wiring. It will not be necessary to wire RS-485 through the screw terminal block if the device is connected to a
T-bus with uninterrupted RS-485 communication.
The front of the Click 301 features a DB-9 connector for RS-232 communication. A straight-through cable can be
used to connect from this port to a computer so that the device can be configured using Click Supervisor. The
front of the device also has an RJ-45 jack for Ethernet communication.
Any data on one port will be transmitted simultaneously on all other ports.

Configuration Features

The faceplate of the Click 301 has three activity indicator LEDs:
PWR (red) lights up when the device has power.
■
TD (yellow) lights up when the device is transmitting data.
■
RD (green) lights up when the device is receiving data.
■
The LEDs are also used to indicate operation modes, which will be discussed in the On-device Configuration
section of this document.
The faceplate also has a push-button labeled Mode Switch, which is used to cycle the Click 301 through operation
modes. This will be discussed in the On-device Configuration section of this document.
On-device Configuration
The Click 301 can be configured using the push-button on the lower part of the faceplate. Press and hold the
push-button to cycle through the different operation modes; release the button when the desired mode is
reached. A quick press and release of the push-button will exit out of any mode and return the unit back to normal
operation. The table below and the following sections describe the different operating modes.
Mode LED
Autobaud Green (solid)
Reset Red (flashing) To reset the Click 301 to factory defaults, press the push-button, then release when the red
Autobaud (green solid)
The Autobaud mode is used to match baud rates with an external device. By default, the device will attempt to
match baud rates with a SmartSensor on the bus; however, the device can be configured to autobaud with any
device that supports a serial interface.
While the device is autobauding, the green LED will be on while the red LED blinks. The autobaud was successful
if the red LED stays on and the green LED turns off. If the autobaud is not successful after a few minutes of trying,
the red and green LEDs will stay on indefinitely. In the case of a failed autobaud, push the push-button once to
return the device to its normal state.
Note. On certain devices, the yellow LED may replace the green LED in the autobaud process—that is, the yellow
LED will come on to select the autobaud process, the yellow LED is on during the autobaud process, etc.
Factory Reset (red flashing)
The Factory Reset operation will erase all user-configured fields, meaning that after the reset, the Click 301
may have to be reconfigured to work properly in its current application. If a device is not responding and
WX-501-0531 • 01.22
Definition
To autobaud the Click 301, press the push-button, then release when the green LED turns on.
LED is blinking.
