the inverter is out of the factory, the loca�on of the installa�on of datalogger is sealed by a sealed plate as shown in Picture 5.14. When installing the datalogger, remove the sealing plate, replace it with the sealing plate with square hole in the accessories, and �ghten the screws.

  • Page 20: Start Up And Shut Off

    5.4.2 Configura�on of datalogger For the configura�on of datalogger, please refer to illustra�ons of the datalogger. 6. Start up and Shut off Ensure that the inverter meets the following condi�ons before star�ng the inverter, otherwise it may cause fire or damage to the inverter without quality assurance, at the same �me the situa�on on our company does not undertake any responsibility.
  • Page 21 7. Zero-export func�on via energy meter There're two kinds of energy meters for this series inverter. First type is Eastron SDM630-Modbus V2 which is able to measure the Max. 100A current directly. More details please refer to Pic 7.1 & 7.2. For the Eastron SDM630 MCT 40mA, it needs external CT to measure the current.
  • Page 22 1 2 3 4 5 6 7 8 Eastron (1,2,3,4) (5,6,7,8) B A G RS 485 RS 485 B RS 485 A Pic 7.1 Eastron meter Eastron SDM630-Modbus V2 Inverter Solar Panel array AC Breaker RS 485 Male connector Family load VCC_5V 485_B N L3 L2 L1...
  • Page 23 9 1 0 11 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0 Eastron 1 2 3 4 15 16 17 18 19 20 Grid voltage Auxiliary Current inputs sampling power supply 1 4 1 3 1 2 RS 485 RS 485 A RS 485 B...
  • Page 24 Three-Phase Smart Meter (1,4,7,10) (3,6,9,10) RS 485 Pic 7.5 CHNT meter CHNT DTSU666 Inverter Solar Panel array AC Breaker RS 485 Male connector Family load L1 L2 L3 N VCC_5V 485_B RS 485 Female connector Three-Phase Smart Meter meter 485_A L1 L2 L3 N 485_A 485_B...
  • Page 25 1. Press Enter bu�on on the LCD panel in the main interface into the menu op�ons, select [parameter se�ng] to enter setup submenu, and then select [run param], at this �me please input the default password 1234 through pressing the bu�on [up down, enter], enter the opera�on parameter se�ng interface, shown as picture 7.7.

  • Page 26: Menu Setting

    7.1 Mul�ple strings and parallel connec�on meters This applica�on is that when the string inverters work in parallel, there is only one power grid and one load, and only one meter can be connected to prevent reverse current, so only this many-to-one an�-reverse current connec�on can be connected. If there're several inverters parallelling opera�on in a plant, also it can use 1pcs meter to realize zero export func�on.For example, if there're 3pcs inverters parallelling opera�on in the system with 1pcs meter.We need to setup 1pcs...
  • Page 27 NAME DESCRIPTION RANGE AVG: Average power of three phase is zero exported. Exp_Mode AVG/MIN MIN: Phase with minimum load power is zero exported, while the other two phase may be in purchase mode. CT ra�o of power grid side meter when extern CT_Ra�o 1-1000 CT is applied.
  • Page 28 1 2 3 4 5 6 7 8 Eastron (1,2,3,4) (5,6,7,8) B A G RS 485 RS 485 B RS 485 A Pic 7.10 Eastron meter Eastron SDM630-Modbus V2 Grid Master(Mst) L1 L2 L3 N RS485 485_B 485_A VCC_5V 485_B RS 485 Female connector Slave2(Slv2)
  • Page 29 9 1 0 11 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0 Eastron 15 16 17 18 19 20 1 2 3 4 Grid voltage Auxiliary Current inputs sampling power supply 1 4 1 3 1 2 RS 485 RS 485 A RS 485 B...
  • Page 30 Three-Phase Smart Meter (1,4,7,10) (3,6,9,10) RS 485 Pic 7.14 CHNT meter CHINT DTSU666 Master(Mst) AC Breaker Solar Panel array Slave1(Slv1) AC Breaker Solar Panel array Slave2(Slv2) AC Breaker Solar Panel array AC Breaker load VCC_5V 485_B RS 485 Female connector 485_A Master(Mst) RS485...
  • Page 31 7.2 How to browse the load power of your PV grid-�e plant on monitoring pla�orm? If you want to browse load power of the system and how much energy (KWH) does it export to grid(inverter output power is used to power the load firstly and then the surplus energy will feed into grid).
  • Page 32 Secondly, go to plant page, if it shows the PV power, load power and grid power, which means the configura�on is correct. - 30 -...

