evertz EQX-IP18-IPG User Manual

Eqx input and ip gateway module
Hide thumbs
Table of Contents

Advertisement

Quick Links

© Copyright 2016
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 1.0, May 2016
The material contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use
of purchasers of the EQX-IP18-IPG product. Evertz Microsystems expressly prohibits the use of this guide for any purpose other than the
operation of the contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the
use of purchasers of the EQX-IP18-IPG product. Due to on going research and development, features and specifications in this manual are
subject to change without notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.
EQX–IP18-IPG
EQX Input and IP Gateway Module
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EQX-IP18-IPG and is the answer not in the manual?

Questions and answers

Related Manuals for evertz EQX-IP18-IPG

Summary of Contents for evertz EQX-IP18-IPG

  • Page 1 Version 1.0, May 2016 The material contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the EQX-IP18-IPG product. Evertz Microsystems expressly prohibits the use of this guide for any purpose other than the operation of the contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the EQX-IP18-IPG product.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...

  • Page 5: Table Of Contents

    EQX–IP18-IPG EQX Input and IP Gateway Module TABLE OF CONTENTS OVERVIEW ........................... 1 VIDEO/IP CONNECTIONS ........................2 AUDIO CONNECTIONS ......................... 2 SPECIFICATIONS ......................... 3 2.1. SERIAL DIGITAL VIDEO INUPUTS ..................3 2.2. ELECTRICAL ........................3 2.3. FRAMES ..........................3 FRAME TYPES ..........................5 INSTALLATION ..........................
  • Page 6 EQX–IP18-IPG EQX Input and IP Gateway Module 7.4. INPUT ROUTE CONTROL ....................24 7.4.1. Route (Grid/ Management) ..................24 7.5. OUTPUT ROUTE CONTROL ..................... 25 7.5.1. Output Route (Grid/Management) ................25 7.6. DIN SDI INPUTS ........................ 26 7.6.1. SDI Input Control ....................26 7.6.2.
  • Page 7 Figure 4-1: Rear Plate Orientation when Installing to the Top half of the Frame ..........7 Figure 4-2: Illustration EQX-IP18-IPG Installed in the Top Slot ............... 8 Figure 4-3: Rear Plate Orientation When installing to the Bottom of the Frame ..........9 Figure 4-4: Illustration EQX-IP18-IPG Installed in the Bottom Slot ..............
  • Page 8 EQX–IP18-IPG EQX Input and IP Gateway Module This page left intentionally blank Page - iv TABLE OF CONTENTS Revision 1.0...
  • Page 9 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 10 EQX–IP18-IPG EQX Input and IP Gateway Module This page left intentionally blank Page - vi Revision 1.0...

  • Page 11: Overview

    EQX-IP18-IPG modules providing square and non-square matrix configurations from as small as 18 inputs through to 576 inputs. The EQX-IP18-IPG hybrid input card provides a gateway to link into IP infrastructures as well as allow a more efficient way to tieline routers together. IP based video packetized and transported over fiber will provide greater density and longer distances than coax based solutions would yield, yet still maintaining the low latency and proper SDI SMPTE switching capabilities in the EQX.

  • Page 12: Video/Ip Connections

    ST 292-1 and SMPTE ST 425-1 Level A input and output signals. AUDIO CONNECTIONS • 2 TDM Outputs: Two Mini DIN connectors for TDM audio (compatible with Evertz TDM v2 only)  Note: EQX-IP18-IPG only supports the RPC based system. All input and output modules including the frame controller must have the RPC based firmware.

  • Page 13: Specifications

    EQX–IP18-IPG EQX Input and IP Gateway Module SPECIFICATIONS 2.1. SERIAL DIGITAL VIDEO INUPUTS Standards : The following video standards are auto detectable 525i/59.94 625i/50 1080p 59.94 1080p 50 1080i 59.94 1080i 50 720p59.94 720p50 1080i60 720p60 1080p 60 Table 2-1: Supported Video Standards Number of SDI inputs: 18 x Mini DIN Number of SFP Ports:...
  • Page 14 EQX–IP18-IPG EQX Input and IP Gateway Module This page left intentionally blank Page - 4 Revision 1.0...

