- Page 1 WWW.SOLTARO.COM – INFO@SOLTARO.COM – TEL 1300 376 582 Main Office & Showroom – 8 Mohr Street, Tullamarine, VIC 3043 Registered Address – Level 9, 440 Collins Street, Melbourne VIC 3000 – ABN 78 800 728 807...
-
Page 2: Table Of Contents
LED Status Troubleshooting WWW.SOLTARO.COM – INFO@SOLTARO.COM – TEL 1300 376 582 Main Office & Showroom – 8 Mohr Street, Tullamarine, VIC 3043 User manual Registered Address – Level 9, 440 Collins Street, Melbourne VIC 3000 – ABN 78 800 728 807... -
Page 3: Table Of Figures
Figure 1 – Account Login Screenshot Figure 2 - Register Account Screenshot Figure 3 - Qendercore Hub Figure 4 - Qendercore Hub (Side View) Figure 5 - WiFi AP Figure 6 - Network Configuration Figure 7 - Angry IP Scanner for Windows... -
Page 4: Qendercore Account Setup Instructions
Qendercore Account Setup Instructions Before attempting setup, navigate to the Qendercore web portal at https://www.qendercore.com/ and register a Qendercore end user account. These account details will need to be entered to setup monitoring for your Soltaro All in One 2. Click on “Create an Account”. -
Page 5: Figure 2 - Register Account Screenshot
Enter the email address for the end user, then click “Register”. An email will be sent to this email address with instructions on how to complete setup of the account. Figure 2 - Register Account Screenshot User manual... -
Page 6: Qendercore Hub Overview
Qendercore Hub Overview Interactive Button: Used to change Hub State Power LED: Used to indicate Hub On/Off Mode LED: Used to indicate Hub Mode Connectivity LED: Used to indicate Hub Connectivity State Figure 3 - Qendercore Hub User manual... -
Page 7: Installation Of Qendercore Hub
Installation of Qendercore Hub Connect the Qendercore hub to your Soltaro All in One 2 by aligning the round connector with the “EMS” connector on the inverter and pushing it upwards NOT CONNECT WHILE INVERTER IS ENERGIZED). Once connected, tighten the outer lockring until it is firm. -
Page 8: Connecting To Qendercore Hub
Connecting to Qendercore Hub LOCAL ACCESS POINT (AP) Once your Qendercore Hub is plugged in and inverter is powered, the “Power” LED (RED) should light up. Shortly after, the Status lights will start flashing, push the Interactive Button twice (two short presses) to enter Setup Mode. The “Mode” light (Green) should start flashing on and off approximately every 1.5 seconds. -
Page 9: Figure 6 - Network Configuration
Browser, and input the Address: http://qendercore.local/ (Only available for Windows 10 + Above) 192.168.89.89 You will be directed to the page below. From here, you can navigate to Internet Connection Soltaro Inverter Setup Figure 6 - Network Configuration User manual... -
Page 10: Local Network
LOCAL NETWORK Press the Interactive Button twice (Two short presses) to activate Setup Mode on the Qendercore Hub. The “Mode” light (Green) should start flashing on and off approximately every 1.5 seconds. Connect your smart device or computer to the same network as the Qendercore Hub. -
Page 11: Internet Connection
Internet Connection There are various methods of connecting your Qendercore hub to your local network: Local Access Point – WiFi (LOCAL ACCESS POINT (AP)) 2. Wi-Fi Protected Setup (WPS) – WiFi (Only available for Wi-Fi routers with WPS Push Button/ PBC functionality) (WiFi Setup –... -
Page 12: Wifi Setup - Wps
WiFi Setup – WPS Once your Qendercore Hub is plugged in and the Status lights are flashing, push the Interactive Button twice (two short presses) to enter Setup Mode. The “Mode” light (Green) should start flashing on and off approximately every 1.5 seconds. -
Page 13: Ethernet Connection Setup
RJ45 connector using the T-568B connection standard. Once the Status LEDs of the Hub are flashing, connect the RJ45 connector to the Ethernet port of the Qendercore Hub and twist the weatherproof lockring onto the Ethernet port. Tighten the weatherproof gland until it is firm. -
Page 14: Figure 13 - Qendercore Hub
(Yellow) LED will flash faster in accordance with the LED Status section of this document. Once the LED remains on, and blinks off every 3 seconds, communications have been established with the Qendercore servers, and it is ready for linking a Qendercore account (See “Link a Qendercore Account”). -
Page 15: Linking A Qendercore Account
After pressing “Continue”, you will be directed to the page below. Setup Mode will end, and the Qendercore Hub Setup is complete. You will be able to view your connected inverter on your Qendercore Account (Please allow up to 30 minutes for information to populate for the first time). -
Page 16: Soltaro Inverter Setup
(Connecting to Qendercore Hub), click on the button in the top right corner to be taken to the Soltaro Maintenance Index. The button can be used on all pages except the Soltaro Maintenance Index page to reach the Soltaro Maintenance Index. -
Page 17: Soltaro Maintenance Index
SOLTARO MAINTENANCE INDEX Once you have signed in, you will be at the Soltaro Maintenance Index. From here, you can access: ● Inverter Measurements ● Basic Settings ● Advanced Settings ● BMS Registers ● Inverter Operations ● Inverter Faults You can use the button in the top right corner to log out and reset your authentication if required. -
Page 18: Basic Settings
BASIC SETTINGS The Basic Settings page is for inverter settings related to typical installations. Sections with “Write Batch” at the bottom must be updated in batches. Fields with next to them must be updated one by one. Figure 21 - Basic Settings Once you click “Write Batch”... -
Page 19: Advanced Settings
The Advanced Settings page is provided for settings not typically required for most installations, and to provide a verification page for compliance-related settings. Figure 24 - Advanced Settings BMS REGISTERS The BMS Registers page is provided to show values recorded by a connected Soltaro Battery. Figure 25 - BMS Registers User manual... -
Page 20: Inverter Operations
Inverter Clock Synchronization o Inverter Clock can be synchronized to the Browser (Your Device) or Hub (Qendercore Hub) time. Please note, Hub Synchronization is only available if Qendercore Hub has a valid internet connection to validate the correct time via our servers. Both options are intended to update the inverter clock, so it is only necessary to use one option. -
Page 21: Led Status
LED Status Figure 28 - Qendercore Hub LED's User manual... -
Page 22: Troubleshooting
Troubleshooting User manual...