  • Page 33: General Opera�On

    8. General Opera�on During normal opera�on, the LCD shows the current status of the inverter, including the current power, total genera�on, a bar chart of power opera�on and inverter ID, etc. Press the Up key and the Down key to see the current DC voltage, DC current, AC voltage, AC current, inverter radiator temperature, so�ware version number and Wifi...
  • Page 34 P1-P6 Q1-Q6 Cut-In Back Cut-Out P1-P6 PF1-PF6 start Time stop PmpTime PtUsed Ac�veP Curve Q-Mode ReactP Exp_Mode Fun- ISO CT_Ra�o 0 AUTO ACREL Fun RCD EASTRON FeedIn CHNT SelfCheck Shunt ShuntQTY Island Generator G.CT AUTO Meter G.MFR ACREL G.FeedIn EASTRON Limiter Setup CHNT...
  • Page 35 INMETRO EN50549 EN50438 IEC61727 CUSTOM VDE_4105 UTE_C15 RD1699 CEI_0_21 G98_G99 AS4777(.2) NB/T 32004 GridStanderd OV_3-OV_1 240.0V Protect Param Advanced Tov_3-Tov_1 1000ms UV_1-UV_3 Back 235.0V Tuv_1-Tuv_3 1000ms OF_3-OF_1 52.00HZ 1000ms Tof_3-Tof_1 Setup 48.00HZ UF_1-UF_3 Tuf_1-Tuf_3 1000ms Vrc_H Vrc_L Frc_H Frc_L VGrid 127/220V OV10Min Address:08 Comm.
  • Page 36 8.1 The ini�al interface From the ini�al interface, you can check power, daily genera�on, gross genera�on, invertert ID , model and �me. 0.0Kw SN-01 2022-01-18 08:00:00 P - 45 Kw Power: 29.86Kw Day : 295kWh Total : 25 MWh State : Standby ID:2110214096 PF:0.000...
  • Page 37 Grid Ua : 234.5V Ia : 0.0A Grid Freq : 50.00Hz Pic 8.3 AC running state informa�on You can check the three phase voltage, current, and grid frequency. Total DC Power: 3.602W Lcd0196 Inv1400 Pic 8.4 Inverter firmware version You can check the inverter LCD so�ware Ver0196 and Control So�ware Version Ver1400. There are two black spot in the bo�om right corner.
  • Page 38 8.1.1 Main Menu There are four submenu in the Main Menu. MENU Statistics 《 Fault Record ON/OFF Setup Pic 8.6 Main Menu 8.2 Sta�s�cs informa�on There are five submenu in the sta�s�cs. MENU》Statistics E-Day E-History E-Month Test Data 《 E-Year Pic 8.7 Sta�s�cs Into each submenu through cursor.
  • Page 39 MENU》Statistics》E-Day <2022-01-18> 10MWh Pic 8.8 E-Day MENU》Statistics》E-Month 2022-01 1-10 20 31 <> 10MWh Pic 8.9 E-Month MENU》Statistics》E-Year <2022> 200KWh Pic 8.10 E-Year - 37 -...
  • Page 40 MENU》Statistics》E-History <2015-2024> 5KWh Pic 8.11 E-History This informa�on is for technician’s reference. 19186 11126 2057 19198 11140 137 : 2145 24362 16666 2248 9119 2927 1497 24362 141 : 12218 142 : 2065 143 : 2653 144 : 148 : 145 : 149 : Pic 8.12 Test Data...
  • Page 41 8.4 ON/OFF se�ng MENU》ON/OFF Turn ON Turn OFF 《 Pic 8.14 ON/OFF se�ng Into each submenu through cursor. MENU》ON/OFF》Turn ON 《 Turn ON Cancel Pic 8.15 ON set MENU》ON/OFF》Turn OFF 《 Turn OFF Cancel Pic 8.16 OFF set - 39 -...

