Toshiba RBM-FGUS1P-E Installation Manual

Outdoor unit
HEAT EXCHANGER FIN GUARD
INSTALLATION MANUAL
Model
RBM-FGUS1P-E, RBM-FGUM1P-E
SAFETY PRECAUTIONS
● Please read this "SAFETY PRECAUTIONS" carefully to install the fi n guards before starting work.
● The precautions listed here are important safety information, which must be strictly adhered to.
● After completing the installation, make sure that the unit operates properly during the trial run.
Also, inform customers that they should store this Installation Manual along with the user's manual and Installation Manual of the
main unit of the air conditioner.
Be sure only agent or qualifi ed service personnel to install the equipment.
WARNING
Improper installation yourself will cause the fi n guard to fall and result in injury.
Install accordingly to this installation instructions strictly.
CAUTION
If installation or install processing is defective, it will cause refrigerant gas leakage or injury.
CAUTION FOR INSTALLING
Install the fi n guards only at position where screw holes locate. Do not open screw holes yourself, not use
screws other than specifi ed for installation. It will damage the heat exchanger, or cause malfunctions of
electrical components or electronic components.
Be careful so as not to damage the fi ns and the pipes during the installation. The pipe damage will cause
refrigerant gas leakage.
CAUTION
Clean up the metal dust after the installation. Also, rust proof the installation location. The uncleared metal
dust after the installation or not rustproofed installation location will cause rust to form.
Wear gloves ( ) during the installation work.
Otherwise, it will cause injury on the parts. (
1. SPECIFICATIONS
Wire material Material : SWRM3, Wire diameter Ø3.5
Surface treatment Polyethylene coating (Colour : Silky shade·munsell No.1Y8.5/0.5)
2. PARTS
(It contains the below parts.)
No.
Heat Exchanger fi n guard (Right)
Heat Exchanger fi n guard (Left)
Heat Exchanger fi n guard (Rear)
Mounting screw (M5)
(M5×16 with washer)
Installation Manual
Mounting screw (drill screw)
(Ø4.2×13L)
Air conditioner packaged unit
Item
Thank you very much for purchasing Heat exchanger
fi n guards for TOSHIBA air conditioner packaged unit.
Please read this Installation Manual to install the
fi n guards, and perform correct works.
Thick gloves like work gloves)
RBM-FGUS1P-E, RBM-FGUM1P-E
This book
- 1 -
Model (RBM-)
FGUS1P-E FGUM1P-E
1
1
1
20 23
1
7 11
(English)
-
2
1
1
