The following settings are common to both application drivers:
Settings Description
Driver Names the driver you are currently working with.
Serial Number
Displays the serial number of your device.
Firmware Version
Shows the version of firmware your device currently has installed. If Click Supervisor detects a
discrepancy between this version and the most current version it currently has access to, you will be
prompted to upgrade when you connect to the device.
Under the Diagnostics tab, you can run diagnostics on your device (see the figure below). Click the General or
Ethernet buttons to run diagnostics on the items listed below each button. If a problem is detected, the program
will display a red square next to the item in question. If no problems are detected, a green circle will appear.
Once you have finished, use the menu bar at the top of the screen to save your settings, return to the Select
Driver screen, and more.
The Save menu allows you to save your settings. Select Save to File to save your settings to a file. Selecting this
■
will open a directory box, allowing you to name your settings file. This file will always be saved in the Wavetronix
folder created when you installed Click Supervisor, under Wavetronix > ClickHome > Drivers > 301 > User. You
can also select Save to Device to save your settings to your Click 301.
Note. If you do not save your settings to your Click 301, they will be lost the next time you power the device down.
The Tools menu contains five options for working with your device. Reset > System power cycles your device,
■
while Reset > Factory Default restores your device to the settings with which it was shipped. Restore will restore
