StarTech.com M2-USB-C-NVME-SATA Quick Start Manual

M.2 SATA/NVMe SSD Enclosure - Tool-less - USB 3.2 (10Gbps) w/ USB-C and USB-A Cables

Product ID

M2-USB-C-NVME-SATA

Product Diagram

Front
1 2
Component
1
Drive Tray Cover • Enclosure component
2 • Connect the Enclosure to the Host Computer
USB-C Port
• Solid Blue indicates the Enclosure is receiving
power
Power and Activity
3
LED Indicator
• Flashing Blue indicates Drive read/write
activity
4 • Pull down to eject the Drive Tray
Drive Tray Release Tab

Package Contents

• M.2 SSD Enclosure x 1
• USB-C to USB-C Cable x 1
• USB-C to USB-A Cable x 1
• Thermal Pad x 1
• SSD Fastener Pegs x 2
• Quick-Start Guide

Product Information

For the latest product information, technical specifications, manuals, and Declarations
of Conformance, please visit:
www.StarTech.com/M2-USB-C-NVME-SATA
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Back
3
4
Function

Product Requirements

• SSD x 1
• M-Key and B+M-Key PCI Express M.2 NVMe and M.2 SATA
• 30 mm, 42 mm, 60 mm, or 80 mm Drive Length

Installation

Install a Drive

Warning! Handle Drives with care.
1. Pull the Drive Tray Release Tab down to eject the Drive Tray. (Figure 1)
Drive Tray
2. Carefully pull the Drive Tray out of the Enclosure.
3. Insert one SSD Fastener Peg into the Drive Tray Hole that corresponds with the
length of the Drive and slide the SSD Fastener Peg into the Notch. (Figure 2)
SSD Fastener Peg
4. Gently slide the Connector on the Drive at a 30-degree angle into the
corresponding Drive Connector, located on the Drive Tray. (Figure 3)
Note: The Connector on the Drive is keyed so that it only fits one way.
5. Pull the SSD Fastener Peg away from the Drive, lightly push the Drive down into
position on the Drive Tray, and release the SSD Fastener Peg. (Figure 3)
Quick-Start Guide
Drive Tray
Release Tab
Figure 1
Notch
Figure 2
Manual Revision: November 6, 2021 12:28 AM
