TCP Keepalive
Monitor Mode Disable
CPU Performance (High)
DHCP Name
HTTP Port
The Ethernet > Channel > Connect tab defines how the unit makes a connection (see the figure and table below).
Setting
Incoming Connection
Response
WX-501-0531 • 01.22
Defines how many seconds the unit waits during an inactive connection before checking its
status. If the unit does not receive a response, it drops that connection. The value can be
between 0 and 60 seconds. 0 disables keepalive. The default setting is 45.
Allows you to disable entry into the monitor mode using the 'yyy' or 'xx1' key sequence at
startup. This field prevents the unit from entering monitor mode by interpreting the stream of
characters that are received during the device server's initialization at startup.
Sets the device to high performance. High performance is 88 MHz, while regular is 48 MHz.
The high performance setting requires more energy.
Lets you enter the name of the host on the network providing the IP address.
Allows the configuration of the web server port number. The valid range is 1–65535. The
default port is 80.
Description
Allows you to configure how the device reacts to incoming connections over the network.
Never rejects all external connection attempts.
Accept DTR accepts external connection requests only when the Modem Control In input is
asserted; this setting cannot be used with Modem mode.
Accept All is the default setting and accepts any incoming connection when a connection is not
already established.
Lets you set character response. When this is set to Character, a single character is transmitted
to the serial port when there is a change in connection state:
C = connected
D = disconnected
N = host unreachable
The IP address of the host connecting to the CoBos device will be provided when you use
verbose mode. This option is overridden when the Active Start Modem Mode or Active Start
Host List is in effect. The default setting is Nothing.
