  • Page 3 The easYgen-3000XT series are control units for engine-generator system management applications. The control units can be used in applications such as: co-generation, stand-by, AMF, peak shaving or distributed generation. The easYgen-3000XT series is also applicable for islanded and mains parallel operations. B37927 easYgen-3000XT Series...
  • Page 4 • In this case, the easYgens-XT will function as an engine control with generator, • mains and engine protection. • The control unit can open and close the generator circuit breaker (GCB) and the • mains circuit breaker (MCB). easYgen-3000XT Series B37927...
  • Page 5 • Refer to ╚═▷ “2.2 Import/Export control” for details. • Load dependent start/stop (LDSS) • Refer to ╚═▷ “2.3 Load dependent start/stop (LDSS)” for details. • Load sharing • Refer to ╚═▷ “2.4 Load sharing” for details. B37927 easYgen-3000XT Series...
  • Page 6: Table Of Contents

    ............... . 29█ easYgen-3000XT Series B37927...
  • Page 7: General Information

    This combination of symbol and signal word indicates a possibly-dangerous situation that could cause slight injuries if it is not avoided. NOTICE! This combination of symbol and signal word indicates a possibly-dangerous situation that could cause property and environmental damage if it is not avoided. B37927 easYgen-3000XT Series...
  • Page 8: Copyright And Disclaimer

    All information and instructions in this manual have been provided under due consideration of applicable guidelines and regulations, the current and known state of the art, as well as our many years of in-house experience. Woodward assumes no liability for any damages due to: •...
  • Page 9: Service And Warranty

    In addition, our employees are constantly interested in new information and experiences that arise from usage and could be valuable for the improvement of our products. Warranty terms Please enquire about the terms of warranty from your nearest Woodward representative. For our contact search webpage please go to: ══▷ http://www.woodward.com/ Directory.aspx...
  • Page 10: Personnel

    The workforce must only consist of persons who can be expected to carry out their work reliably. Persons with impaired reactions due to, for example, the consumption of drugs, alcohol, or medication are prohibited. When selecting personnel, the age-related and occupation-related regulations governing the usage location must be observed. easYgen-3000XT Series B37927...
  • Page 11: General Safety Notes

    Device implemented self test this Woodward device has a self test check implemented. Permanently under control are: • processor function and • • supply voltage.
  • Page 12 Unit includes a lithium backup battery for Real Time Clock. Field replacement of the battery is not allowed. In case of battery replacement please contact your Woodward service partner. Electrostatic discharge Before working with terminals please read the following instructions.
  • Page 13 For additional information on how to prevent damage to electronic components caused by improper handling, read and observe the precautions in: • "Woodward manual 82715, Guide for Handling and Protection of Electronic Controls, • Printed Circuit Boards, and Modules".
  • Page 14: Protective Equipment And Tools

    • • Any use which exceeds or differs from the intended use shall be considered improper use! • • No claims of any kind for damage will be entertained if such claims result from improper use. • easYgen-3000XT Series B37927...
  • Page 15: Reduced Functionality

    The busbar measurement is not available and the related measured values/parameter are hidden. Fig. 2: Toolkit HOME PAGE The status and necessary references from the busbar (in range or dead) depends now from the breaker feedback of the GCB and MCB B37927 easYgen-3000XT Series...
  • Page 16: Import/Export Control

    Mains. Phase angle for synchronization The phase angle between Mains and Generator is used for the synchronization from the GCB and MCB Fig. 3: Toolkit Busbar/System/LSx Import/Export control The Import/Export control is not available in the device easYgen-3000XT Series B37927...
  • Page 17 Gen. PF → Gen. PF Mains PF → Gen PF is internal used ◦ kvar setpoint ◦ Gen. kvar → Gen. kvar Mns. Export kvar → Gen kvar is internal used Mns. Import kvar → Gen kvar is internal used B37927 easYgen-3000XT Series...
  • Page 18: Load Dependent Start/Stop (Ldss)

    2 Reduced functionality 2.3 Load dependent start/stop (LDSS) Fig. 5: Toolkit PF/kvar setpoints Load dependent start/stop (LDSS) The load dependent start/stop functionality is internal disabled and not available. All related configuration and sequencing pages are hidden and not visible. easYgen-3000XT Series B37927...
  • Page 19: Load Sharing

    The LITE version can operate only as a single device in isolated and parallel operation and the load sharing with other devices is not available. All related configuration and multi unit pages are hidden and not visible. B37927 easYgen-3000XT Series...
  • Page 20 Released 2 Reduced functionality 2.4 Load sharing Fig. 7: Toolkit Load share easYgen-3000XT Series B37927...
  • Page 21: Configuration

    The circuit breaker commands must be checked before every commissioning because the relays can be used for different applications and can be assigned to various functions. • Make sure that all relay outputs are configured correctly. • B37927 easYgen-3000XT Series...
  • Page 22 Only applicable for application modes The "Command: close GCB" output issues the signal for the GCB to close. This relay may be configured as an impulse or steady output signal depending on parameter "3414 GCB close command". Impulse easYgen-3000XT Series B37927...
  • Page 23 The auxiliary services output (LogicsManager 03.01) is always enabled in MANUAL operation mode. Relay output [R Programmable This discrete output is enabled when a warning alarm (class A or B alarm) is issued. Preconfigured to "Warning alarm" B37927 easYgen-3000XT Series...
  • Page 24: Configure Engine

    Normally open: The relay "command: GCB open" will be energized to open the GCB and will be de-energized again after the discrete input "Reply GCB" is energized to signal the control that the GCB is open. Notes easYgen-3000XT Series B37927...
  • Page 25 LogicsManager have been fulfilled the GCB will be opened [(0 & 1) & 1] immediately. = 12052 Notes The "Open GCB immediately" has a higher priority than the Enable GCB function and is valid for all application and operating modes. B37927 easYgen-3000XT Series...
  • Page 26: Configure Breakers: Mcb

    "Reply MCB" is energized to signal the control that the MCB is open. Not used The LogicsManager relay R9 is freely programmable. The pre- configuration "04.22 Opening MCB active" works similar to the "N.O." logic. easYgen-3000XT Series B37927...
  • Page 27: Glossary And List Of Abbreviations

    Failure Mode Indicator Graphical Application Programming (GAP™) Group Controller Generator Circuit Breaker Woodward device series (Genset Control) - not preferred for new design! Generator Group Breaker (speed) Governor; rpm regulator Human Machine Interface e.g., a front panel with display and...
  • Page 28 Photovoltaic Reactive power Apparent power Sequencer A sequencer file is carrying specific settings e.g. to enable communication with and/or control of an expansion module. Such files can be prepared by Woodward. Serial Number Suspect Parameter Number Voltage easYgen-3000XT Series B37927...
  • Page 29: Index
