- Page 1 ► Assembly, installation and operating instructions Keep these instructions in a safe place for future use! Issue02/22EN SAP No.1562744...
-
Page 3: Table Of Contents
5.1 Requirements governing the installation site..................11 5.2 Installation.............................. 11 5.2.1 Installation situation (unit installed)......................11 5.2.2 Installing KS in a dry wall.......................... 11 5.2.3 Adjusting the eccentric rollers ........................13 5.2.4 Adjusting the optional volumetric flow limiter ..................14 6 Pre-commissioning checks .................... -
Page 4: General
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions General About these instructions These instructions ensure the safe and efficient handling of this equipment. These instructions form an integral part of the equipment and have to be kept in the direct vicinity of the equipment and available to personnel at all times. All personnel must have carefully read through these instructions prior to commencing all work on the equipment. -
Page 5: Safety
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Safety This section provides an overview of all important safety aspects to ensure optimum protection of personnel as well as safe and trouble-free operation. In addition to the safety instructions in these operating instructions, the valid safety, accident pre- vention and environmental protection regulations must be observed for the area of use of the unit. -
Page 6: Personnel Requirements - Qualifications
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Personnel requirements - Qualifications Expertise The installation of this product requires specialist knowledge of heating, cooling, ventilation, installation and electrical engin- eering. This knowledge, generally learned in professional training in one of the fields mentioned above, is not described sep- arately. -
Page 7: Transport, Storage And Packaging
IMPORTANT NOTE! Warranty claims can only be made within the applicable period for complaints. (More information is avail- able in the T&Cs on the Kampmann website) IMPORTANT NOTE! 2 people are needed to transport the unit. Wear personal protective clothing when transporting the unit. -
Page 8: Storage
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Storage Store packaging under the following conditions: Do not store outdoors. Store in a dry and dust-free place. Store in a frost-free place. Do not expose to aggressive media. Protect from direct sunlight. Avoid mechanical vibrations and shocks. -
Page 9: Construction And Function
Brief description The KS is a combined diffuser for use in and behind drywalls and cladding. The diffuser combines a supply and extract air opening in a single system. The visible outlet front runs continuously so that the opening has the appearance of a continuous... -
Page 10: Dimensions/Nominal Lengths
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Dimensions/Nominal lengths Fig. 2: Views of KS (All figures in mm) Dimensions Nominal length 550 Nominal length 750 Nominal length 950 Nominal length 1150 [mm] [mm] [mm] [mm] A (air outlet front) 1150 B (width of junction box) -
Page 11: Installation And Wiring
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Installation and wiring Requirements governing the installation site Only install and assemble the unit if the following conditions are met: Make sure that the wall/ceiling is sufficiently load-bearing to take the weight of the unit (Technical data). Make sure that the ceiling is sufficiently load-bearing to take the weight of the unit (Technical data). -
Page 12: Installing Ks In A Dry Wall
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions 5.2.2 Installing KS in a dry wall Provide the following opening in the dry wall element before installing the KS: Fig. 4: Dimensions of the installation opening [mm] Dimensions Nominal length 550 [mm] Nominal length 750 [mm]... - Page 13 Do not screw the installation brackets into the areas marked with a *! Fig. 7: Installing the air outlet front When installing the KS, pay attention to the correct installation position, which is indicated by a small label stating "top". Screw the air outlet front to the KS.
-
Page 14: Adjusting The Eccentric Rollers
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions 5.2.3 Adjusting the eccentric rollers The air stream can be manually adjusted using the eccentric rollers as shown on the diagram below using a slot-head screw- driver. Reading area Volumetric flow min. max. Air stream directions Fig. 8: Control of the air stream direction 5.2.4 Adjusting the optional volumetric flow limiter... -
Page 15: Pre-Commissioning Checks
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Pre-commissioning checks Before initial commissioning, check whether all the necessary conditions have been met so that the unit can function safely and properly. Structural tests Check that the unit is securely standing and fixed. Check the horizontal installation/suspension of the unit. -
Page 16: Maintenance
Lüftungskomponenten, Kombinationsschlitzdurchlass Assembly, installation and operating instructions Maintenance Clean the inside of the unit The diffusers conform to the Hygiene Directive VDI 6022. They are largely maintenance-free. Check all elements that come into contact with air (internal surfaces of the unit, outlet elements etc.) for dirt or deposits dur- ing maintenance and use a commercially available product to remove. - Page 20 Country Contact Kampmann UK Ltd. Dial House, Govett Avenue Shepperton, Middlesex, TW17 8AG T +44 1932/ 228592 Great Britain F +44 1932/ 228949 E info@kampmann.co.uk W Kampmann.co.uk...
