- Page 1 Instruction Manual Wireless CarPlay/Android Auto Integration for Audi MIB/MIB II system Model No. VI-AD320C-B9 MCU Ver. 19.1.11.12 SW Ver. V2.0.1.4.lzy Manual Ver. Date May 17. 2019...
-
Page 2: Table Of Contents
Operation Instruction How to switch from original to add-on interface Add on module UI How to connect/disconnect wireless Apple CarPlay CarPlay operation Android Auto operation Other settings 2 / 17 Cartizan Technology | www.icartizan.com... -
Page 3: Warning
Kindly check all components are in the box when receiving the product. If anything missing, inform to the supplier/manufacturer. Start the engine before loading, check the interface whether have function displayed, key control whether correct, the vehicle 3 / 17 Cartizan Technology | www.icartizan.com... - Page 4 There should be a good plan about connect cables, avoid affecting the active component of connecting, such as control components of turning the steering wheel, throttle and brake pedal. There need to be fastened after connecting cables in case of a drop. 4 / 17 Cartizan Technology | www.icartizan.com...
-
Page 5: Compatibility
Select vehicles with MIB/MIB2 STD, 2013- 5.8 / 7 inch monitor 4 Pin LVDS connector A4/S4 2016- Audi A5/S5 2016- 2018- 2016-2018 NOTE! This interface does NOT fit vehicles with 8.3 inch factory screen. 5 / 17 Cartizan Technology | www.icartizan.com... -
Page 6: Features
Operate by OEM knob controller & steering wheel buttons Support OEM microphone Further software update via USB port Wireless/ AirPlay Wireless/wired USB media F/R view Further SW. wired Android Auto Mirroring playback cameras update CarPlay 6 / 17 Cartizan Technology | www.icartizan.com... -
Page 7: Package Components
Package Components: Optional Component: Quadlock Main Power Cable 4 pin LVDS Cable External Microphone Main Unit (Needed when a car without Dimension: 130*105*30 mm MIC) USB & CVBS Cable WiFi & BT Antenna 7 / 17 Cartizan Technology | www.icartizan.com... -
Page 8: Connection Diagram
Rear camera in DIP SW Front camera/DVR video in Camera Power. Supply 12V power for backup camera WiFi & BT antenna Reverse Detect. Connect to reverse light if CAMERA_POWER cable does not output 12V 8 / 17 Cartizan Technology | www.icartizan.com... -
Page 9: How To Connect An External Mic (Optional)
How to connect an external MIC (optional): OEM quadlock connector MIC+ MIC- MIC+ MIC- DONE Connect the external microphone to pinout MIC+ and MIC- of OEM quadlock connector. NOTE! Ignore this page if your car integrates original microphone. 9 / 17 Cartizan Technology | www.icartizan.com... -
Page 10: Dip Setting
2013-2017 Q5 (MMI); AD320C-Q5U; 2012-2015 A4/A5/A6/A7 (MMI) (AD320C-A6 for 2010-2012 Q5 (MMI); 2012-15 A6/A7) 2010-2011 A4/A5 (MMI) 2010-2011 A6 (C6) AD320C-Q7 2010-2015 Q7 2016-2018 A6/A7 AD320C-A7C 2014-2018 Q3 AD320C-Q3S AD320C-A8 Without MMI: 2009-2015 A4/A5/Q5 AD320C-SYM 10 / 17 Cartizan Technology | www.icartizan.com... -
Page 11: Operation Instruction
Order: OEM - Add on - OEM AUX jack but with AMI, please plug in an AMI cable to factory AMI port, and do not connect anything with another side of the cable. OEM UI Add on Module Interface 11 / 17 Cartizan Technology | www.icartizan.com... -
Page 12: Add On Module Ui
CarPlay/Android Auto status bar. Display when iPhone/Android ○ phone has connected CarPlay/Android Auto ○ Front view/DVR video in ○ ○ Wireless/Wired CarPlay and wireless Android Auto Settings ○ ○ Back to factory infotainment Wired Android Auto 12 / 17 Cartizan Technology | www.icartizan.com... -
Page 13: How To Connect/Disconnect Wireless Apple Carplay
BT setting menu Your iPhone Device Select iAP2 Profile, then tap Pair & Allow on the pop-up Connect Mobile Device notification of iPhone Select your iPhone device Start Search in the searched list 13 / 17 Cartizan Technology | www.icartizan.com... -
Page 14: Carplay Operation
CarPlay. Bluetooth paired devices, you can find out all BT paired devices list here Reset add on module CarPlay Operation Long press 3S to activate Siri Back to add on module 14 / 17 Cartizan Technology | www.icartizan.com... -
Page 15: Android Auto Operation
: Turn the dial to move menu-pointer; Click as confirm; Long press 3S to activate Google Assistant ○ : Menu-pointer switch to A area; Long press to bring up upper left menu B area ○ : Menu-pointer switch to B area 15 / 17 Cartizan Technology | www.icartizan.com... -
Page 16: Other Settings
Other settings Audio effect setting Display setting Front image flip Right/Left driving horizontal mode, also available for CarPlay Choose reversing Automatic front view display camera type time, 0 means disable front view 16 / 17 Cartizan Technology | www.icartizan.com... - Page 17 Total Solution for Car Audio & Video Interface Copyright © Cartizan. All rights reserved. 17 / 17 Cartizan Technology | www.icartizan.com...
