Entrust nShield Connect Installation Manual page 43

4. Enter the IPv6 route gateway If a link-local address is entered for the IPv6 route
gateway the screen below will be displayed.
Edit route entry
Select an interface
for link-local address:
fe80:2222:2222:2222:
2222:2222:2222:2222
Interface #1
BACK NEXT
5. Select the interface for the IPv6 gateway. Press the right-hand navigation button to
accept.
9.2.8. Remove route entry
To remove a route entry:
1. From the front panel menu, select System > System configuration > Network config
> Set up routing > Remove route entry.
The following screen is displayed:
► 1. 1. 1. 1/ 1
3. 3. 3. 3/ 3
1111:1111:1111:1111:
1111:1111:1111:1111
/128
BACK SELECT
2. Select the IPv4/IPv6 route to be removed. Press the right-hand navigation button.
3. The selected route will be displayed. Press the right-hand navigation button to
remove the route.
9.2.9. Enable IPv6 SLAAC
SLAAC can be enabled/disabled independently on each of the two interfaces.
To enable SLAAC:
1. From the front panel menu, select System > System configuration > Network config
> Set up interface #1 > Configure #1 IPv6 > Static addr/SLAAC > Select
Static/SLAAC.
The following screen is displayed:
nShield® Connect Installation Guide 43 of 73
