- Page 1 User Manual 10308002 Boreas Pagoma Freezer User Manual Version 1.0...
-
Page 2: Table Of Contents
User Manual Table of Contents Disclaimer ........................4 LIMITED WARRANTY & DISCLAIMER ..................4 LIMITATION OF LIABILITY ....................... 7 Safety ..........................8 2.1. Proper Use ........................9 III. After Sales Support ....................... 9 Boreas Pagoma Freezer Introduction .................10 Technical Specifications ....................11 Standards and Conformity ...................12 VII. - Page 3 User Manual 12.5 Cleaning the Door Gasket ...................33 12.6 Vacuum Relief Port .....................33 12.7 Replacing the Battery ....................34 12.8 Preparing a Unit for Storage ..................35 12.9 Preventative Maintenance ...................35 12.9.1 Freezers ........................35 12.9.2 Maintenance Checklist ....................36 Version 1.0...
-
Page 4: Disclaimer
User Manual Disclaimer • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 5 User Manual published specifications; provided that Buyer shall (a) promptly notify the Company in writing upon the discovery of any defect, which notice shall include the product model and serial number (if applicable) and details of the warranty claim; and (b) after the Company's review, the Company will provide Buyer with service data and/or a Return Material Authorization ("RMA"), which may include biohazard decontamination procedures and other product-specific handling instructions, then, if applicable, Buyer may return the defective Products to the Company with all costs prepaid...
- Page 6 User Manual THE OBLIGATIONS CREATED BY THIS WARRANTY STATEMENT TO REPAIR OR REPLACE A DEFECTIVE PRODUCT SHALL BE THE SOLE REMEDY OF BUYER IN THE EVENT OF A DEFECTIVE PRODUCT. EXCEPT AS EXPRESSLY PROVIDED IN THIS WARRANTY STATEMENT, THE COMPANY DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, ORAL OR WRITTEN, WITH RESPECT TO THE PRODUCTS, INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE OR USE.
-
Page 7: Limitation Of Liability
User Manual LIMITATION OF LIABILITY NOTWITHSTANDING ANYTHING TO THE CONTRARY CONTAINED HEREIN, THE LIABILITY OF THE COMPANY UNDER THESE TERMS AND CONDITIONS (WHETHER BY REASON OF BREACH OF CONTRACT, TORT, INDEMNIFICATION, OR OTHERWISE, BUT EXCLUDING LIABILITY OF THE COMPANY FOR BREACH OF WARRANTY (THE SOLE REMEDY FOR WHICH SHALL BE AS PROVIDED UNDER THIS SECTION) SHALL NOT EXCEED AN... -
Page 8: Safety
User Manual Safety IMPORTANT Safety Items to be Observed. ! DANGER (may cause serious damage to property and or casualties) 1. Please carefully read this User Manual prior to operating the instrument and observe the instructions on safe operation. 2. The power source must be grounded reliably and away from any sources of electromagnetic interference. -
Page 9: Proper Use
User Manual selected or approved by the Company shall operate to void any warranty contained hereinabove for the product 18. Do NOT operate this instrument immediately after transport, due to the Compressor await 1-2 days before operating. The instrument must be used in accordance with this User Manual. -
Page 10: Boreas Pagoma Freezer Introduction
User Manual Boreas Pagoma Freezer Introduction Version 1.0... -
Page 11: Technical Specifications
User Manual Technical Specifications Model 10308002 Product Name Boreas Pagoma Capacity 390 litres Temperature Range -50°C (-58°F) to -86°C (-123°F) in @ 32°C (89.6°F) ambient 35.8” W x 78.3”H x 31.4” F-B Exterior Dimensions （90.9cm x 199cm x 79.7cm） 23.2”W x 51.6”H x 19.9” F-B Interior Dimensions （58.9cm x 131 cm x 50.5cm）... -
Page 12: Standards And Conformity
User Manual Standards and Conformity Construction in Accordance with the following Safety Standards: UL 61010-1:2012 CSA C22.2#61010-1-12:2012 UL 61010-2-011:2021 CSA C22.2#61010-2- 011:2019 Construction in Accordance with the following EMC Standards: EN 61010-1:2010 EN 61326-1:2013 Version 1.0... -
Page 13: Inspection
User Manual VII. Inspection Unpack the equipment carefully and check for any damage which may have arisen during transport. In the event of identified damage, please contact serviceusa@hollandgreenscience.com The package includes the following items Part Part Description Quantity Description Quantity Number Number M4 screw cap... -
Page 14: Installation And Operating Instructions
User Manual VIII. Installation and Operating Instructions Version 1.0... - Page 15 User Manual Version 1.0...
-
Page 16: Installation Warning
User Manual Installation Warning Allow the unit to sit upright for 24 hours before starting up. Location When the freezer is in position, set the front caster brakes. The freezer must not be moved with product loaded inside. Note: For proper ventilation and airflow, a minimum clearance of 12cm at the rear and top and a clearance of 20cm on the side of the freezer is required. -
Page 17: Install Shelves
User Manual Figure 1-7. Positioning bracket installation Install Shelves Install the shelf clips into the shelf rails (front and back) at the desired shelf level, as shown in Figure 1-8. Install the shelves in the cabinet onto the clips, as shown in Figure 1-9. Note: Maximum shelf load is 50 kg per shelf. -
Page 18: Parameter Setting
User Manual 1. Check the location of the external components of the product to ensure that the external components of the product are not damaged. 2. See the serial tag on the side of the unit for electrical specifications or refer to the electrical schematics in this manual. - Page 19 User Manual 2. Touch anywhere on the screen to enter the home page. As shown in Figure 1-13. Home Page: ① —Log in / Log out icon, blue after log in and grey after log out, as shown in Figure1-13 and Figure 1-15. ②...
