Chapter 1 – Quick Start

Overview

The Reveal™ high-bandwidth vibration sensor measures vibration speed at low frequency ranges (10Hz – 1kHz),
and peak g-force at high frequency ranges (1.5kHz – 10kHz). The sensor can support between one and four
independent vibration inputs referred to as "channels" in this document. The vibration sensor can be used for
simple motor on/off functionality, or vibration analysis utilizing ISO standards such as ISO 10816. The high
frequencies are used for more advanced analysis not specified in ISO standards.

Part Numbers

Part Number
RBS306-VSHB-US

Documentation

The following documentation is available at https://www.multitech.com/products/sensors.
Document
User Guide
Connection Guide
Reveal™ Wireless Vibration Sensor User Guide
Rating
Outdoor/Industrial
Description
This document provides overview, safety and regulatory
information, design considerations, schematics, and general
hardware information.
This document provides instructions and information on how
to connect Reveal LoRaWAN sensors on gateways and
networks.
Wireless
LoRaWAN
QUICK START
Region
North America, South
America
Part Number
RB00017
RB00001
