Rumbling
A deep rumbling sound can indicate that the main bearings 3/17 and 3/8 are worn. Check the
crankshaft wear by pulling the shaft from side to side. No movement should be detectable.
Diagrams
FIGURE
REF
1
INDEX OF PICTURES
2
CRANK CASE
3
CRANKSHAFT
4
PISTON AND CONNECTING ROD
5
CYLINDER, COMPL. 1ST. STAGE
6
CYLINDER, COMPL. 2ND. STAGE
7
CYLINDER, COMPL. 3RD. STAGE
8
FAN WHEEL AND GEAR WHEEL GUARD FOR AXIAL FAN
9
COOLING
10
UNLOADER MANIFOLD
11
UNLOADERS
12
OIL LUBRICATION
13
CRANK CASE BREATHER
14
MOTOR
15
MICROFILTER
Fig 1 - Compressor,
complete
July 21
MAINTENANCE INFORMATION
DETAILS
VP30/VP500
MANUAL PAGE
17
18
20
22
24
26
28
30
32
34
37
39
41
43
45
14 of 42
