© Copyright 2018
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 1.0, June 2018
The material contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use
of purchasers of the 570EMR-AG-HUB product. Evertz Microsystems expressly prohibits the use of this guide for any purpose other than the
operation of the contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the
use of purchasers of the 570EMR-AG-HUB product. Due to on going research and development, features and specifications in this manual are
subject to change without notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.
570EMR-AG-HUB
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 570EMR-AG-HUB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for evertz 570EMR-AG-HUB

Summary of Contents for evertz 570EMR-AG-HUB

  • Page 1 Version 1.0, June 2018 The material contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 570EMR-AG-HUB product. Evertz Microsystems expressly prohibits the use of this guide for any purpose other than the operation of the contained in this reference guide consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 570EMR-AG-HUB product.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...

  • Page 5: Table Of Contents

    570EMR-AG-HUB User Manual TABLE OF CONTENTS OVERVIEW ........................... 1 1.1. FEATURES & BENEFITS ..................... 1 1.2. SYSTEM I/O .......................... 1 SPECIFICATIONS ......................... 3 2.1. AUDIO INPUTS ........................3 2.2. ETHERNET INTERFACE ...................... 3 2.3. ELECTRICAL ........................3 2.4. FRAMES ..........................3 INSTALLATION ..........................
  • Page 6 570EMR-AG-HUB User Manual 5.5.2. SFP Port Output ...................... 16 5.5.3. Express IP Output Control ..................16 5.5.4. IP Output Control ..................... 17 5.5.5. IP Output Advanced Control ..................17 5.6. IP INPUT (S302M) ......................17 5.6.1. Global Control ......................18 5.6.2.
  • Page 7 570EMR-AG-HUB User Manual TABLE OF CONTENTS Page - iii Revision 0.1...
  • Page 8 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 9 570EMR-AG-HUB User Manual This page left intentionally blank TABLE OF CONTENTS Page - v Revision 0.1...

  • Page 11: Overview

    4 Audio channels and must have one dedicated Multicast Address associated with it. Each TDM input must have 128 dedicated multicast addresses of Transport Streams. The 570EMR-AG-HUB rear panel occupies 2 slots in 570 Frame and has 20 x DIN 1.0/2.3 connectors.
  • Page 12 570EMR-AG-HUB User Manual • SFP 5 sends/receives AES67 audio for TDM Inputs 1-5 and TDM Outputs 11-15 • SFP 6 is the IP redundant of SFP 5. • SFP 7 sends/receives AES67 audio for TDM Inputs 6-10 and TDM Outputs 16-20 •...

  • Page 13: Specifications

    570EMR-AG-HUB User Manual SPECIFICATIONS 2.1. AUDIO INPUTS Number of TDM / MADI Inputs 10 x DIN Number of TDM / MADI Outputs 10 x DIN Connector DIN 1.0/2.3 75 Ω terminating Impedance 2.2. ETHERNET INTERFACE Number of SFP Ports 8 x 10GE SFP+ (Rest of them are for future development) 2.3.
  • Page 14 570EMR-AG-HUB User Manual This page left intentionally blank Page - 4 Revision 0.1...

  • Page 15: Installation

    10GE of data per port. Only 8 x 10GE SFP ports are available to be used. 3.1.2. Rear Plate The rear plate of 570EMR-AG-HUB is equipped with 20 DIN connectors. The 1-10 DIN connectors are used for TDM / MADI Inputs and 11-20 DIN connectors are used for TDM / MADI Outputs.

  • Page 16: Rear Plate Mapping

    570EMR-AG-HUB User Manual 3.1.3. Rear Plate Mapping Figure 3-2 : 570EMR Main TDM/MADI Inputs & Outputs Page - 6 Revision 0.1...

  • Page 17: Hardware Installation

    ESD strap to be worn. Locate on the chassis two vacant slots. Unpack the 570EMR-AG-HUB and separate the rear panel from the main card. Locate on the rear of the rack the two slots and remove the blank panels. Insert the rear panel into the back of the chassis and secure using the screws provided.
  • Page 18 570EMR-AG-HUB User Manual This page left intentionally blank Page - 8 Revision 0.1...

  • Page 19: Configuring 570Emr Through Webeasy

    570EMR-AG-HUB User Manual CONFIGURING 570EMR THROUGH WEBEASY ® The 570FC provides a built-in web interface that allows a user to interact with the 570FC as well as WebEASY supported products using a standard Internet web browser. The 570FC web interface can ®...

  • Page 20: System

    570EMR-AG-HUB User Manual 5.1. SYSTEM This tab provides the basic configurations/Monitoring of IP address, InBand Control, Data Port Monitoring and Reference. Figure 5-1 : WebEASY - System ® Page - 10 Revision 0.1...

