1.
OVERVIEW ................................................................................................................................... 1
2.
SPECIFICATIONS ......................................................................................................................... 3
2.1. INPUTS AND OUTPUS......................................................................................................... 3
2.2. ENCAPSULATION PARAMETERS ...................................................................................... 3
2.3. DE-ENCAPSULATION PARAMETERS ................................................................................ 3
2.4. TSM LITE MONITORED PARAMETERS.............................................................................. 3
2.5. PHYSICAL (MAXIMUM NUMBER OF CARDS).................................................................... 3
3.
INSTALLATION ............................................................................................................................. 4
3.1. REAR PLATE DESCRIPTION .............................................................................................. 4
3.1.1. Video Connections ..................................................................................................... 5
3.1.2. Frame Controller Ethernet Connection ....................................................................... 5
3.2. HARDWARE INSTALLATION .............................................................................................. 6
3.3. CONFIGURING THE BASIC NETWORK SETTINGS ........................................................... 8
4.
CARD CONFIGURATION ........................................................................................................... 10
4.1. CONNECTING TO VLPRO ................................................................................................. 10
4.2. MAIN CONTROL TAB ........................................................................................................ 11
4.3. INPUT TO IP CONTROL ..................................................................................................... 13
4.3.1. IP Output Control Tab .............................................................................................. 13
4.3.2. SDI Input Monitor Tab .............................................................................................. 14
4.3.3. Misc. Faults Tab ...................................................................................................... 15
4.3.4. Port Control Panel ................................................................................................... 15
4.3.5. Monitor Tab ............................................................................................................. 16
4.3.6. Input to IP Redundancy ........................................................................................... 17
4.4. IP TO OUTPUT CONTROL ................................................................................................. 17
4.4.1. Redundancy Control Tab ......................................................................................... 17
4.4.2. Port Clarification ...................................................................................................... 18
4.4.3. Port Control Tab ...................................................................................................... 18
4.4.4. Monitor Tab ............................................................................................................. 19
4.4.5. IP to Output Redundancy ......................................................................................... 20
4.5.
DEVICE REDUNDANCY ..................................................................................................... 21
5.
TROUBLESHOOTING ................................................................................................................. 23
5.1. UPDATING VLPRO SERVER JAR FILE ............................................................................ 23
EMX3/EMX6/3000FR/3700 MultiFrame Manual
TABLE OF CONTENTS
Revision 1.0
3080IPG-HD High Density IP Gateway
Page i
Advertisement
Table of Contents
Related Manuals for evertz EMX3
Summary of Contents for evertz EMX3
-
Page 1: Table Of Contents
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway TABLE OF CONTENTS OVERVIEW ........................... 1 SPECIFICATIONS ......................... 3 2.1. INPUTS AND OUTPUS......................3 2.2. ENCAPSULATION PARAMETERS ..................3 2.3. DE-ENCAPSULATION PARAMETERS ................3 2.4. TSM LITE MONITORED PARAMETERS................3 2.5. PHYSICAL (MAXIMUM NUMBER OF CARDS)..............3 INSTALLATION .......................... - Page 2 EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Figures Figure 1-1: 3080IPG-HD Block Diagram ......................2 Figure 3-1: Rear Plate for 3080IPG-HD12-IP10GE ..................4 Figure 3-2: Serial Connection for 3080IPT-HD ....................6 Figure 3-3: 3080IPG-HD TeraTerm Main Menu ....................7 Figure 3-4: Network Configuration for 3080IPG-HD ..................
- Page 3 Apr 2014 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance either express or implied.
- Page 4 EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway This page left intentionally blank Page iv Revision 1.0...
-
Page 5: Overview
The 3080IPG-HD supports several forms of redundancy scenarios in accordance to today’s broadcasters needs. With these features, the 3080IPG-HD can be used in conjunction with any other Evertz equipments like Audio/Video Routers, and Multiplexers in a fully redundant System. The failover features are implemented when a link loss, or a UDP loss occur. -
Page 6: Figure 1-1: 3080Ipg-Hd Block Diagram
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Input 3G/HD/SD Equalizer Monitor Encapsulators Input 1 10GE – SFP+ Cage Decapsulators Input 3G/HD/SD Encapsulators Equalizer Monitor Input 12 10GE – SFP+ Cage Cross Point Decapsulators Switch Output Cable 3G/HD/SD Monitor Driver... -
Page 7: Specifications
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway SPECIFICATIONS 2.1. INPUTS AND OUTPUS • 6xSDI or 12xSDI SD, HD, or 3G input • 6xSDI or 12xSDI SD, HD, or 3G output • Min SDI input bitrate 270Mb/s • Max SDI input bitrate 2.97Gb/s •... -
Page 8: Installation
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway INSTALLATION 3.1. REAR PLATE DESCRIPTION The 3080IPG-HD comes standard with a companion +6RU rear plate. Figure 2-1 provides an illustration of the 3080IPG-HD rear plate. Figure 3-1: Rear Plate for 3080IPG-HD12-IP10GE Page - 4 INSTALLATION Revision 1.0... -
Page 9: Video Connections
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway 3.1.1. Video Connections SDI IN: Each BNC connector input is compatible with SMPTE SDI standards. SDI OUT: Each BNC connector output is compatible with SMPTE SDI standards 3.1.2. Frame Controller Ethernet Connection The IPG Series uses 10Base-T (10 Mbps), 100Base-TX (100 Mbps) or Gigabit (1Gbps) twisted pair Ethernet cabling systems. -
Page 10: Hardware Installation
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway 1000: This Amber LED is ON when a 100Base-TX link is last detected. The LED is OFF when a 10Base-T link is last detected (the LINK LED is ON). Upon power-up the LED is OFF as the last detected rate is not known and therefore defaults to the 10Base-T state until rate detection is completed. -
Page 11: Figure 3-3: 3080Ipg-Hd Teraterm Main Menu
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Before inserting the front card, connect the serial cable to the board using the serial cable provided (See Fig. 3-2 for reference). Now insert the 3080IPG-HD card into the corresponding front slots ensuring the card lines up with the slot runners on the bottom and the top of the chassis. -
Page 12: Configuring The Basic Network Settings
(5) Trace – Engineering Only This menu is for Evertz personnel only. You may be requested to access and execute options within this menu when seeking technical support from Evertz. Guidance will be given should this be required. - Page 13 EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway From the Main Menu, select option (2) SNMP Configuration. Select option (1) Set IP Address and enter the IP address of your VistaLINK PRO Server. Exit using option (S) Save and Exit, now extract the card ®...
