7708VB-8-HSE
8 SDI/ASI or 6 HD-SDI plus
Ethernet Fiber Transceiver
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571
Copies of this manual can be ordered from your Evertz dealer or from Evertz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7708VB-8-HSE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for evertz 7708VB-8-HSE

Summary of Contents for evertz 7708VB-8-HSE

  • Page 1 7708VB-8-HSE. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 7708VB-8-HSE series products. Due to on going research and development, features and specifications in this manual are subject to change without notice.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface...

  • Page 5: Table Of Contents

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver TABLE OF CONTENTS OVERVIEW........................... 1 GETTING STARTED ........................3 2.1. REAR PLATE DESCRIPTION ..................... 3 2.1.1. Video Connection ..................... 4 2.1.2. SFP Connection ......................4 2.1.3. Ethernet Connection ....................4 2.2.
  • Page 6 7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.2. Controlling the Video Standard Restriction .............. 18 4.4.3. Controlling the Monitoring Output (Video 8) ............. 19 4.4.4. Controlling Video Generation on LOS ..............19 4.4.5. Controlling Video Error-Code Cleaning ..............20 4.4.6.
  • Page 7 7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver Figures Figure 1-1: 7708VB-8-HSE Block Diagram ...................... 2 Figure 2-1: 7708VB-8-HSE Rear Plate ......................3 Figure 2-2: Reproduction of Laser Certification and Identification Label ............5 Figure 4-1: Location of Status Indicators, Jumpers and Controls ..............9 Figure 4-2: Card Edge Menu Structure (Status Section) ................
  • Page 8 7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver This page left intentionally blank Page - iv Revision 0.1...
  • Page 9 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 10 7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver This page left intentionally blank Page - vi Revision 0.1...

  • Page 11: Overview

    Optical output wavelengths of 1310nm, 1550nm, and up to eight CWDM wavelengths (1470nm - 1610nm). • DWDM wavelength (ITU-T G.694.1 compliant) support. • Pluggable Evertz XFP module permits wavelength swapping/sparing. • Comprehensive signal and card status monitoring via four digit card edge display or remotely ® through SNMP and VistaLINK •...

  • Page 12: Figure 1-1: 7708Vb-8-Hse Block Diagram

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver Figure 1-1: 7708VB-8-HSE Block Diagram Page - 2 Revision 0.1...

  • Page 13: Getting Started

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver GETTING STARTED 2.1. REAR PLATE DESCRIPTION Figure 2-1: 7708VB-8-HSE Rear Plate Page - 3 Revision 0.1...

  • Page 14: Video Connection

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 2.1.1. Video Connection HD/SDI IN: Six auto-sensing BNC inputs for HD-SDI, SDI/SDTi, or DVB-ASI. These inputs provide adaptive equalization for up to 100m of industry standard Belden 1694A cable at 1.485Gb/s, or 250m of 1694A cable at 270Mb/s.

  • Page 15: Care And Handling Of Optical Fiber

    2.2.1. Safety CLASS 1 LASER PRODUCT 2.2.2. Assembly Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified Evertz technical personnel. 2.2.3. Labeling Certification and Identification labels are combined into one label. As there is not enough room on the product to place the label, it is reproduced here in the manuals.

  • Page 16: Handling And Connecting Fibers

    Evertz recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. For further information about care and handling of fiber optic cable, see section 3 of the Fiber Optics System Design section of this manual binder.

  • Page 17: Technical Specifications

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver TECHNICAL SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standards: SMPTE ST 292-1, SMPTE ST 259-C, DVB-ASI, SMPTE 305M (SDTi) Number of Inputs: Connector: BNC per IEC 61169-8 Annex A Equalization: Automatic to 70m @2.470Gb/s, 100m @ 1.485Gb/s, and 250m @270Mb/s with Belden 1694A or equivalent Return Loss:...

  • Page 18: Maximum Input Power

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 3.5. MAXIMUM INPUT POWER Max Input Power: Standard: -1dBm High Sensitivity: -7dBm Optical Sensitivity: Standard: -14dBm High Sensitivity: -22dBm 3.6. ELECTRICAL Voltage: +12V DC Power: 3.7. PHYSICAL (NUMBER OF SLOTS)

  • Page 19: Status Indicators And Displays

    8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver STATUS INDICATORS AND DISPLAYS The 7708VB-8-HSE has 8 LED Status indicators and a 4 digit alphanumeric display on the front card edge to show operational status of the card at a glance. The card edge shaft-encoder/pushbutton is used to select various displays on the alphanumeric display.