  • Page 15: Frame Types

    EQX–IP18-IPG EQX Input and IP Gateway Module FRAME TYPES A typical EQX platform has the ability to route up to 576x576 signals in a standard 26RU frame, up to 288x288 in a standard 16RU frame and up to 180X180 in a 10 RU frame. EQX platform can be expanded beyond its standard routing capability by adding X-Link expansions to the frame.
  • Page 16 EQX–IP18-IPG EQX Input and IP Gateway Module This page left intentionally blank Page - 6 Revision 1.0...

  • Page 17: Installation

    In the case of installing spare cards and rear plates into the frame, the following steps need to be taken into consideration. Step 1 : Install the EQX-IP18-IPG rear plate to the top half of the EQX frame with screws provided and make sure the orientation of the rear plate is the same as shown in Figure 3-1.

  • Page 18: Figure 4-2: Illustration Eqx-Ip18-Ipg Installed In The Top Slot

    EQX–IP18-IPG EQX Input and IP Gateway Module Step 2: Insert the EQX-IP18-IPG module in to the top half of the EQX frame and make sure the orientation of the card is the same as shown in Figure 3-2. Figure 4-2: Illustration EQX-IP18-IPG Installed in the Top Slot ...

  • Page 19: Installation Of Rear Plate Or Module Into Bottom Half Of An Eqx26 Frame

    INSTALLATION OF REAR PLATE OR MODULE INTO BOTTOM HALF OF AN EQX26 FRAME Step 1: Install the EQX-IP18-IPG rear plate to the EQX frame with screws provided and make sure the orientation of the rear plate is the same as shown in Figure 4-4-3.

  • Page 20: Figure 4-4: Illustration Eqx-Ip18-Ipg Installed In The Bottom Slot

    EQX–IP18-IPG EQX Input and IP Gateway Module Step 2: Insert the EQX-IP18-IPG module in to the bottom of the EQX26 frame and make sure the orientation of the card is the same as shown in Figure 4-4-4. Figure 4-4: Illustration EQX-IP18-IPG Installed in the Bottom Slot Page - 10 Revision 1.0...

  • Page 21: Setting Genlock Reference

    Figure 5-2: Illustration of Dip Switch 5.1. NTSC REFERENCE Step 1 : Make sure the NTSC reference signal is provided to the EQX frame. Step 2 : Set the dip switch at the EQX-IP18-IPG card edge position to the following: Switch Pin State Open...

  • Page 22: Pal Reference

    EQX Input and IP Gateway Module 5.2. PAL REFERENCE Step 1: Make sure the PAL reference signal is provided to the EQX frame Step 2: Set the dip switch at the EQX-IP18-IPG card edge position to the following: Switch State Open...

  • Page 23: Checking Input Status With Leds On The Module

    CHECKING INPUT STATUS WITH LEDS ON THE MODULE The EQX-IP18-IPG module input status LEDs are split up into two columns to indicate valid input detections. Whether the module is inserted in the top or bottom of the frame, the left side indicates SDI detection from the DIN inputs while the right side indicates SDI detection from the Data Port inputs.

  • Page 24: Figure 6-2: Led Indicators When Installed In The Bottom Half Of The Frame

    EQX–IP18-IPG EQX Input and IP Gateway Module DIN Inputs Data Port Inputs Figure 6-2: LED Indicators when Installed in the Bottom half of the Frame Page - 14 Revision 1.0...

  • Page 25: Web Interface Configuration

    EQX–IP18-IPG EQX Input and IP Gateway Module WEB INTERFACE CONFIGURATION EQX-IP18-IPG can be controlled entirely via web-interface. Each tab in the web interface is explained in the following sections. 7.1. LOGIN Make sure IPG is pingable from PC and type the IP address of the card in the address bar of the browser.

