Section 3 | Control Panel Operation
3.1 HMI Display Operation
Disclaimer – Parameters are not allowed to be modified by end users. This is to protect the equipment from
accidental damage. Modifying parameters for any reason, without our knowledge and permission will
constitute a void of the warranty.
The PLC display is laid out in the simplest way possible. This section will focus on the different functions of the
PLC interface and how they are used. Including how to edit, save, and reload recipes.
Many buttons on the main display will change color or text when pressed.
The following image shows the different sections of the display.
If you have any questions or concerns on using the display, please contact us.
10
