Introduction; Packaging; Specifications; Safety Information - Labnet Pro 30 Instruction Manual

1.0 Introduction

Congratulations on purchasing your Labnet Pro 30 Reciprocal Shaker. This shaker features a left to right linear action to provide gentle
to vigorous shaking. Four platform configurations make this model valuable for a variety of applications.

2.0 Packaging

The Labnet Pro 30 Reciprocal Shaker includes the following components:
Pro 30 Reciprocal Shaker

Instruction Manual

230V includes EU and UK plug types

NOTE: Platform needs to be purchased separately.

3 .0 Specifications

Electric Power Supply
S2030-RC-B
S2030-RC-B-230V
Fuse
Speed
Stroke Length
Timer
Maximum Load
Dimensions (W x L x H)
Platform Dimensions (W x L)
Weight
Operating Conditions
This device is intended for use in a basic electromagnetic environment (Basic, class B), and it is in compliance with IEC 61326-1.
Supply cord can be exchanged only with cord 3 x 1.0 mm
The Pro 30 Reciprocal Shaker is designed to be safe at least when operated under the following conditions:
Indoor use only

Altitude up to 2,000 meters

Pollution degree 2


4.0 Safety Information

Do not use the shaker near water. Ensure that water doesn't get on the device, particularly during cleaning.
If the unit is used in a manner not specified by the manual, the degree of protection may be impaired.

The plug should only be used in a wall outlet with protective earthing.

The unit should be used with a power supply cord of at least 18 AWG.

The equipment will not restart if mains power is interrupted.

The equipment will restart in cases of mechanical interruption.

Do not expose the shaker to aggressive vapors (e.g., organic solvents).

Do not insert any objects into the shaker (such as a screwdriver or metal rods).

Never operate the shaker without the platform securely attached.

Hazardous samples should be shaken only in appropriate containment vessels.

Do not shake flammable or explosive samples.
Do not put your fingers between the platform and the housing. Danger of mechanical injury.
120V ± 10%, 50/60Hz, 0.3A
230V ± 10%, 50/60Hz, 0.15A
2 x 1A
From 5 to 150 strokes per minute
1.2 in. (30 mm)
20 to 120 minutes, in 10 min. steps, HOLD function
11 lbs. (5 kg) including platform
10 x 12.6 x 6.3 in. (25.5 x 32 x 16 cm)
11.8 x 11.8 in (30 x 30 cm)
14.6 lbs. (6.6 kg)
4°C to 65°C, up to 85% RH, non-condensing
or for USA/Canada 3 x 18 AWG.
2
Instruction Manual | 1
