EASYGEN-3000XT FLASH INSTRUCTION
Flashing a Woodward easYgen-3000XT device for full or partial update
What to do?
The updating process comes with conditions, which need certain preparations, ask for step-by-step procedure,
and will be closed with some final preparations.
First, read this instruction manual completely and carefully, before you start updating your device.
w w w . w o o d w a r d . c o m
Released
For trained personnel only!
Updating the device software needs expert level. Otherwise, the device
can become unusable or even cause error function that can lead into
dangerous situation with genset.
DO NOT switch off the device
until the flash procedure is explicitly mentioned as
completely finished as described below
If the device to be updated is installed into a running genset system, it
is mandatory that a genset control expert guarantees trouble free
system setup during update process.
If firmware update process is however interrupted before it has finished,
due to lost or switched off power supply, your device may be no longer
able to operate.
Note that you perform firmware update at your own risk.
37630 easYgen-3000XT Flash Instruction
#37630
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Woodward EASYGEN-3000XT Series
Summary of Contents for Woodward EASYGEN-3000XT Series
- Page 1 EASYGEN-3000XT FLASH INSTRUCTION #37630 Flashing a Woodward easYgen-3000XT device for full or partial update For trained personnel only! Updating the device software needs expert level. Otherwise, the device can become unusable or even cause error function that can lead into dangerous situation with genset.
- Page 2 Released PRECONDITIONS The following conditions are mandatory BEFORE updating a device: PC or laptop computer with the latest version of Woodward software ToolKit installed here Get the latest version Appropriate configuration files installed/copied on your computer Powered up easYgen-3000XT (12/24 V) but ...
- Page 3 Released PREPARATIONS EASYGEN-3000XT Select operation mode "STOP" Ensure that "running gensets" are controlled by other genset control(s) Remove all interface connections, except the connection for updating the device TOOLKIT Save your current settings as *.wset file on your computer to ensure re-storing it later ...
-
Page 4: Update Procedure
Released UPDATE PROCEDURE Select “File” --> “Load Application” and follow the instructions - Load Application sub window opens Continue with “Next” - Application File Selection window opens Click “Browse” and select the provided *.scp file. If available, select _eth.scp or _usb.scp with respect to the appropriate interface to which you are connected now Continue with “Next”... - Page 5 Released Update via USB: Continue at Step 6 “Select Device” window Update via Ethernet: appears. Notes! Ensure that the device will NOT BE SWITCHED OFF during update process before you click “Next”! Select you device if not already selected and click “Next”...
- Page 6 Released Via Ethernet, the transfer takes about 6 - 9 minutes. Via USB, the transfer takes about 15 – 18 minutes. Still valid: DO NOT SWITCH OFF THE DEVICE! Wait until the bar graph is completed. With some ToolKit versions (e.g.: ToolKit 5.1) loading application window seems to stuck up at the end when the bar graph is full.
- Page 7 Released Now the device will reboot automatically and continues the update process. easYgen-3000XT with display: During the reboot, the display of the device will show in RED: “Updating: Please do not switch off the device!” The bar graph shows the progress of the update action DO NOT SWITCH OFF THE DEVICE! This process will finish after about 4-5 minutes...
- Page 8 Released Check the version In ToolKit: Navigate to “STATUS MENU” “Diagnostic” – “Version” Via HMI: “Next Page” “Diagnostic” “Version” The “Application”, “HMI”, “Bitmap” and “Language” must have the same version. If there is any discrepancy, there will show an exclamation mark besides the respective version HMI Screen: ToolKit screen HMI screen...
- Page 9 Released Close update Ensure latest (saved) setting Check whether your latest specific settings are still/again loaded. If not: Re-load your latest saved settings or execute “factory settings” Undo temporary safety preparations Re-connect all interface connections that have not been necessary for the flash update process Device is updated and ready for use! Start your application w w w .
- Page 10 OR INDIRECTLY FROM THE USE OF THIS APPLICATION NOTE, UNLESS WOODWARD HAS PROVABLY ACTED WITH WILLFUL MISCONDUCT OR GROSS NEGLIGENCE. WOODWARD RESERVES THE RIGHT TO UPDATE ANY PORTION OF THIS PUBLICATION AT ANY TIME. INFORMATION PROVIDED BY WOODWARD IS BELIEVED TO BE CORRECT AND RELIABLE. HOWEVER, NO RESPONSIBILITY IS ASSUMED BY WOODWARD UNLESS OTHERWISE EXPRESSLY UNDERTAKEN.
