Summary of Contents for Holland Green Science 10308001
- Page 1 User Manual 10308001 Boreas Freezer User Manual Version 1.0...
-
Page 2: Table Of Contents
User Manual Table of Contents Disclaimer ........................3 LIMITED WARRANTY & DISCLAIMER ..................3 LIMITATION OF LIABILITY ....................... 6 Safety ..........................7 III. Proper Use ........................8 After Sales Support ....................... 8 Boreas Series Freezer Introduction ................9 BDW-25L320 ........................9 Technical Specifications ....................10 VII. -
Page 3: Disclaimer
User Manual Disclaimer • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 4 User Manual conformance with said published specifications; provided that Buyer shall (a) promptly notify the Company in writing upon the discovery of any defect, which notice shall include the product model and serial number (if applicable) and details of the warranty claim; and (b) after the Company's review, the Company will provide Buyer with service data and/or a Return Material Authorization ("RMA"), which may include biohazard decontamination procedures and other product-specific handling instructions, then, if applicable, Buyer may return the defective...
- Page 5 User Manual THE OBLIGATIONS CREATED BY THIS WARRANTY STATEMENT TO REPAIR OR REPLACE A DEFECTIVE PRODUCT SHALL BE THE SOLE REMEDY OF BUYER IN THE EVENT OF A DEFECTIVE PRODUCT. EXCEPT AS EXPRESSLY PROVIDED IN THIS WARRANTY STATEMENT, THE COMPANY DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, ORAL OR WRITTEN, WITH RESPECT TO THE PRODUCTS, INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE OR USE.
-
Page 6: Limitation Of Liability
User Manual LIMITATION OF LIABILITY NOTWITHSTANDING ANYTHING TO THE CONTRARY CONTAINED HEREIN, THE LIABILITY OF THE COMPANY UNDER THESE TERMS AND CONDITIONS (WHETHER BY REASON OF BREACH OF CONTRACT, TORT, INDEMNIFICATION, OR OTHERWISE, BUT EXCLUDING LIABILITY OF THE COMPANY FOR BREACH OF WARRANTY (THE SOLE REMEDY FOR WHICH SHALL BE AS PROVIDED UNDER THIS SECTION) SHALL NOT... -
Page 7: Safety
User Manual Safety IMPORTANT Safety Items to be Observed. Safety Warnings ! DANGER (may cause serious damage to property and or casualties) 1. Please carefully read this User Manual prior to operating the instrument and observe the instructions on safe operation. 2. -
Page 8: Proper Use
User Manual III. Proper Use The instrument is designed for non-residential use and to be used in conjunction only with accessories recommended within this manual and by the manufacturer. After Sales Support If problems are encountered or technical support is required when installing or using the instrument, please contact serviceusa@hollandgreenscience.com The Company may provide technical assistance and information regarding the instrument or equipment or service without charge at its sole discretion. -
Page 9: Boreas Series Freezer Introduction
User Manual Boreas Series Freezer Introduction Version 1.0... -
Page 10: Technical Specifications
User Manual Technical Specifications Model 10308001 Boreas Product Name Climate Type SN/N -10 ℃～-25 ℃ Cabinet Temperature Effective Volume 320L 220V Rated Voltage Frequency 50Hz Refrigerant R290 5 ℃ ～ 28 ℃ Ambient Temperature 18 ℃ ～ 25 ℃ Ideal Temperature Ambient Humidity <80% RH... -
Page 11: Standards And Conformity
User Manual VII. Standards and Conformity Construction in Accordance with the following Safety Standards: UL 61010-1:2012 CSA C22.2#61010-1-12:2012 UL 61010-2-011:2021 CSA C22.2#61010-2- 011:2019 Construction in Accordance with the following EMC Standards: EN 61010-1:2010 EN 61326-1:2013 VIII. Inspection Unpack the equipment carefully and check for any damage which may have arisen during transport. -
Page 12: Installation Instructions
User Manual Installation Instructions Initial Setup • Leave a 30cm ventilation gap around all four sides of the cabinet. • Install the instrument only on a stable and level floor surface • When the freezer is located into the desired position, set the front castor brakes. •... -
Page 13: Operating Instructions
User Manual Operating Instructions 10.1 User Interface 1. Cooling Status Indicator 2. Defrost Indicator 3. Fan Status Indicator 4. Power Indicator 5. Keyboard Lock Indicator 6. Door open Indicator 7. Power Switch 8. Setting Key 9. Increase Key 10. Decrease Key 11. -
Page 14: Parameter Settings
User Manual 10.2 Parameter Settings Upon power on, the screen displays the current internal temperature value. To change the set temperature Function Keys Operation Display Default Displays the inside temperature Press the key 8 for 3 seconds Displays the initial set data and flashes Press the key 9 Figure increases Press the key 10... -
Page 15: Temperature Query Settings
User Manual 10.3 Temperature Query Settings Press key 9 to check high and low temperature record. Display Default Displays inside temperature Display highest temperature (HT) Press key 9 Press key 9 again Display HT date HD Press key 9 again Display HT hour HH Press key 9 again Display HT minute... -
Page 16: Review And Set Time
User Manual 10.4 Review and Set Time Key operation Display Default Display cabinet temperature Press key 10 Display Time, Year Y_17 Press key 10 again Month N_03 Press key 10 again Date D_15 Press key 10 again Hour H_08 Press key 10 again Minute E_20 Press key 10 again Second S_21... -
Page 17: Alarm Codes
User Manual 10.5 Alarm Codes. Alarm code Describe High temperature alarm Low temperature alarm Power failure alarm During a power failure or fault a battery will activate allowing the display to continue, the power failure alarm displays ‘AUF’ and the current inside temperature will cycle on the display. -
Page 18: Maintenance
User Manual Maintenance Keep the instrument dry and clean in routine operations. Clean the outer surface with a non-abrasive cleanser and only connect the power supply when the entire instrument surface is dry. If liquid or moist solids enters the instrument, please immediately disconnect the power supply and contact supportusa@hollandgreenscience.com •... -
Page 19: Trouble Shooting
User Manual XII. Trouble Shooting 12.1 Poor Cooling Performance • Check ambient temperature is within limits. • Check if the external door is closed. (Check for frost on seal) • Check if the temperature is set correctly. • Check if the storage cabinet is near a heat source. •...
