- Page 1 Total Solution for Car Multimedia Video Interface Installation Manual Model No.: PAS-FD-951 Camera Interface Version: 2.1 Cartizan Technology | www.icartizan.com...
- Page 2 The 'Power/CAN Cable' should always be connected last and be disconnected first. The vehicle should be powered off before installing this camera interface. You should check the names and colors of each wire exactly before you connect the wires. Cartizan Technology | www.icartizan.com 2 / 8...
-
Page 3: Specification
Compatible System FORD SYNC 3 version 2.0, 2.3, 3.0 Fiesta, Ecosport, Edge, Focus, Mondeo, KUGA MAX (Hybrid), Compatible Car Model KUGA(GAS), Taurus, Mustang, F150, etc. Compatible Screen Size 6.5", 7", 8" Compatible Year 2016-2018 Cartizan Technology | www.icartizan.com 3 / 8... - Page 4 Total Solution for Car Multimedia Video Interface 2. Components Cartizan Technology | www.icartizan.com 4 / 8...
-
Page 5: Dip Switch Setting
No.5 No.6 No.7 No.8 Selection of Function OFF (▲) OFF (▲) OFF (▲) OFF (▲) Add-on rear camera, Guide line OFF (▲) OFF (▲) ON (▼) OFF (▲) Add-on rear/front camera, Guide line Cartizan Technology | www.icartizan.com 5 / 8... -
Page 6: Installation Diagram
Total Solution for Car Multimedia Video Interface 4. Installation Diagram Cartizan Technology | www.icartizan.com 6 / 8... - Page 7 Total Solution for Car Multimedia Video Interface 5. Remark For some new models of FIESTA, TRANSIT AND ECOSPORT, the SYNC box is behind the dashboard instead of the radio monitor. Cartizan Technology | www.icartizan.com 7 / 8...
- Page 8 Total Solution for Car Multimedia Video Interface Copyright ©Cartizan. All Rights Reserved. Cartizan Technology | www.icartizan.com 8 / 8...
