ML150 User Manual V1.0
Learn how to set up your new MiCODUS Tracker
Copyright ©2022 MiCODUS | All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML150 and is the answer not in the manual?

Questions and answers

Related Manuals for MICODUS ML150

Summary of Contents for MICODUS ML150

  • Page 1 ML150 User Manual V1.0 Learn how to set up your new MiCODUS Tracker Copyright ©2022 MiCODUS | All Rights Reserved...

  • Page 2: Main Features

    IP65 Voice Overspeed Vibration Geo-fence Shift Alarm Monitor Alarm Alarm 2.Specifications Model ML150 Weight 58.4g Device Information Dimensions 36mm(L) * 23mm(W) * 54mm(H) Charging Time Around 5 hours Battery Working Time 3-5 days under tracking mode Working Voltage DC 3.4V - 4.5V...

  • Page 3: Activate Device

    External Interface Mircrophone,Magnetic 3. Activate Device Install the SIM card via the correct direction as below: Normal SIM State Event Charging Solid POWER LED (RED) Charger inserted and battery has been fully charged Dark Charger has not been inserted Dark Searching for network Flash every 1 second CELL LED...

  • Page 4: Package Content

    Hard-Wired Car Charger (Optional) 5. Functions Explanation Please follow with the quick user guide carefully! For example: a. Working modes setting * ML150 has 3 working modes to meet different tracking ML150 demands, the setting command format is as below: MODE,1,10,3600# MODE,A,T1,T2#...
  • Page 5 Voice Monitor: For example: * Set center number by this sms command: ML150 CENTER,A,center number# CENTER,A,12345678910# * Switch the tracker to voice monitor mode by this sms command: MONITOR# SET CENTER NUMBER OK * Dial the sim number of the tracker from the center...

  • Page 6: Troubleshooting

    APN,CMNET# (if no name & Password) APN Setting APN,Network name[,name,password]# APN,internet,internet,internet# (if with name & Password) If set with Domain Name: SERVER,1, SERVER,1,d.micodus.net,7700# Domain,Port# Server Setting If set with IP: SERVER,0,IP,Port# SERVER,0,47.254.77.28,7700# A=old password, six digitals, digital range: 0-9, Revise the instruction PASSWORD,[A],[B]# default：000000;...
  • Page 7 Functions Command Format Explanation Check ID,IMEI,APN, IP,PORT,TIMER,Center Parameter Inquiry PARAM# number,SOS number,Time Zone Latitude&Longitude WHERE# Inquiry Map URL Inquiry URL# Check All Alarms Status ALARM# BATTERY: XX% (Built-in Battery Power Percent) NET: CLOSED (No Network) FAILED (Connecting Network or Failure) SUCCESS(Connected to Network), NONE (No GSM Signal) HIGH / MED / LOW (Signal Strength)
  • Page 8 Functions Command Format Explanation Delete Center Number CENTER,D# A=1/2/3, 1:Tracking mode 2:Power saving mode 3:Hibernation mode; Default mode: 1 T1: upload interval of GPS data in moving status, unit: second,10-3600s; default: 10s T2: upload interval of GPS data in static status, unit: second, 180-65535s;...
  • Page 9 Functions Command Format Explanation A=ON/OFF, default: OFF; SENALM,[A][,M]# M=0/1/2, way of alarming, 0 :GPRS only, 1: SMS+ Vibration Alarm GPRS, 2 : GPRS+SMS+phone call, default:2 Setting SENALM,OFF# Example: SHIFT,ON,100,1# ( Means Setting 100 meters shift alarm range, when the ignition turned off, vehicle’s 100 meters’...

  • Page 10: Any Questions

    9. Any Questions? E-mail: support@micodus.com Skype: MiCODUS 10. Download the APP Search "MiCODUS" in iOS APP store or Google Play Store, or just scan the QR code as below to download MiCODUS APP: Download on the APP Store Download for...
