Summary of Contents for AV Access 4KVC00
Page 1
4KVC00 USB 3.0 HDMI Video Capture User Manual...
Page 3
AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document.
Page 4
Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, or in another ...
Introduction Introduction Overview 4KVC00 is an HDMI to USB 3.0 (USB-C interface) video capture convertor, capable of supporting the HDMI2.0 standard 4K@60Hz resolution input and output, and provides up to 1080P@60Hz video capture to the computer. It will automatically detect the input video format and adjust to the appropriate output size and frame rate.
Introduction Panel 2 3 4 Name Description HDMI In Connect to an HDMI source device such as a PC. Power LED On/Off: The device is powered on/off. USB Type-C port (USB 3.0; Maximum data rate: 5Gbps; Support external device to supply power of 5V for the video capture.) Please use the following cable: USB-C USB Type-C to USB 3.0 Type-A cable;...
Specifications Specifications Video HDMI In/Out: HDMI 2.0 with 4K@60Hz 4:4:4 8bit Input / Output Signal Type USB-C Out: USB 3.0 (UVC and UAC standard) HDMI In/Out: Up to 3840 x 2160@60Hz, including 4K@60Hz/4K@30Hz/1080P/720P USB-C Out: Input / Output Resolution USB-C and USB 3.0: Up to 1080P@60Hz (YUV2 and MJPEG) USB 2.0: Up to 1080P@60Hz (MJPEG) Deep Color 4K@60Hz: Up to 8bit...
Application Application Display Display Laptop Connect a USB-C/USB 3.0/ USB 2.0 device Connect an Connect an Room PC to USB-C port HDMI display HDMI source such as a room PC, device such device such and connect as TV to HDMI as a PC to the room PC to Out port.
OBS Settings OBS Settings Perform the wiring according to the “Application” section. It is recommended to connect the device to USB3.0 port of PC in priority. Step 1: Click “+” “Video Capture Device”, and create a new video capture setting.
Audio Noise Settings Audio Noise Settings If there is noise when capturing audio, set the volume of the microphone to a value less than or equal to 54. The value is only related to the input of the computer, and has nothing to do with the volume of the applications (such as OBS) or the computer’s output volume.
Troubleshooting Troubleshooting No Power The device can be powered by the host device connected to USB-C port, and no additional external power supply is needed. Ensure that the connected USB device can supply enough power. No Video The device will be virtually set as a USB camera device in the connected host PC, ensure that you select the correct USB camera in the used software.
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
