COMMON MESSAGES
Bytes Description
0 Current Sub-Band, sub-band currently joined and used for communication to the gateway and
network server. Value ranges from 1-8 for US915. For other regions, value depends on available
channels.
1 RSSI of last DOWNLINK received, signed integer format values in bytes 1 and 2 in two's complement
format.
2 SNR of last DOWNLINK received, signed integer format values in bytes 1 and 2 in two's complement
format.

Downlink Messages

Downlink messages are from the cloud to the sensor and are used to configure the sensor. The sensor initiates
downlink messages, since the sensor is typically sleeping with the radio turned off.
For LoRaWAN devices, a downlink can be received after any uplink within the receive window.
The following messages can be sent back to the sensor upon a downlink request.
Command Payload
0x00 Not used
0x01 4 bytes
-- 0-7 bytes
0xfc 3 bytes

General Configuration

Use the general configuration command to configure parameters that apply to all sensor types.
Byte Description
0x00 Disable sensor events
0x01 Radio config
0x02 Supervisory period. Default 19 hours.
0x03 Sampling rate
Disable Sensor Events
The following table shows the disable sensor event bit definitions.
Bit Description
7:1 Not used
0 Disable all sensor events
16
Description
Not used
General configuration
Sensor configuration, refer to the Sensor Specific Messages chapter
Advanced configuration