  • Page 20: Status Indicator Leds

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.1. STATUS INDICATOR LEDS Two large LEDs at the front card-edge display the status of module as follows: MODULE OK: This Green LED indicates good module health. It will be ON while there is no laser, XFP, card-slot or power faults.

  • Page 21: Dot-Matrix Display / Card Status And Controls

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.2. DOT-MATRIX DISPLAY / CARD STATUS AND CONTROLS Additional status monitoring and controls are provided via the 4-digit dot-matrix display located at the card-edge. The card-edge shaft-encoder/pushbutton (see Figure 4-1) is used to navigate through the display menus.

  • Page 22: Display Of Warning Status Indications

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.3.1. Display of Warning Status Indications The top level, default display indicates general card status and critical warnings: Normal operation. Slot Error Warning – A compatible rear-plate is not detected. Flashing indication SLOT…ERR...

  • Page 23: Displaying The Input Video Standard

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver If a specific menu selection has a configuration value associated with it, then this may be changed using the shaft encoder. Pressing the pushbutton will apply the displayed value and return you to the previous menu level.

  • Page 24: Displaying The Output Video Standard

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.3.3. Displaying the Output Video Standard To display the video output standard from the STAT menu, use the shaft encoder/pushbutton to select the VOUT menu item and then choose the desired video channel VO1 to VO8. The following...

  • Page 25: Displaying The Transmit Power

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.3.5. Displaying the Transmit Power Menu selection can display transmit optical power detected by the XFP module in (dBm). To display the transmit power from the STAT menu, use the shaft encoder/pushbutton to select the OPTO menu item and then choose the TXP menu item.

  • Page 26: Displaying The Link Capacity Usage (Fill)

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.3.8. Displaying the Link Capacity Usage (Fill) Menu selection can display the network capacity usage of the Output. To display the network capacity usage from the STAT menu, use the shaft encoder/pushbutton to select the NET menu item, and then choose the FILL menu item.

  • Page 27: Top Level Control Menu Structure

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4. TOP LEVEL CONTROL MENU STRUCTURE Table 4-2 gives a brief description of the top level of the CONTROL menu tree that appears when you enter the Control card edge menu system. Selecting one of these items will take you down into the next menu level to set the value of that parameter.

  • Page 28: Controlling The Led Status Indicators

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.1. Controlling the LED Status Indicators The LED status indicators can be controlled using menu selections. To configure the LED status indicators from the CTRL menu, use the shaft encoder/pushbutton to select the LED menu item. The...

  • Page 29: Controlling The Monitoring Output (Video 8)

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.3. Controlling the Monitoring Output (Video 8) The Video 8 Output can be configured as a monitoring output using menu selections. To configure the monitoring output from the CTRL menu, use the shaft encoder/pushbutton to select the VID menu item and then choose the MON menu item.

  • Page 30: Controlling Video Error-Code Cleaning

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.5. Controlling Video Error-Code Cleaning The video CRC and EDH code cleaning can be controlled using menu selections. To configure the error-code cleaning from the CTRL menu, use the shaft encoder/pushbutton to select the VID menu item and then choose the CLN menu item.

  • Page 31: Controlling The Network Ethernet Fill

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.7. Controlling the Network Ethernet Fill The network Ethernet fill can be controlled using menu selections. Flexible Bandwidth Management (FBM) dynamically assigns free bandwidth up to 1Gbps, and a reserve value may be configured to guarantee a minimum assigned bandwidth.

  • Page 32: Controlling The Orientation Card-Edge Display Text

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 4.4.9. Controlling the Orientation Card-Edge Display Text The text orientation can be controlled using menu selections. To configure the text orientation from the CTRL menu, use the shaft encoder/pushbutton to select the DISP menu item. The following selections...

  • Page 33: Jumpers And Local Controls

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver JUMPERS AND LOCAL CONTROLS Several jumpers, located at the front of the module are used to preset various operating modes. Figure 5-1: Jumpers Location 5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME STATUS The FRAME STATUS jumper determines whether local faults (as shown by the Local Fault indicator) will be connected to the 7700FR frame's global status bus.

