MAXIMATOR VP30 Maintenance Information page 16

Fig 2 – Crankcase, parts list
POS. PART NUMBER
1 161901
2 139491
3 094471
4 080764
5 162027
6 162235
7 181379
8 179742
9 151882
10 125407
11 002224
12 074047
13 161876
14 148784
15 125814
16 125997
17 030880
18 001180
19 076333
20 161874
21 165851
22 181539
23 094447
24 181539
25 073466
26 138703
27 153818
28 001104
29 001074
30 080764
31 094471
32 088668
33 160363
34 150010
35 108758
36 030880
37 096172
38 162024
July 21
DESCRIPTION
CRANK CASE
STUD M12 X 30
SPRING WASHER D12
NUT M12
RETAINING RING 85 X 3
EXTENSION 1" X 100
O-RING 30 X 2,5
FITTING RI 1 X 1/4
FILLER PLUG
SPRING WASHER D5
SCREW M5 X 25
O-RING 180 X 3
GASKET RING 17,4 X 24 X 1,5
VALVE SPINDLE CPL.
FILTER
EXTENSION 1/2" X 50
GASKET RING 20,7 X 28 X 1,5
LOCKING SCREW R1/2
SCREW M12 X 45
GASKET RING 34,3 X 42 X 2
BEARING COVER SV 225/350
SCREW M6 X 30
SPRING WASHER D6
SCREW M6 X 30
O-RING 71 X 2
PUMP COVER
RETAINING RING 47X1,75
LOCKING SCREW 1/2"
LOCKING SCREW R 1/8"
NUT M12
SPRING WASHER D12
LOCKING SCREW 1/4"
O-RING 24 X 2,5
VALVE HOUSING
O-RING 14 X 2
GASKET RING 20,7 X 28 X 1,5
LOCKING SCREW M20 X 1,5
OIL LEVEL GLASS SP100
VP30/VP500
MAINTENANCE INFORMATION
16 of 42
QUANTITY
1
12
12
12
1
1
1
2
1
6
6
1
1
1
1
1
1
1
4
1
1
6
4
4
1
1
1
1
1
4
4
1
1
1
1
1
1
1