- Page 20 User Manual ⑥ —Freezer “ON/OFF” button. ⑦ —"BUZZER” button ⑧ —Running records display area, display the latest three records. Touch the “Login” button and put in the login username ”admin” and password ”8888”, as shown in Figure 1-14. all buttons are activated after the user logs in, as shown in Figure 1-15. Touch the temperature display area from the home page to enter the temperature setting page, as shown in Figure 1-16.
- Page 21 User Manual 5. Touch the running record display area from the home page to enter the running record page, as shown in Figure 1-18. The running history of the freezer are displayed in the running record page, slide the right scroll bar to view more history.
- Page 22 User Manual 6. Touch the time display area from the home page to enter the data/time modification page, as shown in Figure 1-19. In the data/time modification page, digital keyboard pops up by touching on the numbers. Put in the corresponding time to change the date or time. 7.
- Page 23 User Manual The current registered users can be viewed in the user management page. There are two buttons on the right side, "Add user" and "Delete User". The “Add User” window pops up by touching the “Add User” button. In this window you can add users and set the current user's usage rights, as shown in Figure 1-22.
- Page 24 User Manual 9. Touch the “System settings” button from the setting page to enter the system settings page, as shown in Figure 1-24. System language can be switched by touching the “Chinese” or “English” button in the System settings page. Digital keyboard pops up by touching the number location of “Screen saver”...
-
Page 25: Start-Up
User Manual Start-Up Freezer will run by touching the “ON/OFF” button in the home page after the parameter settings. 8.10 Data/Information Retrieval 1. Touch the “Display” button from the home page to enter the display page, as shown in Figure 1-26. 2. - Page 26 User Manual The trend of the chamber temperature can be viewed in the temperature log page. TEMP Limit window pops up by touching the ordinates, the TEMP Limit can be adjusted in this window, as shown in Figure 1-29. Touch on the display area of the curve to see the corresponding temperature values at the point.
- Page 27 User Manual 4. Touch the “Alarm Event” button from the display page to enter the alarm log page, as shown in Figure 1-30. Alarm histories in the operation of products can be viewed in the alarm log page. Click the " Data Download " button, the history data will be saved to the U disk， the file format is .csv, and they can be opened by Excel to view.
-
Page 28: Bot Mode
User Manual 6. Touch the “Device Info” button from the display page to enter the device information page, as shown in Figure 1-32. The main information and the software version of the freezer can be viewed in the device information page. 8.11 BOT Mode Touch the “BOT”... -
Page 29: Calibration
User Manual Calibration Once the freezer has stabilised, the control probe may need to be calibrated. Calibration frequency is dependent on use, ambient conditions and accuracy required. A good laboratory practice would require at least an annual calibration check. On new installations, all parameters should be checked after the stabilisation period. Caution: Before making any calibration or adjustments to the unit, it is imperative that all reference instruments be properly calibrated. -
Page 30: Alarms
User Manual Alarms The Boreas Pagoma alarms are displayed on the freezer control panel. When an alarm is active, the alarm message will be displayed in the alarm record screen and there will be an audible alarm in the Home Page screen. Press the “BUZZER”... -
Page 31: Fault Diagnosis
User Manual Fault Diagnosis Fault Possible Reasons Solution Door Open · Damage to door switch · Replace the door switch · The door was not fastened · Close the door and handle Power Supply · Power input does not meet the requirements ·... -
Page 32: Maintenance And Cleaning
User Manual XII. Maintenance and Cleaning 12.1 Cleaning the Exterior Cabinet Wipe down the freezer exterior using only soap and water and a general use laboratory disinfectant. Rinse thoroughly with clean water and dry with a soft cloth. Caution: Avoid excessive use of water around the control area due to the risk of electrical shock. Damage to the controls may also result. -
Page 33: Defrosting The Chamber
User Manual 12.4 Defrosting the Chamber 1. Remove all product and place in another freezer. 2. Turn the unit off and disconnect from the power source. 3. Open all doors and place towels on the chamber floor. 4. Allow the frost to melt and become loose. 5. -
Page 34: Replacing The Battery
User Manual The vacuum relief port requires routine maintenance. It will ice over unless preventive measures are taken. If the vacuum relief port becomes iced over, the freezer will take several hours to equalize pressure. Warning: Do not leave the freezer unattended while the door is open. Observe the inner side of port periodically for frost and ice build-up. -
Page 35: Preparing A Unit For Storage
User Manual 12.8 Preparing a Unit for Storage Defrost the unit as described in ‘Defrost Freezer’. This will prepare the unit for storage. Turn off the battery power switch (O). Turn off the freezer power switch. Disconnect power to the battery(s) and to the freezer. Warning: If the unit has been in service, turn it off and disconnect the power cord connector before proceeding with any maintenance. -
Page 36: Maintenance Checklist
User Manual 12.9.2 Maintenance Checklist Action Monthly Yearly Every 2 Years √ Verify Ambient Temperature, <32.2°C √ * Adjust door handle for firm latching, as needed √ Check and clean probe cover, gaskets, hinges and door(s) of ice and snow. More frequent cleaning may be required, depending See Figure 1-4 for probe location.
