Entellisys Low Voltage Switchgear
Chapter 3. Description
9
1
4
6
7
1.
Side barrier
2.
Bottom barrier
3.
Rear base/barrier
4.
Primary disconnects – line
5.
Current Transformers
Fig. 3-5 Circuit breaker compartment (22-inch)
6.
Primary disconnects -- load
7.
Drawout rails
8.
Racking anchor pins
9.
Secondary Disconnect
12
5
8
3
7
2
