VicFlex
®
Style AB6 Bracket
1.0 PRODUCT DESCRIPTION
Description by Component
Style AB6 Bracket: Optimized for cold storage applications
Dry Sprinkler
Available Models
• Series FL-QR/DRY - please refer to
• Series FL-QR/DRY/SW - please refer to
• Series FL-QR/DRY/C - please refer to
• Series FL-QR/DRY/ST - please refer to
• Series FL-SR/DRY - please refer to
• Series FL-SR/DRY/SW - please refer to
• Series FL-SR/DRY/C - please refer to
• Series FL-SR/DRY/ST - please refer to
Available Styles
• Pendent, Horizontal Sidewall
Available Escutcheons
• Recessed, Sleeve and Skirt, Flush, Concealed
Maximum Working Temperature
• Standard: 150°F/65°C (EPDM/Neoprene foam)
• (Optional) High: 225°F/107°C (Silicone closed-cell foam)
Maximum Working Pressure
• 175 psi/1375 kPa/12 bar
ALWAYS REFER TO ANY NOTIFICATIONS AT THE END OF THIS DOCUMENT REGARDING PRODUCT INSTALLATION, MAINTENANCE OR SUPPORT.
victaulic.com
10.90 2870 Rev M Updated 04/2022
Sprinkler Fittings
™
publication 45.01
publication 45.02
publication 45.03
publication 45.04
publication 45.51
publication 45.52
publication 45.53
publication 45.54
© 2022 Victaulic Company. All rights reserved.
1
10.90
