- Page 1 RM5800 User Manual RM5800 User Manual Emerson™ Automation Solutions, Rosemount® Inc Revision B.1 18 March 2022 Revision B.1...
-
Page 2: Table Of Contents
RM5800 User Manual ONTENTS Purpose ..............................3 General Information ..........................3 Product Description ........................3 Product Specifications ........................... 3 Operational Description ........................ 3 Normal Operating Conditions ....................... 3 Radio Specifications ........................4 Antenna Specifications........................4 Integration Instructions ........................5 Design description......................... 5 4.1.1 Device Photo ......................... -
Page 3: Purpose
RM5800 User Manual URPOSE This document serves as a user manual for the Emerson Rosemount RM5800 radio module. ENERAL NFORMATION 2.1 P RODUCT ESCRIPTION Rosemount Inc.’s RM5800 WirelessHART 2.4GHz Radio Module has been specifically designed to interface with industrial and process control equipment designed and marketed by the Emerson family of companies. -
Page 4: Radio Specifications
RM5800 User Manual 3.3 R ADIO PECIFICATIONS Parameter Units Comments Operating frequency 2.4000 2.4835 Channel center: 2.440Ghz Number of channels Channel separation Occupied channel bandwidth At –20 dBc Modulation IEEE 802.15.4 Raw data rate kbps Receiver operating maximum input level Receiver sensitivity –95 At 50% PER, V... -
Page 5: Integration Instructions
NSTALLATION UIDELINES The RM5800 radio module is only available for use in the Emerson family of products. The RM5800 is not readily available to consumers; it is not sold by retail to the public. The RM5800 radio module has a limited modular approval, which requires that it be installed by approved host integrators under advisement of the module manufacturer. -
Page 6: Fcc Antenna Selection
Further, the RM5800 is only utilized by Emerson internal companies, and is not available to the general public. The RM5800 is an industrial network communication module and only works on Wireless Hart protocols and as such is part of an industrial process control system professionally installed and maintained per Section 4.3 of the modular integration manual, available... -
Page 7: Fcc Documentation Requirements
Antenna types: 1. Maximum 8.0dBi dipole antenna (tested kinds include Taoglas 2.5/3.0dBi PCB strip, Emerson 4.5dBi per drawing 00753-2035 and PCTEL 8.0dBi omnidirectional antenna BOA24008NF), nominal impedance 50 ohms 2. -
Page 8: Eu Compliance
RM5800 User Manual d'interférences et (2) cet appareil doit accepter toute interférence, y compris les interférences pouvant causer un mauvais fonctionnement du dispositif. 5.3 EU C OMPLIANCE The RM5800 has been demonstrated compliance to EN 300 328. Host products are required to demonstrate compliance to EU Radio Equipment Directive (RED) 2014/53/EU and follow all documentation and labeling requirements. - Page 9 RM5800 User Manual The Emerson logo is a trademark and service mark of Emerson Electric Co. Rosemount is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners. Revision B.1...
