Summary of Contents for Toshiba RBM-PMB0361U-E
- Page 1 R32 or R410A Installation Manual PMV Kit RBM-PMV0361U-E RBM-PMV0901U-E English...
-
Page 2: Table Of Contents
– 1 – Accessory parts Thank you very much for purchasing TOSHIBA Air conditioner. Please read this manual carefully before using your PMV Kit. Q’ty RBM- Part name Shape Usage • Also read the Installation Manual that come with the indoor unit, outdoor unit and optional parts. -
Page 3: Precautions For Safety
PRECAUTIONS FOR SAFETY • If refrigerant gas has leaked during the installation work, ventilate the room immediately. • Ensure that installation work satisfy all Local, National International regulations. If the leaked refrigerant gas comes in contact with fire, noxious gas may generate. •... - Page 4 – 3 – Precautions for using R32 refrigerant General (Installation space / area) • The installation of pipe-work shall be kept to a minimum. The basic installation work procedures are the same as conventional refrigerant (R410A, • Pipe-work shall be protected from physical damage. R22) models.
- Page 5 Unventilated area 7. Ventilated area • The appliance shall be stored so as to prevent mechanical damage from occurring. • Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. Information on servicing •...
- Page 6 – 5 – 10.Repairs to sealed components 13.Detection of flammable refrigerants • During repairs to sealed components, all electrical supplies shall be disconnected from • Under no circumstances shall potential sources of ignition be used in the searching for the equipment being worked upon prior to any removal of sealed covers, etc. or detection of refrigerant leaks.
- Page 7 15.Removal and evacuation 17.Decommissioning • When breaking into the refrigerant circuit to make repairs or for any other purpose, • Before carrying out this procedure, it is essential that the technician is completely Conventional procedures shall be used. However, it is important that best practice is familiar with the equipment and all its details.
-
Page 8: Installation Of R32 Or R410A Refrigerant Air Conditioner
– 7 – INSTALLATION OF R32 OR R410A 19.Recovery • When removing refrigerant from a system, either for servicing or decommissioning, it is REFRIGERANT AIR CONDITIONER recommended good practice that all refrigerants are removed safely. • When transferring refrigerant into cylinders, ensure that only appropriate refrigerant This PMV Kit adopts the HFC refrigerant (R32 OR R410A) which does not deplete the ozone layer. -
Page 9: Selection Of Installation Place
SELECTION OF INSTALLATION PLACE PMV Kit outline Purpose of using In the case of very quiet room, and also very nervous for indoor unit noise level, PMV Kit should be installed before CAUTION CAUTION indoor unit which should become lower noise level. Do not install the air conditioner at place where combustible gas may leak. -
Page 10: Installation Of Pmv Kit
– 9 – INSTALLATION OF PMV KIT Installation space • Make space for installation and service. (Make space to the electrical parts box cover side for service.) • When installing the unit inside the ceiling, be sure to create a check port. The check port is required when the unit is installed and serviced. -
Page 11: Refrigerant Piping
REFRIGERANT PIPING Pipe forming / End positioning Connection of refrigerant pipe Flaring Connect all the refrigerant pipes with flare connecting work. Cut the pipe with a pipe cutter. WARNING Remove burrs completely. CAUTION CAUTION Remaining burrs may cause gas leakage. If refrigerant gas has leaked during the installation work, ventilate the room immediately. -
Page 12: Fixation After Connection Pipes
– 11 – FIXATION AFTER CONNECTION PIPES Airtight test / Air purge, etc. For airtight test, air purge, addition of refrigerant, and gas leak check, follow the Installation Manual 1. After connection to pipes, fix the PMV Kit using the attached binding band so that it attached to the outdoor unit. -
Page 13: Electric Work
ELECTRIC WORK • Work procedure 1 Applicable model: High wall type MMK-UP 1H series WARNING <PMV Kit connection wiring method> 1. Using the specified wires, ensure to connect the wires, and fix wires securely so that • To comply with the EMC (Electromagnetic Compatibility) standards, be sure to use the clamp filters that are the external strength of the wires do not transmit to the connecting part of the supplied accessories. - Page 14 – 13 – 3) Be sure to install a clamp filter (accessory) on the PMV Kit side and another clamp filter (accessory) on the 4) After turning off the power supply, remove the terminal cover and the clamp base. indoor unit side. Take off claws of the clamp filter at 2 positions.
- Page 15 • Work procedure 2 <Standard Duct type> <Concealed Duct High Static Pressure type> Applicable model: P.C. board Standard Duct type MMD-UP 1BH series, Concealed Duct High Static Pressure type MMD-UP 1H series, Installation place for PMV connector 1-way Cassette SH type MMU-UP 1SH series, (Blue, CN82) Compact 4-way Cassette type MMU-UP...
- Page 16 – 15 – • Work procedure 3 <Compact 4-way Cassette type> Applicable model: All the indoor units except work procedure 1 Installation place for PMV connector (Blue, CN82) P.C. board and 2 <PMV Kit connection wiring method> Wire clamp * Pass the connection •...
- Page 17 EB99835101-3 (DH91307803)
