Kate
Installation Guide
For Model:
KTE52
4007498
net weight of fan: 18.81 lb (8.53 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Fan Assembly. pgs. 5 - 6
Wiring. pg. 6
Warranty. pg. 10
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kate KTE52 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade Kate KTE52

Summary of Contents for Craftmade Kate KTE52

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Kate Installation Guide For Model: KTE52 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, inches (76cm) 7 feet ensure that the hanging location allows the (2.13m) blades a clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or 12ft.

  • Page 6: Canopy Assembly

    7. Canopy Assembly. Locate 2 screws on underside of hanging bracket hanging and remove screw closest to the open end of the bracket hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and push up.

  • Page 7: Light Kit Assembly (Optional)

    9. Light Kit Assembly (Optional). If you wish to use your fan WITHOUT the light kit, remove 3 screws from switch housing cap. motor housing Align holes in switch housing cap with holes in switch housing. (Note: Gap on edge of switch housing cap must align with reverse switch in switch housing for the proper fit.) Secure switch housing cap with 3 screws that were previously...

  • Page 8: Testing Your Fan

    10. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and wall switch (if applicable). Test fan speeds with the pull chain on the switch housing. Start at the OFF position (no blade movement). First pull will set the fan to HI.

  • Page 9: Troubleshooting

    Service at 1-800-486-4892 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Craftmade. We will repair 2. Verify that reverse switch is set completely in or ship you a replacement fan, and we will pay the return either direction.