  • Page 26: System Tab

    7.2.1. Data Port Configuration This control allows the user to select which data port will be configured. The EQX-IP18-IPG module has six configurable ports, all of which can be assigned to a unique IP Address, Netmask and Gateway.

  • Page 27: Rear Panel

    EQX–IP18-IPG EQX Input and IP Gateway Module • This field displays the number of error free Ethernet frames transmitted. Ethernet Tx Frames Err • This field displays the number of transmitted Ethernet frames containing errors. Ethernet Tx Broadcast Frames • This field displays the number of Broadcast frames transmitted.

  • Page 28: Sfp Monitor

    EQX–IP18-IPG EQX Input and IP Gateway Module • This field displays the type of rear panel installed. Cxp Presence • This field displays whether a correct rear panel type is installed. SFP Detection • This control allows the user to specify the type of cable used with the SFP. Options are Auto, Optical, Copper 3m and Copper 5m Figure 7-4: Rear Panel 7.2.4.

  • Page 29: Genlock Configuration

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.2.5. Genlock Configuration Reference Selection • This field displays the reference selected using the dip switch. Figure 7-6: Genlock Configuration 7.2.6. Genlock Monitoring The following fields display the current overall status of the genlock. Genlock Status •...

  • Page 30: Trap Destination Ip

    This control is used to set the number of transmission packets per frame. This options only applies to the non-SMPTE 2022 standards (Evertz TS and ASPEN). Range is 1-7. Must apply and reboot module in order for the change to take effect.

  • Page 31: Rpc Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.2.11. RPC Control Main and Backup SFP Port • This port is used for inband control and magnum is communicating with the card via this port. In IPG, port 1 is used for main and port 2 is used for backup. Receive IP Address •...

  • Page 32: Card Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.2.12. Card Control Purge Card • This function clears all the settings Purge Status • This field displays whether the is ready to be purg or the purg is in progress. Load Factory config •...

  • Page 33: License

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.3. LICENSE 7.3.1. License Control Product License File • This section is used to download the product license file. To download the license, Choose File and click Upload. Product Serial Number • This field displays the product serial number. Product MAC Address •...

  • Page 34: Input Route Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.4. INPUT ROUTE CONTROL 7.4.1. Route (Grid/ Management) The Input Route Grid/ Management displays the current routes configured on the module. It shows which SFP input is routed to which SDI output (out to crosspoint). These configurations are controlled by MAGNUM.

  • Page 35: Output Route Control

    EQX–IP18-IPG EQX Input and IP Gateway Module Figure 7-14: Web Interface - Input Route Control Tab 2 7.5. OUTPUT ROUTE CONTROL 7.5.1. Output Route (Grid/Management) The Output Route Grid/Management displays the current routes configured on the module. It shows which DIN SDI input is routed to which SFP output. These configurations are managed by MAGNUM. ...

  • Page 36: Din Sdi Inputs

    EQX–IP18-IPG EQX Input and IP Gateway Module To Perform Take • Most of the time the routes are managed by Magnum, in some exceptional cases manual route can be done on the IPG as well. Once the manual route is done on the Grid, the Take button has to be pressed for the change to be applied.

  • Page 37: Sdi Input Monitoring

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.6.2. SDI Input Monitoring SDI Input Present • This field displays whether a valid SDI signal (Present) is applied to that input or not (Lost). SDI Input Video Standard • This field displays the input video standard. SDI Input Signal Type •...

  • Page 38: Ip Output

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.7. IP OUTPUT This section allows the user to configure and monitor the output settings for each SFP data port. Figure 7-17: Web Interface - IP Output Tab 7.7.1. IP Output Control IP Output Status •...

  • Page 39: Ip Output Advanced Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.7.2. IP Output Advanced Control IP Output Type Of Service • This control is used to set the Type of Service number on the IP output from 0-255. IP Output Time To Live •...

  • Page 40: Ip Output Monitoring

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.7.3. IP Output Monitoring IP Output Present • This field displays whether there is valid data on the port by showing Active or Inactive. IP Output Bits Rate (Mbps) • This field displays bits rate on the port from the DIN SDI input selected. Clear Stats •...

