Relio 4.2.x User Manual – 07/2015
2.3. Front panel
Explanation:
POWER LED:
On
: RELIO has power.
Off
: RELIO does not have power. Note: this does not indicate that the Relio itself is running,
it only indicates presence of the +12 V at the rear panel power connector.
MAINTENANCE MODE LED: indicates maintenance mode has been activated.
MAINTENANCE MODE BUTTON: Activates maintenance mode, which suspends all alarms and automatic
actions by the Relio.
Head Office : Parc d'activites Kennedy - 20, avenue Neil Armstrong – 33700 Bordeaux-Merignac (France)
Tel +33 (0)5 57 928 928 – Fax +33 (0)5 57 928 929 –
POWER LED
Page 10
contact@worldcastsystems.com – www.worldcastsystems.com
MAINTENANCE MODE BUTTON
MAINTENANCE MODE LED
