- Page 1 4KVC00 USB 3.0 HDMI Video Capture User Manual...
- Page 3 AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document.
- Page 4 Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, or in another ...
-
Page 5: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................3 Panel ............................3 Application ......................4 Specifications ....................... 5 Audio & Video Settings ..................6 Audio Settings ........................6 Video Settings ........................10 Use OBS to Record Video..................10 Use ZOOM to Capture Video ................... -
Page 6: Introduction
Thank you for purchasing this product. For proper installation and optimum performance, please read the instructions in this manual carefully. 4KVC00 is an HDMI to USB 3.0 (USB-C interface) video capture convertor, capable of supporting the HDMI2.0 standard 4K@60Hz resolution input and output, and provides up to 1080P@60Hz video capture to the computer. -
Page 7: Package Contents
Introduction Package Contents Before you start the installation of the product, please check the package contents: Video Capture x 1 USB Type-C to USB 3.0 Type-A/Type-C Cable x 1 Mounting Brackets (with Screws) x 2 User Manual x 1 ... -
Page 8: Application
Application Application Display Display Laptop Connect a USB-C/USB 3.0/ USB 2.0 device Connect an Connect an Room PC to USB-C port HDMI display HDMI source such as a room PC, device such device such and connect as TV to HDMI as a PC to the room PC to Out port. -
Page 9: Specifications
Specifications Specifications Video HDMI In/Out: HDMI 2.0 with 4K@60Hz 4:4:4 8bit Input / Output Signal Type USB-C Out: USB 3.0 (UVC and UAC standard) HDMI In/Out: Up to 3840 x 2160@60Hz, including 4K@60Hz/4K@30Hz/1080P/720P USB-C Out: Input / Output Resolution USB-C and USB 3.0: Up to 1080P@60Hz (YUV2 and MJPEG) USB 2.0: Up to 1080P@60Hz (MJPEG) Deep Color 4K@60Hz: Up to 8bit... -
Page 10: Audio & Video Settings
Audio & Video Settings Audio & Video Settings Audio Settings If there are audio problems such as the sound is discontinuous or noisy when using the device, the reason is the connected PC’s recording audio sample rate is different with the audio sample rate of input HDMI audio. Please refer to the following steps to solve the problem. - Page 11 Audio & Video Settings Step 2: Select “Sound Control Panel” to open Sound control panel. Step 3: Click “Recording” to select “2-USB Audio Device” (the name may be “eEver USB Audio Device”) in this submenu, and then click “Properties” to open the properties panel.
- Page 12 Audio & Video Settings Step 4: Click “Advanced” in the properties panel, as shown in the following figure. In Advanced submenu, select format from drop down menu. • If the audio problem is sound discontinuity, the reason is the input HDMI audio sample rate is 44100Hz, but the PC recording sample rate is 48000Hz, please set the format from drop down menu to “2 channel, 16 bit, 44100Hz (CD Quality)”;...
- Page 13 Audio & Video Settings Step 5: After the format is selected, click “Apply” to make the settings take effect. Important: After the settings are completed, please restart the recording software such as OBS. www.avaccess.com services@avaccess.com...
-
Page 14: Video Settings
Audio & Video Settings Video Settings Use OBS to Record Video Perform the wiring according to the wiring diagram of “Application” section. And ensure the software “OBS” is installed on the PC connected to USB-C port. Step 1: Click “+” to select “Video Capture Device” in the submenu. www.avaccess.com services@avaccess.com... - Page 15 Audio & Video Settings Step 2: Create a new name in the following window, and then click “OK” to enter the next interface. www.avaccess.com services@avaccess.com...
- Page 16 Audio & Video Settings Step 3: Select “eEver USB Video Device” (the name may be “2-USB Video Device”) on “Device” tab. Step 4: Select “Custom” on “Resolution/FPS Type” tab. www.avaccess.com services@avaccess.com...
- Page 17 Audio & Video Settings Step 5: Select “1920x1080” on “Resolution” tab. Note: HDMI Input Resolution OBS Resolution Choice 720P 1280x720 1080P (recommended) 1920x1280 4KP30 4KP60 (recommended) www.avaccess.com services@avaccess.com...
- Page 18 Audio & Video Settings Step 6: Select “Output desktop audio (WaveOut)” on “Audio Output Mode” tab. Step 7: Click the check box in front of “Use custom audio device” to set it to enable. www.avaccess.com services@avaccess.com...
- Page 19 Audio & Video Settings Step 8: Select “eEver USB Audio Device” (the name may be “2-USB Audio Device”) on “Audio Device” tab. And then click “OK”. www.avaccess.com services@avaccess.com...
- Page 20 Audio & Video Settings Step 9: Click “Start Recording”. Note: Mute the Audio: in “Audio Mixer” zone, you can click the icon to mute the corresponding audio selected. Such as mute the audio from HDMI IN, click “Desktop Audio” tab. www.avaccess.com services@avaccess.com...
-
Page 21: Use Zoom To Capture Video
Audio & Video Settings Use ZOOM to Capture Video Perform the wiring according to the wiring diagram of “Application” section. And ensure the software “ZOOM” is installed on the PC connected to USB-C port. Launch ZOOM, enter the following interface. Click on the up-right corner or ->... - Page 22 Audio & Video Settings Step 1: Enter Settings interface. Click “Video” on the left to set. Select “eEver USB Video Device” (the name may be “2-USB Video Device”) on “Camera” tab. www.avaccess.com services@avaccess.com...
- Page 23 Audio & Video Settings Step 2: Click the check box in front of “Mirror my video” on “My Video” tab to set it to enable. Note: If the selected video is in mirror mode, please set “Mirror my video” to enable.
- Page 24 Audio & Video Settings Step 3: Select “Audio” on the left. And select “Speakers (USB Audio Device)” on “Speaker” tab. Step 4: Select “USB Audio Device” on “Microphone” tab. Step 5: Then exit the Settings page. If you create a new meeting, the video can be captured from HDMI In.
-
Page 25: Trouble Shooting
Trouble Shooting Trouble Shooting No Power The device can be powered by the host device connected to USB-C port, and no additional external power supply is needed. Ensure that the connected USB device can supply enough power. No Video The device will be virtually set as a USB camera device in the connected host PC, ensure that you select the correct USB camera in the used software. -
Page 26: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 28 AV Access Technology Limited V1.0.0...