  • Page 42: Menu Setup

    8.5 Parameter se�ng Se�ng includes system param, run param, protect param, comm.. param. All of these informa�on for maintenance reference. MENU》Setup System Param 《 Param Protect Param Comm. Param Pic 8.17 Se�ng 8.5.1 System Param System Param MENU》Setup 》 Time Set Language Set Display Set Factory data reset...
  • Page 43 8.5.1.1 Time Set Time Set 2022-01-18 09:36:30 Cancel Pic 8.18 System Param 8.5.1.2 Language Set Lauguage Set 简体中文 English 《 Polski Pic 8.19 Lauguage set 8.5.1.3 Display Set Display Set Brightness Keep 《 Delay time 05S Cancel Pic 8.20 Display set - 41 -...
  • Page 44 8.5.1.4 Factory data reset Factory data reset Confirm to reset 《 Cancel Pic 8.21 Factory data reset set 8.5.1.5 Se�ng Restor Setting Restor Confirm to restore 《 Cancel Pic 8.22 Factory data reset set Note: Password required-- only for access-authorized engineer. Un-authorized access may avoid the warranty.
  • Page 45 8.5.2 Running Param PassWord * * * * Pic 8.23 Password MENU》Setup》Run Param ActiveP 31% SelfCheck 20S QMode OFF Island ReactP 0.0% Meter 1.000 Limiter Fun_ISO OFF Feed_In Fun_RCD OFF MPPT Num Cancel - 43 -...
  • Page 46 NAME DESCRIPTION RANGE Adjust the output ac�ve power in % 0-110% Ac�veP OFF/Q(P)/PF(P) QMode Mul�ple reac�ve power control modes /Q(U)/PF/PER ReactP Adjust reac�ve power output in % -100%-+100% Power Fator -1-0.8~+0.8-1 Fun_ISO Insula�on resistance detec�on ON/OFF Fun_RCD Residual current detec�on ON/OFF Self-check Inverter's self-check �me.The default value 60s...
  • Page 47 MENU》Setup》Run Param Vref 0.0V OFDerate PowerLimit UFUprate OFF VoltageRT WGra 0.0% Sunspec WGraStr 0.0% Cancel NAME DESCRIPTION RANGE Arc-fault detec�on func�on ON/OFF/Clear OFDerate Ac�ve power response to over frequency 0-100% Pmax/Hz UFUprate Ac�ve power response to under frequency 0-100% Pmax/Hz power response to grid voltage devia�on ON/OFF WGra...
  • Page 48 8.5.2.1 Over-frequency Response This series inverter provides “over-frequency response” func�on. Long pressing the “OFD Derate” to enter the “over-frequency response” se�ng menu. MENU》Setup》Run Param Vref 220.0V OFDerate ON PowerLimit UFUprate OFF VoltageRT Sunspec WGra 20.0% Sunspec Cancel Definition of Over- frequency Response Parameters Description Range Parameter...
  • Page 49 When the frequency exceeds : 51.5Hz, the inverter output should stop (ie 0 W). StopPoint When the frequency is lower than : 51.5 Hz, the inverter will linearly increase the power StopPoint output with a gradient of 100% Pmax/Hz un�l it reaches : 50.5 Hz.
  • Page 50 “Q(U)” Mode QU Setting Start 30.0% Stop 20.0% RmpTime 2s PtUsed Curve Back QU Setting 80.0% -25.0% 90.0% 0.0% 110.0% 0.0% 120.0% 25.0% 120.0% 25.0% 120.0% 25.0% Back (U1,Q1) Upper Q/Pn lnd (U2,Q2) (U4,Q4) Grid Voltage (U3,Q3) (U5,Q5) Lower Q/Pn Cap (U6,Q6) Pic 8.25 Reac�ve Power Regula�on Curve in Q(U) Curve - 48 -...
  • Page 51 Parameter Range Description The QU mode starts when the active power Start 0%-130% Rate out power is greater than this value The QU mode stops when the active power 0%-130% Rate out power Stop is less than this value Increase or decrease the time required for RMpTime 0-1000s the reactive power to reach the specified...
  • Page 52 “Q(P)” Mode The reactive power output by the inverter is controlled by the active power of the inverter. Upper Q/Pn lnd (P1,Q1) P2(P2,Q2) P/Pn P4(P4,Q4) P3(P3,Q3) P5(P5,Q5) Lower P6(P6,Q6) Q/Pn Cap Pic 8.26 Reac�ve Power Regula�on Curve in Q(P) Mode MENU》Setup》Run Param ActiveP 31% SelfCheck 20S...
  • Page 53 parameter Range descrption Value of Q/Pn at point (P1,Q1) on the Q(P) mode 0%-100% Pn curve Reactive power value at point (P1,Q1) on the Q(P) -60% -60% Q/Pn mode curve Value of Q/Pn at point (P2,Q2) on the Q(P) mode 0%-100% Pn curve Reactive power value at point (P2,Q2) on the Q(P)
  • Page 54 PU Setting 0.0% 0.0% 0.0% 0.0% 0.0% 0.0% 0.0% 0.0% Back U/Vref (U1,P1) (U2,P2) (U3,P3) (U4,P4) P/Pn Pic 8.27 Ac�ve Power Regula�on Curve in PU Curve parameter Range Description Value of P/Pn at point (P1,U1) on the PU mode 0%-110% Pn curve Grid voltage limit at point (P1,U1) on the PU mode 0% -150% Vref...
  • Page 55 “PF(P)” Mode PFP Setting Vstart 0.0% Vstop 0.0% 0.0% -1.000 0.0% -1.000 0.0% -1.000 -1.000 0.0% 0.0% -1.000 Back PFP Setting 0.0% -1.000 Time Back P1(P1,PF1) lagging P2(P2,PF2) P4(P4,PF4) P/Pn P3(P3,PF3) P5(P5,PF5) PF leading P6(P6,PF6) Pic 8.28 Power factor Regula�on Curve in PF(P) Mode - 53 -...
  • Page 56 Parameter Range Description The PFP mode is enable when grid Vstart 0-150% Vref voltage is greater than Vstart The PFP mode is disable when grid voltage Vstop 0-150% Vref is less than Vstop Power value at point (PF1,P1) on the PF(P) 0-110% Pn Curve PF value at point (PF1,P1) on the PF(P)
  • Page 57 8.5.3 Protect Param MENU》Setup》Protect Param INMETRO UTE_C15 EN50549 RD_1699 EN50438 CEI_0_21 IEC61727 G98_G99 CUSTOM 《 AS4777 VED_4105 NBT32004 Cancel Pic 8.29 Protect Param Note: Engineer only. CUSTOM AC OverVoltage 1: 270.0V 《 Tripping Time 1: 100ms AC OverVoltage 2: 300.0V Tripping Time 2: 100ms AC OverVoltage 3: 300.0V Tripping Time 3: 100ms...
  • Page 58 CUSTOM AC OverFreq 1: 52.00Hz 《 Tripping Time 1: 2000ms AC OverFreq 2: 53.00Hz Tripping Time 2: 500ms AC OverFreq 3: 54.00Hz Tripping Time 3: 200ms CUSTOM AC LowFreq 1: 48.00Hz 《 Tripping Time 1: 2000ms AC LowFreq 2: 47.00Hz Tripping Time 2: 500ms AC LowFreq 3: 46.00Hz...
  • Page 59 MENU》Setup》Protect Param INMETRO UTE_C15 EN50549 RD_1699 EN50438 CEI_0_21 IEC61727 G98_G99 CUSTOM AS4777 《 VED_4105 NBT32004 Cancel MENU》Setup》Protect Param AS4777.2 Australia A AS4777.2 Australia B AS4777.2 Australia C AS4777.2 New Zealand Pic 8.30 “AS4777” 8.5.4 Comm. Param MENU》Setup》Comm.Param Address : 01 《...

