40MK*B
High- Wall Ductless Split System
Sizes 018 to 036
A NOTE ABOUT SAFETY
GENERAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PART NAMES
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPLAY PANELS
REMOTE CONTROL
REMOTE CONTROL FUNCTIONS
CLEANING, MAINTENANCE AND TROUBLESHOOTING
Please read this Owner's Information Manual carefully before installing and using this appliance
and keep this manual for future reference.
For your convenience, please record the model and serial numbers of your new equipment in the
spaces provided. This information, along with the installation data and dealer contact information,
will be helpful should your system require maintenance or service.
UNIT INFORMATION
Model # ___________________________________
Serial # ___________________________________
INSTALLATION INFORMATION
Date Installed _____________________________
Downloaded from
ManualsNet.com
Owner's Manual
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NOTE TO EQUIPMENT OWNER:
search engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DEALERSHIP CONTACT INFORMATION
Company Name: _________________________________
Address:_________________________________________
________________________________________________
Phone Number:__________________________________
Technician Name:_________________________________
________________________________________________
PAGE
2
2
3
4
5
6 - 8
8 - 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Carrier 40MK B Series
Summary of Contents for Carrier 40MK B Series
- Page 1 40MK*B High- Wall Ductless Split System Sizes 018 to 036 Owner’s Manual TABLE OF CONTENTS PAGE A NOTE ABOUT SAFETY ................. . . GENERAL .
- Page 2 A NOTE ABOUT SAFETY GENERAL The high wall fan coil unit provides quiet, maximum comfort. In Any time you see this symbol in manuals, instructions and on addition to cooling and/or heating, the high wall fan coil unit the unit, be aware of the potential for personal injury. There are matched with an outdoor condensing unit will filter and three levels of precaution: dehumidify the air in the room to provide maximum comfort.
- Page 3 PART NAMES ■ Indoor 1. Front panel 2. Air Inlet 3. Display 4. Air Filter 5. Horizontal airflow grille 6. Vertical air flow louver 7. Interconnecting tubing 8. Control and power wiring to indoor unit 9. Service valves 10. Remote control 11.
- Page 4 DISPLAY PANELS SELECTED TEMPERATURE / SELF-DIAGNOSTIC CODES indicator DEFROST indicator Illuminates when the coil is warming up to prevent cold blow or when the unit goes into defrost mode. OPERATION indicator This indicator flashes once per second after power is on and illuminates when the unit is in operation.
- Page 5 REMOTE CONTROL AUTO COOL HIGH HEAT TEMP Mode On/Off SLEEP Self Clean Follow Me Turbo Ionizer Smart Eye F.P. Silence A14358 Fig. 6 - Remote control Remote Control Operation - Quick Start CAUTION NOTE: When transmitting a command from the remote control to the unit, be sure to point the control toward the right side of the unit.
- Page 6 Manual Operation Setting the Room Temperature Set Point Pressing the increase temperature set point and decrease If the remote control is lost, damaged, or the batteries are buttons will raise or lower the temperature. exhausted, the MANUAL button can be used to run the unit. The The unit will confirm signal receipt with a beep and the value of MANUAL mode needs to be used when the indoor temperature is the set temperature on the display will change accordingly.
- Page 7 Selecting Vertical Direction of the Louver Timer ON and Timer OFF Use both functions to program the unit to turn on and shut off at For models that do not have the vertical swing function, the specified times. vertical louvers can be adjusted manually to direct the airflow to UNIT OFF achieve optimal comfort in the space.
- Page 8 Self Clean Mode 1. Open front panel on unit. Press the “Self Clean” button to activate or deactivate the 2. Pull filters down to remove. self- cleaning function. Under this function, the air conditioner will 3. Vacuum filters. automatically clean and dry the evaporator.. 4.
- Page 9 Troubleshooting Refer to Table 2 before contacting your local dealer. Table 1—Periodic Maintenance INDOOR UNIT EVERY MONTH EVERY 6 MONTHS EVERY YEAR Clean Air Filter* Change Remote Control Batteries OUTDOOR UNIT EVERY MONTH EVERY 6 MONTHS EVERY YEAR Clean Outdoor Coil from Outside Clean Outdoor Coil from Inside†...
- Page 10 Catalog No:OM40MKC(Q)B- B- 01 Copyright 2015 CAC / BDP D 7310 W. Morris St. D Indianapolis, IN 46231 Edition Date:05/15 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations. Replaces: NEW Downloaded from ManualsNet.com search engine...
