Freescale Semiconductor
56800TDC Kit Installation Guide
Thank you for choosing this Freescale Development Tools product, featuring the
CodeWarrior Integrated Development Environment (IDE). This document provides
instructions on how to set up the Freescale 56800/E Telecommunications Daugh-
ter Card (TDC1) with a 56852EVM, 56858EVM, 56F826EVM or 56827EVM. If you
have any questions regarding the hardware kit or software development tools,
please contact the Technical Information Center:
www.freescale.com/support
Kit Contents
Your 56800TDC kit includes:
Hardware
• TDC1 Board
Software
• Metrowerks® CodeWarrior® with Processor Expert
CD-ROM
• Freescale 56800/E Accelerated Development System Resource CD-ROM
Documentation
• 56800TDC Kit Installation Guide (this document)
• Warranty Registration card
1
Install the TDC1 Board on an EVM
1. Remove all power connections from the EVM.
2. Review the EVM's User Manual and disable any peripheral resource which you plan to use on the TDC1 board. For example, if
you are using a 56858EVM board and plan to use the ESSI Port #0 to communicate with the codecs on the TDC1 board, then the
ESSI Port #0 jumpers for the audio codec will need to be removed on the EVM board.
3. Connect the TDC1 to the EVM
• Align connectors P1 and P2 on the bottom of the TDC1 board above the 56852EVM, 56858EVM, 56F826EVM or the
56F827EVM board's connectors (J1 and J2,
respectively). The Keypad, Display and DAA portion of the TDC1 board whould be to the left side of the EVM.
• Press firmly on the TDC1 board above these two
connectors.
2
Configure the 56800TDCEVM Board
The TDC1board is shipped with all jumper blocks in the default configuration,
shown in the table at right.
For more information about jumper settings, refer to the TDC1 Hardware User's
Manual (located on the Resource CD-ROM).
© Freescale Semiconductor, Inc., 2004. All rights reserved.
DSP56800TDCKIG
Rev. 1, 10/2004
Welcome!
TM
Development Tools
System Requirements
•Appropriate EVM board
•
CodeWarrior Development tools with
Processor Expert
Help
To obtain assistance for the 56800TDC,
please contact the Technical Information
Center:
www.freescale.com/support
Jumper Group Connections
JG1 2 - 3, 5 - 6, 8 - 9, 11 - 12, 14 - 15, 17 - 18
JG2
JG3
JG4
JG5
JG6
1 - 2
2 - 3
1 - 2
1 - 2
1 - 2