  • Page 21: Control Port Configuration

    570EMR-AG-HUB User Manual 5.1.1. Control Port Configuration Ethernet: Allows the user to set the IP Address, Netmask and Gateway. This IP Address is used for control and monitor, when 570EMR in standalone frame. Proxy: This IP Address is received from 570FC through proxy. Doesn’t allow the user to change the IP in 570EMR webpage but user can change the IP Address in 570FC Software tab page.

  • Page 22: Sfp Monitor

    This control allows the user to set the timeout for RPC Connection. 5.1.9. Card Control Card Alias: Allows the user to set the name of the 570EMR-AG-HUB. Purge Card: Allows the user to clear all the settings in 570EMR. Load Factory Config: Allows the user to load the factory configuration.

  • Page 23: Product Features

    570EMR-AG-HUB User Manual 5.2. PRODUCT FEATURES This section provides whether the card has license for MADI feature. Figure 5-2 : WebEASY - Product Features ® 5.3. SIGNAL INPUT This section provides the information on TDM / MADI Link, TDM Source Identifier and TDM / MADI audio channel presence and also it detects the pop/clicks in the incoming TDM signal.

  • Page 24: Global Control

    570EMR-AG-HUB User Manual 5.3.1. Global Control Enable Pop Suppression: This section allows the user to enable or disable the Pop suppression globally. Pop suppression is used for reducing the pop/click sound when the audio switch happens in upstream path. 5.3.2. Link Monitoring For each of 10 TDM inputs, the user can view the following parameters.

  • Page 25: Sfp Output

    570EMR-AG-HUB User Manual 5.4.1. SFP Output SFP2 is the backup of SFP1 and SFP4 is the backup of SFP3. Clicking each SFP’s button shows the status, Multicast address and Port# for each Transport Streams. 5.4.2. Express IP Output Control This section allows the user to set the Multicast Address and Port# for each TDM by selecting the individual TDM Ports.

  • Page 26: Ip Output (Aes67)

    570EMR-AG-HUB User Manual 5.5. IP OUTPUT (AES67) Figure 5-5 : WebEASY - IP Output (AES67) ® 5.5.1. AES67 packet Time Packet time is the real-time duration of the media data contained in a media packet. Given the sampling rate and packet time, the number of samples per packet can be calculated. Short packet times allow for lower latency but introduce overhead and high packet rates that may overtax some devices or networks.

  • Page 27: Ip Output Control

    570EMR-AG-HUB User Manual 5.5.4. IP Output Control This section allows the user to see or set the Multicast Address and UDP Port# for the each Transport Stream in each TDM Inputs. Also it displays the status of the IP Output.

  • Page 28: Global Control

    570EMR-AG-HUB User Manual 5.6.1. Global Control SFP redundancy Selection: Allows the user to see whether the traffic for IP to TDM Output path is on SFP1 or SFP2, SFP3 or SFP4. 5.6.2. Express IP Input This section allows the user to set the Multicast Address and Port# for each TDM by selecting the individual TDM Ports.

  • Page 29: Global Control

    570EMR-AG-HUB User Manual 5.7.1. Global Control SFP redundancy Selection: This field allows the user to see whether the traffic for IP to TDM Output path is on SFP1 or SFP2, SFP3 or SFP4. 5.7.2. Express IP Input This section allows the user to set the Multicast Address and Port# for each TDM by selecting the individual TDM Ports.

  • Page 30: Delay Control

    570EMR-AG-HUB User Manual 5.9. DELAY CONTROL Figure 5-9 : WebEASY - Delay Control ® Manual and Auto Mode In AUTO Mode: * "Network Delay", i.e., this control allows the user to set the upper limit on time for audio to reach AG-HUB from upstream source (in this case IPG), usually 1ms enough.

  • Page 31: Pcr Control

    570EMR-AG-HUB User Manual 5.10. PCR CONTROL Figure 5-10 : WebEASY - PCR Control ® 5.10.1. PCR Output Control PCR Output PID: This parameter allows the user to set the time reference PCR PID. PCR Enable: This parameter allows the user to Enable/Disable the PCR generation.

  • Page 32: Ptp Control

    570EMR-AG-HUB User Manual 5.11. PTP CONTROL Figure 5-11 : WebEASY - PTP Control ® PTP is used to distribute time and timebase to every device in the system. Senders mark each packet of video, audio or ANC with an “RTP Timestamp” that indicates the “sampling time” (or equivalent).

  • Page 33: Appendix

    570EMR-AG-HUB User Manual APPENDIX Real-Time Transport Protocol (RTP): The use of RTP is recommended as it provides services such as time stamping, sequence numbering and delivery monitoring which can be beneficial for real-time delivery systems. Time To Live (TTL): TTL is a mechanism that limits the life span of data in a network. Using the Multicast IP protocol, the TTL value indicates the scope or range in which a packet may be forwarded.
  • Page 34 570EMR-AG-HUB User Manual End of Document Page - 24 Revision 0.1...
