Chapter 4 – Common Messages

Common Messages

This chapter defines the protocol and message definitions common to all Reveal wireless sensors. Common
messages include basic error messages, tamper, supervisory, link quality, and downlink acknowledgments. Sensor
specific messages are in the Sensor Specific Messages chapter.

Message Protocol

This section defines the protocol and message definitions for the device.
Note: MultiTech provides a web-based console at
devices. We recommend using this console rather than the protocols defined in this section.
If not using the console, use this topic to configure the device through downlink messages and decode the device
data.

Uplink Messages

The uplink messages (sensor to web application) have the following structure.
Item
Protocol Version
Packet Count
Message Type
Message Payload
Message Payload
0x00 5-byte reset code
0x01 >3 (9)
0x02 1-byte event
-- Sensor event
Reveal™ Wireless Vibration Sensor User Guide
Size Description
4 bits A constant 1, provides extensibility to the specific format of a message type.
4 bits A sequential number starting at 0 for the first message sent from the sensor to
the cloud. It increments by one for each subsequent message. When it reaches
0xF (15 decimal), it wraps back to 0. Packet count helps identify when a message
is lost. For example, if the packet count goes 2,4 instead of 2,3,4, it indicates a
message has been lost. It can also help identify out-of-order or duplicate
messages.
1 byte Byte format is 8 bits, with 256 combinations possible.
0-7 bytes Each message type has between 0 and 8 bytes of payload data specific to the
sensor. Refer to the following table for payload information.
console.radiobridge.com
Description
Device has reset. The reset cause is represented in the 5-byte
reset code payload.
Daily supervisory message (1-2 per day). The 3-byte payload
contains current sensor status. Refer to
0x01for payload details.
A tamper event has occurred. Refer to
details.
Sensor events are defined in the Sensor Specific Messages
chapter.
COMMON MESSAGES
for configuring and monitoring
Supervisory Message
Tamper Message 0x02for
