MAXIMATOR VP30 Maintenance Information page 24

nd
Fig 6 – 2 Stage Cylinder – parts list
Pos. Part Number
1 162032
2 161922
3 094471
4 080764
5 004286
6 073440
7 164542
8 094463
9 080772
10 161559
11 162033
12 161560
13 161920
14 094455
15 514339
July 21
Description
O-RING 100 X 2
GUIDE CYLINDER
SPRING WASHER D12
NUT M12
STUD M10 X 25
O-RING 70 X 2
CYLINDER D27
SPRING WASHER D10
NUT M10
CYLINDER GASKET D38
LAMELLA VALVE LV 111
CYLINDER HEAD GASKET
CYLINDER HEAD
SPRING WASHER D8
SCREW M8 X 75
VP30/VP500
MAINTENANCE INFORMATION
24 of 42
Quantity
1
1
4
4
4
1
1
4
4
1
1
1
1
4
4