  • Page 60: Repair And Maintenance

    9. Repair and Maintenance String type inverter doesn’t need regular maintenance. However, debris or dust will affect heat sink’s thermal performance. It is be�er to clean it with a so� brush. If the surface is too dirty and affect the reading of LCD and LED lamp, you can use wet cloth to clean it up. Warning: When the device is running, the local temperature is too high and the touch can cause burns.

  • Page 61: Error Code

    Check the solar panel output connec�on. Failure in reading memory (EEPROM). Restart the inverter if the Read the memory error fault s�ll exists, contact your installer or Deye service. Failure in wri�ng memory (EEPROM). Restart the inverter if the Write the memory error fault s�ll exists, contact your installer or Deye service.
  • Page 62 The DC busbar is unbalanced 2. Restart the inverter, if the fault s�ll exists, contact your installer or Deye service. DC end insula�on error Hardly appear the code. Never ever happened so far. Inverter 1 DC high fault Hardly appear the code.
  • Page 63 1. Check AC current sensor and its circuit. AC over current(one cycle) 2. Restart the inverter, if the fault s�ll exists, contact your installer or Deye service. DC over current Hardly appear the code. Never ever happened so far. Check the AC voltage protec�on se�ng. And Check if the AC AC Line W,U over voltage cable is too thin.Check the voltage difference between LCD and...
  • Page 64 Error code Description Ongrid - Three Phase AC grid V over current Hardly appear the code. Never ever happened so far. AC grid W over current Hardly appear the code. Never ever happened so far. Reactor A phase over current Hardly appear the code.
  • Page 65 11.Specifica�on SUN-70K SUN-75K SUN-80K SUN-90K SUN-100K SUN-110K Model -G03 -G03 -G03 -G03 -G03 -G03 Input Side Max.DC Power(kW) 97.5 Max.DC Input Voltage(V) 1000 Start-up DC Input Voltage(V) MPPT Opera�ng Range(V) 200~850 Max.DC Input Current(A) 40+40+40+40+40+40 Max. Short Circuit Current (A) 60+60+60+60+60+60 Number of MPPT/Strings per MPPT MAX inverter backfeed current (A)

  • Page 66: General Data

    General Data DC Connec�on MC-4 mateable AC Connec�on IP65 rated plug Display LCD1602 Interface RS485/RS232/Wifi/LAN 2022-07-01 Ver: 2.3 - 64 -...
  • Page 67 Add: No.26-30, South Yongjiang Road, Beilun, 315806, Ningbo, China Tel: +86 (0) 574 8622 8957 Fax: +86 (0) 574 8622 8852 E-mail: service@deye.com.cn Web: www.deyeinverter.com...
