- Page 1 4KSP18-L 4K HDMI Splitter 1x8 User Manual...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. AV Access Technology Limited assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
-
Page 3: Important Safety Instructions
Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing, No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, or in ... -
Page 4: Table Of Contents
Overview Table of Contents Overview ........................2 Package Contents ........................3 Panel ............................... 4 Installation Instructions ..................6 EDID Management ....................7 Upgrade Guide ......................8 Preparation ..........................8 RS232 Update ..........................9 Troubleshooting ....................17 Specification ......................18 Warranty ....................... 20 www.avaccess.com... -
Page 5: Overview
Overview Overview 4KSP18-L is a 1x8 slim splitter for HDMI with Ultra HD 4K support. It reliably distributes one HDMI source signal up to eight HDMI displays. The HDCP compliant splitter supports resolutions up to 4K@30Hz and 1080p@60Hz. This splitter features two advanced technologies: EDID management,... -
Page 6: Package Contents
Overview Package Contents Before you start the installation of the product, please check the package contents: 1 x Splitter 4KSP18-L 1 x Power Supply (DC 12V 1A) 2 x Mounting Ear 1 x Phoenix Connector (3.5mm, 3Pin) ... -
Page 7: Panel
Overview Panel Top Panel ID Name Description ON: The splitter is on. Power LED OFF: The splitter is off. ON: Both source device and display device are connected. INPUT LED OFF: Only source is connected but no display device, or no source device is connected. ON: The correspondingly numbered output 1~8 is OUTPUT connected to a display device. - Page 8 Overview Front Panel Name Description Power Connector Connects to a DC 12 V 1A power adapter INPUT Port Connects to an HDMI source device OUTPUT Port 1~8 Connects up to eight HDMI display devices Rear Panel Name Description RS232 Update firmware EDID DIP Switch Adjusts EDID settings www.avaccess.com...
-
Page 9: Installation Instructions
Installation Instructions Installation Instructions Connect an HDMI source device (such as a Blu-Ray, games console, media server etc.) to the input port of the splitter using quality HDMI cables. Connect up to eight HDMI display devices (LED/LCD display or projector) to the output ports of the splitter. Connect the power adapter to the splitter and power on all devices. -
Page 10: Edid Management
EDID Management EDID Management The splitter features EDID management, which provides three EDID options for different resolutions output and ensures that the HDMI source reliably outputs correct content for display. The following table lists the EDID information built in the splitter. You can toggle the switch to a certain position to read EDID from a specific output or to directly use the EDID information. -
Page 11: Upgrade Guide
Upgrade Guide Upgrade Guide Preparation Hardware 4KSP18-L x 1 PC x 1 USB-to-UART cable x 1 ST-LINK V2 Update Tool x 1 Software Hex file ST-LINK/V2 driver program: st-link_v2_usbdriver.exe ST MCU update tool: ST Visual Programmer ST MCU UART update tool: Flash Loader Demo... -
Page 12: Rs232 Update
Upgrade Guide RS232 Update Part 1. Install Flash Loader Demo on PC Note: It supports Microsoft Windows XP, Windows Vista, Windows 7 and Windows 10. Take Windows XP as an example: Step 1. Double click the setup file. Step 2. Click Next. www.avaccess.com... - Page 13 Upgrade Guide Step 3. Click Yes. Step 4. Click Next. www.avaccess.com...
- Page 14 Upgrade Guide Step 5. Click Next, it starts to install. Step 6. Click Finish. www.avaccess.com...
- Page 15 Upgrade Guide Part 2. Hardware Connection Connect the PC to the splitter by USB-to-UART cable. Part 3. Update Step 1. Double click Flash Loader Demo. Step 2. Configure the splitter as shown in the following figure, power on the splitter and then click Next immediately. www.avaccess.com...
- Page 16 Upgrade Guide Step 3. The following page comes up. www.avaccess.com...
- Page 17 Upgrade Guide Step 4. Choose STM8_32K from the drop down list, and then click Next. www.avaccess.com...
- Page 18 Upgrade Guide Step 5. Choose Download to device, browse for the .hex or .S19 file, choose Global Eras, click Next. www.avaccess.com...
- Page 19 Upgrade Guide Step 6. Download successful, as shown in the following figure. Step 7. Click on Close button to close the window. www.avaccess.com...
-
Page 20: Troubleshooting
Troubleshooting Troubleshooting 1. The display device connected to the splitter shows no picture. Check that all the devices are on and working properly. Check that all the cables are qualified and connected properly. Check that the display device works properly and that the source ... -
Page 21: Specification
Specification Specification Technical Input/ Output 1 x HDMI IN, 8 x HDMI OUT Input/ Output Signal HDMI 1.4a, 3D, DVI 1.0, HDCP 1.4 Type 4096 x 2160@24Hz, 3840 x 2160@30Hz, Input/ Output Resolution 1920x1080@30/60Hz, 1280x720@60Hz, Support 720x576@30/60Hz, 640x480@30/60Hz Maximum Data Rate 10.2 Gpbs Maximum Pixel Clock 340 MHz... - Page 22 Specification General Operating Temperature 0°C to 45°C (32°F to 113 °F) Storage Temperature -20°C to70°C (-4°F to 158 °F) Humidity 10% to 90%, non-condensing Power Supply DC 12 V 1 A Power Consumption 1080p: 3.5 W, 4K: 5 W Human-body Model: ESD Protection ±8kV(Air-gap discharge)/ ±4kV(Contact discharge)
-
Page 23: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 24 AV Access Technology Limited V1.0.8...