  • Page 34: Configuring The Module For Firmware Upgrades

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES UPGRADE: The UPGRADE jumper is used when firmware upgrades are being done to the card. For normal operation, this jumper should be installed in the RUN position.

  • Page 35: Vistalink ® Remote Monitoring/Control

    ® monitor and control Evertz VistaLINK enabled fiber optic products. 2. Managed devices (such as 7708VB-8-HSE), each with a unique address (OID), communicate with ® the NMS through an SNMP Agent. Evertz VistaLINK enabled 7700 series modules reside in the ®...

  • Page 36: General

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.2. GENERAL Figure 6-1: General Tab Control Password: This parameter allows the user to set a new password to protect the 7708VB-8. Pressing this control will open a secondary window as shown in Figure 4-2: New Password Window.
  • Page 37 7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver Video Error Code Correction: This parameter allows the user to enable or disable the video error code correction. Ethernet Bandwidth: This parameter allows the user to select the desried Ethernet bandwidth, options include Auto, 1G, 780M or 220M.

  • Page 38: Input Video Control

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.3. INPUT VIDEO CONTROL Figure 6-3: Input Video Control Tab There are 8 input channels for the 7708VB-8, for each channel the following two parameters can be set by the user.

  • Page 39: Output Video Control

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.4. OUTPUT VIDEO CONTROL Figure 6-4: Output Video Control Tab There are 8 output channels for the 7708VB-8, for each channel the following parameter can be set by the user.

  • Page 40: Input Video Status

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.6. INPUT VIDEO STATUS Figure 6-6: Input Video Status Tab There are 8 input channels for the 7708VB-8, for each channel the following parameter can be viewed by the user.

  • Page 41: Channel 1 And 2 Faults

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.8. CHANNEL 1 AND 2 FAULTS Figure 6-8: Channel 1 and 2 Faults Tab For each channel, 1 and 2, the user can enable the listed traps to be monitored and reported. The user will know there is a fault when the green indicator turns red.

  • Page 42: Channel 3 And 4 Faults

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.9. CHANNEL 3 AND 4 FAULTS Figure 6-9: Channel 3 and 4 Faults Tab For each channel, 3 and 4, the user can enable the listed traps to be monitored and reported. The user will know there is a fault when the green indicator turns red.

  • Page 43: Channel 5 And 6 Faults

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.10. CHANNEL 5 AND 6 FAULTS Figure 6-10: Channel 5 and 6 Faults Tab For each channel, 5 and 6, the user can enable the listed traps to be monitored and reported. The user will know there is a fault when the green indicator turns red.

  • Page 44: Channel 7 And 8 Faults

    7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.11. CHANNEL 7 AND 8 FAULTS Figure 6-11: Channel 7 and 8 Faults Tab For each channel, 7 and 8, the user can enable the listed traps to be monitored and reported. The user will know there is a fault when the green indicator turns red.

  • Page 45: Fault Notification

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver 6.12. FAULT NOTIFICATION Figure 6-12: Fault Notification Tab These traps can be set to monitor the parameters of the 7708VB-8, the user will know there is a fault when the green indicator turns red.
  • Page 46 7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver This page left intentionally blank Page - 36 Revision 0.1...

  • Page 47: Upgrade Procedure

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver UPGRADE PROCEDURE Ensure that the 7708VB-8 is running the latest firmware, to check this simply right click on the cards address in VLPro Client and select Version Information. Figure 7-1: Product Version Drop-down Menu This will open a window that displays all of the current version information loaded onto the 7708VB-8.

  • Page 48: Figure 7-2: Product Firmware Version

    Figure 7-2: Product Firmware Version To upgrade the firmware, locate the latest .jar files which can be found on the Evertz website. Open VLPro Client and navigate to the top tool bar. Locate the Help drop down menu and select Apply Update.

  • Page 49: Figure 7-5: Jar File Directory Location

    7708VB-8-HSESeries User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver When the window opens you want to select the latest .jar file for the 7708VB-8, from its saved location on the computer and select Open. Figure 7-5: Jar File Directory Location At this point the VLPro Server will send a message asking to Restart, select Yes.
  • Page 50 7708VB-8-HSE User Manual 8 SDI/ASI or 6 HD-SDI plus Ethernet Fiber Transceiver This page left intentionally blank Page - 40 Revision 0.1...
