SERVICE MANUAL
AIR-CONDITIONER
Outdoor Unit
Multi Controller
Outdoor Unit
Multi Controller
2-PIPE SUPER MULTI, HEAT PUMP
MAR-M102HTM8-PE
RBM-Y1032-PE (3-way)
RBM-Y1042-PE (4-way)
3-PIPE SUPER MULTI, HEAT PUMP WITH
SIMULTANEOUS HEATING AND COOLING
MAR-F102HTM8-PE
RBM-Y1032F-PE (3-way)
RBM-Y1042F-PE (4-way)
FILE NO. A90-9819
Printed in UK March 1998 s