-
Page 14: Card Configuration
® Please consult your network administrator if you continue to have problems connecting the card with VistaLINK PRO, alternatively contact Evertz Microsystems Ltd. or your authorized reseller for technical ® support. Right click the IP address or the sub-modules of the 3080IPG-HD to access and configure their parameters. -
Page 15: Main Control Tab
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway 4.2. MAIN CONTROL TAB Right click the IP address and select “View Configuration” to open the configuration dialogue box (see Fig. 4-1) and set Ports 1, 2, 3, and 4’s Data Port IP parameters. -
Page 16: Figure 4-2: Ethernet Monitor Main/Redundant
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway • Error-Free Frames Received/Transmitted: total number error-free frames received/transmitted from the transport stream. • Erroneous Frames Received/Transmitted: The total number of frames with errors received/transmitted from the transport stream. • Broadcast Frames Received/Transmitted:... -
Page 17: Input To Ip Control
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway • Add Trap Destination: Input for the IP address of the SNMP monitoring agent • Current Trap Destination: Displays the currently used IP address’ of the SNMP monitoring agent Figure 4-3: SNMP Trap Destination 4.3. -
Page 18: Sdi Input Monitor Tab
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway o Off – Allows both ports to simultaneously stream the same content with different destination IP addresses (when both ports are enabled) o Manual – Allows the user to select which port will stream the content o Revertive –... -
Page 19: Misc. Faults Tab
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway 4.3.3. Misc. Faults Tab Figure 4-6: Misc. Fault Tab • Input Presence Trap: Selecting this trap enables a notification if the input SDI stream is Lost. This notification will be sent to the IP address defined in the SNMP Trap Destination IP Address (see Fig. -
Page 20: Monitor Tab
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway • Sources UDP Port (0 to 65535): Enter the source UDP port number for the IP address entered above. • Destination IP Address: Enter the Unicast or a Multicast (Destination) IP address. Multicast addresses should be in the range of 224.0.0.0 through 239.255.255.255. -
Page 21: Input To Ip Redundancy
By assigning the stream properties, the user is in full control of which streams are used to implement redundant measures within the system. Ensure the Evertz equipment used throughout the system supports automatic failover switching when using this method. -
Page 22: Port Clarification
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway • IP Rx Force Active Ethernet Port: Sets the Ethernet port that will be used to stream the SDI output Figure 4-10: IP to Output Redundancy Control 4.4.2. Port Clarification For SDI DIN outputs 1-6:... -
Page 23: Monitor Tab
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway • Enable: Enable or Disable the Input stream on the specific port • IP Address: Enter the destination IP address, the multicast address you want to receive. Ensure you enter the correct IP address and it is in the multicast address range of 224.0.0.0 through 239.255.255.255... -
Page 24: Ip To Output Redundancy
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Figure 4-12: IP to Output Monitoring 4.4.5. IP to Output Redundancy The IP input signal is de-encapsulated to an SDI output in a method where one of two possible IP input streams is used for SDI output. The user defines which IP streams will be used for de-encapsulation by entering the Multicast address of the desired streams in the “Port Control”... -
Page 25: Device Redundancy
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway IP de-encapsulators Multicast 1.1 Port 1 10GigE SFP+ SDI Output IP de-encapsulators Multicast 2.1 Port 2 10GigE SFP+ TSM Lite Analyzer Figure 4-13: IP to Output Redundancy Block Diagram 4.5. DEVICE REDUNDANCY Device redundancy is a 1 to 1 backup scenario in which the functionality of a failing device is taken over by a backup device. -
Page 26: Figure 4-14: Unit Redundancy Block Diagram
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Normal Operational Situation 3080IPG-HD6/12- IP10GE Main VistaLINK® PRO Auto-Response/IRM 3080IPG-HD6/12- IP10GE Backup Failover Situation 3080IPG-HD6/12- IP10GE Main FAILED 3080IPG-HD6/12- IP10GE Backup Figure 4-14: Unit Redundancy Block Diagram Page - 22 CARD CONFIGURATION... -
Page 27: Troubleshooting
UPDATING VLPRO SERVER JAR FILE Evertz products are constantly evolving and new features are often added. It is therefore important to update the JAR files in use to provide access to all the latest features or enhancements. It will also be necessary to add JAR files for new products. -
Page 28: Figure 6-2: Vistalink Pro - Applying Jar Updates
EMX3/EMX6/3000FR/3700 MultiFrame Manual 3080IPG-HD High Density IP Gateway Figure 6-2: VistaLINK PRO – Applying JAR Updates ® You will be prompted to restart the server to enable the change to take effect. Apply as many JAR updates as required before restarting the server.