  • Page 41: Ip Input Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.8. IP INPUT CONTROL This section will allow the user to monitor or configure the IP input parameters. Figure 7-20: IP Input Control Tab 7.8.1. Global Control Next Timeout • This control is used to set the Next Timeout. A value of 0 means immediate timeout while a value of 255 means timeout never.

  • Page 42: Ip Input Control

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.8.2. IP Input Control IP Input Status • This field displays the status of the SFP port as either Enabled or Disabled. It shows enabled if a valid source is routed to it. IP Input IP Address •...

  • Page 43: Ip Input Monitoring

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.9. IP INPUT MONITORING Figure 7-21: IP Input Monitoring Tab 7.9.1. IP Input Monitoring LAN Mode Level Status • This field displays the current LAN mode level. 7.9.2. IP Input Monitoring IP Input Present •...

  • Page 44: Sdi Output

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.10. SDI OUTPUT This section will display output settings or allow the user to confiture some of the parameters. Figure 7-22: SDI Output Tab 7.11.1. Router Source Core Router Source Selection • This control is used to select what type of input will be used for routing. The options are ‘IP Decap, Baseband Direct and Baseband Synchronized”.

  • Page 45: Router Source

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.11.2. Router Source Apply Router Source 1 Selection Globally • Configurations made on SDI Output 1 will be copied to all of the other 17 SDI Outputs. 7.11.3. SDI Output Global SDI Output if Input Lost •...

  • Page 46: Sdi Output Monitoring

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.11.5. SDI Output Monitoring Figure 7-23: SDI Output Monitoring SDI Output Present • This field is used to display if there is an SDI output signal present and locked. SDI Output Active Ethernet Port •...

  • Page 47: Video Notify

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.12. VIDEO NOTIFY This section will display the health of the input and output of video signals. Figure 7-24: Video Notify Tab 7.12.1. Video Monitoring Control Black Duration • This control is used to set the duration of black frames before it is considered a fault. Picture Noise Level •...

  • Page 48: Figure 7-25: Video Output Notify

    EQX–IP18-IPG EQX Input and IP Gateway Module OutputPicture Black • When set True; if the output video is black a trap message will be sent to the trap addresses configured in the Trap Control section of the System tab. OutputPicture Freeze •...

  • Page 49: Audio Notify

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.13. AUDIO NOTIFY This section will display the health of Input and output Audio signal, Figure 7-26: Web Interface - Audio Notify Tab 7.13.1. Audio Monitoring Control Audio Over Level (-45 to 0 dBFS) •...

  • Page 50: Ip Notify

    EQX–IP18-IPG EQX Input and IP Gateway Module • When set True; a fault condition on a Audio Pair will send out a trap message to the trap addresses configured in the Trap Control section of the System tab. Audio Faults This field will display green when there is no fault on the audio and red for a fault indication.

  • Page 51: Encapsulator Fault

    EQX–IP18-IPG EQX Input and IP Gateway Module • When set True; if the bandwidth limit is exceeded, a trap message will be sent to the trap addresses configured in the Trap Control section of the System tab. Ethernet Fault Present •...

  • Page 52: Notify

    EQX–IP18-IPG EQX Input and IP Gateway Module 7.15. NOTIFY Notify tab allows the user to enable or disable the DIN SDI Input Present traps and Fan Notify traps with monitoring. Figure 7-28: Notify Tab 7.15.1. SDI Input Notify SDI Input 1 to 18 Present •...
  • Page 53 EQX–IP18-IPG EQX Input and IP Gateway Module • When set True; if the CPU temperature exceeds the threshold limit that is set in the System tab, a trap message will be sent to the trap addresses configured in the Trap Control section of the System tab.

  • Page 54: Taskbar Functions

    In some cases Refersh buttons is press in order to see the updated changes in each section. Apply • This function is only available if longed in as root/evertz and only used if any manual change is done Dynamic Apply •...
