Troubleshooting; Maintenance And Cleaning; Installation Of The Double Platform - Labnet Pro 30 Instruction Manual

7.0 Troubleshooting

Should you have a question about the operation of the Labnet Pro 30 Reciprocal Shaker or if service is required, contact your Corning
representative. Do not send in a unit for service without first calling to obtain a repair authorization number. Should the unit require
return to Corning for service, it should be properly packaged to avoid damage. Any damage resulting from improper packaging shall be
the responsibility of the user.
Problem
Power switch doesn't illuminate
when turned on.
Shaker doesn't start when you press
START/STOP button.
HOLD yellow signal light and RUN
green signal light are blinking.

8.0 Maintenance and Cleaning

No routine maintenance or lubrication is required.

It is recommended that the shaker is kept clean to ensure long trouble-free operation.

8.1. Cleaning
The housing of the shaker can be cleaned with a soft, damp cloth or special cleaners for plastic surfaces (e.g., for car interior –
armature). Do not immerse the device or spill liquids on the device.
NOTE: Do not use any aggressive or abrasive cleaners (acetone, nitro, polish, etc.) because the surface can get permanently damaged.
Prior to any cleaning or maintenance of the device, unplug the power cord from the wall socket.

9.0 Installation of the Double Platform

Before the installation of the double platform, turn off the Power switch.
For installation of the double platform, prepare the upper platform with the rubber pad and posts kit, which includes four posts, four
washers, four screws and four nuts.
Posts kit
E
A
B
C
1. Set the four posts (A) above the four holes at the corners of the bottom platform.
2. Put the washer (B) on each screw (C), and then screw it into each post from the bottom side of the platform.
3. Fit the upper platform (D) on the top of the four posts so that the threads of the posts are protruding through the four corner holes.
4. Screw the four nuts (E) on the threads of the four posts to fix the upper platform.
Explanation/Solution
Check the connection to the main power supply.

Check the fuses.

Call for authorized service.

Check the connection to the main power supply.

Check the fuses.

Call for authorized service.

Motor overload. Reduce the load on the platform.

Call for authorized service.

E
D
A
B
C
