Summary of Contents for Vogt VT Series

  • Page 1 VT-Series Ice Maker Model VT40, VT60, VT100 Revision Date: 8/28/13...
  • Page 2 NOTICE This manual is the property of the owner of this particular Vogt Tube-Ice® machine. Model #____________________ Serial #____________________. It is to be left on the premises with this machine at all times. After start-up, it should be stored in a safe place where it can be readily available when needed for future reference in maintaining troubleshooting or servicing.
  • Page 3 If, at any time, you encounter conditions that we have not addressed in this manual, ® we welcome you to write or call Vogt Ice, LLC and we will give your questions our immediate attention and reply. Vogt Ice ® , LLC 1000 W.
  • Page 5 TABLE OF CONTENTS General Information - Section 1 History of Company ..................... 1-1 Receipt of Your Ice Machine ................1-2 Installation Information - Section 2 Important Safety Notice ..................2-1 Machine Dimension ..................... 2-2 Machine Weights & Refrigerant Line Sizes ............2-2 Ice Chute Cutout ....................
  • Page 6 Electrical Controls - Section 5 (Continued) Condensing Unit Electrical Schematic ..........5-11 (Standard) Condensing Unit Control Panel Layout ..........5-12 (Standard) Condensing Unit Electrical Schematic ............5-13 (CE) Condensing Unit Control Panel Layout ............5-14 (CE) Maintenance - Section 6 Preventive Maintenance ..................
  • Page 7 ISTORY OF OMPANY Henry Vogt Machine Co. was founded as a small machine shop in Louisville, Kentucky in 1880. In 1938, Vogt built the first Tube-Ice ® machine and revolutionized the ice-making industry. Our first “sized-ice” machine quickly replaced the old can-ice plants, which required much hard labor and large amounts of floor space for freezing, cutting, and crushing ice by hand.
  • Page 8 (i.e., the trucker’s Bill of Lading). Immediately make a separate written request for inspection by the freight line’s agent. Any repair work or alteration to the machine without the permission of the Vogt Ice can void the machine’s warranty. You should also notify your Vogt distributor or the factory.
  • Page 9 ® Vogt VT Service Manual Installation Instructions Installation Information Important Safety Notice. This information is intended for use by individuals possessing adequate backgrounds of electrical, refrigeration and mechanical experience. Any attempt to repair major equipment may result in personal injury and property damage. The manufacturer or seller cannot be responsible for the interpretation of this information, nor can it assume any liability in connection with its use.
  • Page 10 ® Vogt VT Service Manual Installation Instructions 58" - VT40, VT60 & VT80 71" - VT100 FIGURE 2-1 Ice Machine Dimensions Unit "A" "B" "C" "D" "E" "F" VT40 72 5/8" 27" 24 3/8" 50 3/4" 44" 34" VT60 89"...
  • Page 11 ® Vogt VT Service Manual Installation Instructions Piping Installation: Use ACR refrigeration tubing and nitrogen purge during brazing to prevent formation of copper oxide. For piping runs exceeding 25’, consult a reliable piping manual (Copeland, Heatcraft, or Vilter) for proper pipe sizing. Heat sink all ball valves and remove Schrader valve core prior to brazing. Pressure test piping for leaks.
  • Page 12 ® Vogt VT Service Manual Installation Instructions Makeup water, water tank drain and water tank overflow are ½” FPT connections FIGURE 2-3 VT Lowside Water and Electrical Connections – Rear View Makeup Water Flow VT40 VT60 VT100 Usage - Gallons /100 lbs of Ice Flow rate –...
  • Page 13 Wiring And Electrical Connection. WARNING Only service personnel experienced in refrigeration and qualified to work with high ® voltage electrical equipment should be allowed to install or work on the Vogt Series Ice machine. WARNING Main Power: Power for the entire ice machine will be supplied at the condensing unit.
  • Page 14 ® Vogt VT Service Manual Installation Instructions Air Cooled Condenser Wiring (VT100 with KeepRite Condenser) : Run four #14 AWG wires from the terminals A, B, T4 and T5 on the condensing unit control panel terminal block to the air cooled condenser control panel.
  • Page 15 ® Vogt VT Service Manual Installation Instructions Power is supplied to the lowside through circuit breaker (CB1) located in the condensing unit control panel. See diagram below. CB1 supplies power to lowside unit Condensing unit control panel FIGURE 2-7 Condensing Unit Circuit Breakers (200/230V)
  • Page 16 ® Vogt VT Service Manual Installation Instructions Must solder with 45% silver solder Liquid return from Air Cooled Condenser (7/8” line) Discharge gas to Air Cooled Condenser (1 3/8” line) Teflon Seal 12A2600T01 (for 1 1/4”-12 thread fitting) Female Rota-lock Adapters: 12A2600T03 (for 1 3/4”-12 thread fitting)
  • Page 17 ® Vogt VT Service Manual Installation Instructions Air Cooled Condenser: The air cooled condenser will be wired to the condensing unit control panel. Run two #14 AWG wires and a ground wire from the condensing unit control panel to the Air Cooled condenser control panel.
  • Page 18 ® 2-10 Vogt VT Service Manual Installation Instructions FIGURE 2-11B KeepRite VT100, 200/230V Remote Air Cooled Condenser Wiring Note: Fan cycling switch, FCC2 (Danfoss) for fan motor #2, is not factory set. Switch must be set in the field before startup. Cut Out = 210 psi, Diff = 25 psi.
  • Page 19 ® Vogt VT Service Manual 2-11 Installation Instructions FIGURE 2-11C KeepRite VT100, 400/460V Remote Air Cooled Condenser Wiring Note: Fan cycling switch, FCC2 (Danfoss) for fan motor #2, is not factory set. Switch must be set in the field before startup. Cut Out = 210 psi, Diff = 25 psi.
  • Page 20 ® 2-12 Vogt VT Service Manual Installation Instructions Note: Rota-lock fittings supplied for both lowside Must solder with 45% silver and highside Suction Line Hot Gas Line Liquid Line FIGURE 2-12 VT Lowside Connections Rota-lock Fitting Rota-lock Adapter Teflon Seal (on lowside &...
