Vogt P18AL TUBE-ICE Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

P18AL
®
TUBE-ICE
MACHINE
Manual Part Number 12A4171M09
Service Manual
$50
00
8/28/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P18AL TUBE-ICE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vogt P18AL TUBE-ICE

Summary of Contents for Vogt P18AL TUBE-ICE

  • Page 1 P18AL ® TUBE-ICE MACHINE Manual Part Number 12A4171M09 Service Manual 8/28/00...
  • Page 2 NOTICE This manual is the property of the owner of this particular Tube-Ice® machine. Model #____________________ Serial #____________________. It is to be left on the premises with this machine at all times. After start- up, it should be stored in a safe place where it can be readily available when needed for future reference in maintaining troubleshooting or servicing.
  • Page 3 (Medium & Large Machines) Model Number: __________________________ Serial Number: __________________________ This form must be filled out completely and signed by the customer in order to assure acceptance by Vogt. Date of Start-Up: _______________________________ Form Completed By: _____________________________________ AC Condenser Model Number: _____________________...
  • Page 5 ® TUBE ICE , LLC, located in Louisville, Kentucky since 1880. Sales - (800) 853-8648 Parts and Service - (502) 635-3000 Since 1880, Manufacturers of Quality Tube-Ice ® Machines 3/6/07...
  • Page 6 ® Vogt ® Tube-Ice Machines Installation, Service Manual and Parts Catalog #12A4171M09 P18 Ammonia Lowside Model...

  • Page 7: Table Of Contents

    MACHINES Model P18AL Page No. 1. INTRODUCTION A Brief History Of Our Company ..........................1-1 Vogt Energy-Savings Tube-Ice® Machines ........................1-1 Preview ..................................1-1 Important Safety Notice..............................1-2 Special Precautions To Be Observed When Charging Refrigeration Systems ..............1-2 Safety Symbols and What They Mean ..........................1-3 Assembly Drawing Model P18AL, FIGURES 1-1, 1-2, 1-3 &...
  • Page 8 P18AL Service Manual TABLE OF CONTENTS Startup Checklist................................3-11 4. HOW YOUR TUBE-ICE MACHINE WORKS Principle of Operation..............................4-1 Freeze Period .................................4-2 Harvest Period ................................4-2 Piping Nomenclature, Table 4-1............................4-2 Water Cooled Piping Schematic, FIGURE 4-1......................4-3 Air-Cooled Piping Schematic, FIGURE 4-2........................4-4 5. START-UP AND OPERATION Refrigeration System Review ............................5-1 Refrigerant Charge ................................5-2 Ammonia Specification By Grade, Table 5-1........................5-2...
  • Page 9 P18AL Service Manual TABLE OF CONTENTS Optional Maintenance Operations ..........................7-5 Water Cooled Condenser Cleaning..........................7-5 Cooling Tower/Evaporative Condenser........................7-6 Compressor................................7-7 8. TROUBLESHOOTING List Of Symptoms................................8-1 Machine Stopped ................................8-2 & 8-3 Freeze-Up Due To Ice Failing To Discharge.........................8-3 Low Ice Capacity................................8-4 Poor Ice Quality................................8-5 High Discharge Pressure (Check Gage Accuracy) ......................8-5 Low Discharge Pressure (Check Gage Accuracy) ......................8-5 High Suction Pressure (Check Gage Accuracy) ......................8-6...
  • Page 10 P18AL Service Manual TABLE OF CONTENTS Removing Excess Water From Ammonia ........................9-7 Water Removal Procedure.............................9-7 Cutter Motor Removal/Replacement ..........................9-9 Cutter Gear Reducer Removal/Replacement .........................9-9 Water Tank Removal..............................9-9 Cutter and Bearing Removal/Installation........................9-10 Cutter/Water Tank Parts List, TABLE 9-1 ........................9-11 Cutter/Water Tank Assembly, FIGURE 9-3........................9-12 Cutter/Tank Parts, FIGURE 9-4 ............................9-13 Crushed Ice Production..............................9-13 10.

  • Page 11: Introduction

    1. Introduction ® TUBE ICE , LLC A Brief History Of Our Company Henry Vogt Machine Co. was founded as a small machine shop in Louisville, Kentucky in 1880. In 1938, Vogt built the first Tube-Ice ® machine and revolutionized the ice-making industry.

  • Page 12: Important Safety Notice

    P18AL Service Manual INTRODUCTION Important Safety Notice. This information is intended for use by individuals possessing adequate backgrounds of electrical, refrigeration and mechanical experience. Any attempt to repair major equipment may result in personal injury and property damage. The manufacturer or seller cannot be responsible for the interpretation of this information, nor can it assume any liability in connection with its use.
  • Page 13 P18AL Service Manual INTRODUCTION Safety Symbols & What They Mean. Prior to installation or operation of the Tube-Ice ® machine, please read this manual. Are you familiar with the installation, start-up, and operation of a Tube- ® machine? Before you operate, adjust or service this machine, you should read this manual, understand the operation of this machine, and be aware of possible dangers.
  • Page 14 P18AL Service Manual INTRODUCTION FIGURE 1-1 P18AL Front View 3/6/07...
  • Page 15 P18AL Service Manual INTRODUCTION FIGURE 1-2 P18AL Back View 3/6/07...
  • Page 16 P18AL Service Manual INTRODUCTION FIGURE 1-3 P18AL Left View 3/6/07...
  • Page 17 P18AL Service Manual INTRODUCTION FIGURE 1-4 P18AL Right View 3/6/07...
  • Page 18 P18AL Service Manual INTRODUCTION 3/6/07...

  • Page 19: Receipt Of Your Tube-Ice Machine

    Any repair work or alteration to the machine without the permission of the Tube-Ice, LLC can void the machine’s warranty. You should also notify your Vogt distributor or the factory. ®...

  • Page 20: Safety Valves

    "NC" - No Condenser "21" - 230-1-60 Product Variation Codes (An alphanumeric designator assigned to specific variations.) "000 or Blank" – Standard Product If unsure of the product code shown on your machine please consult the factory. Figure 2-1 Vogt Model Nomenclature 3/6/07...

  • Page 21: Installing Your Tube-Ice Machine

    Important Notice. The Warranty Registration / Start-Up Form must be completed and returned to ® Vogt Tube-Ice to initiate and assure a full warranty. A postage paid envelope is provided or you may fax the report to 800-770-8648. Machine Room The machine must be located inside a suitable building and must not be subjected to ambient temperatures below 50°F (10°C) or above 110°F (43.3°C).

  • Page 22: Foundation Layout

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE Foundation Layout CAUTION The approximate machine operating weight is 3,000 pounds. CAUTION The machine foundation should be constructed from concrete or similar material in accordance with all local and federal OSHA codes and building regulations. The minimum required foundation size is shown in Figure 3-1.

  • Page 23: Water Tank Overflow

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE Make-Up Water In. The water required for ice making must be potable water, safe for human consumption, and should be of the highest quality available. The best way to determine water quality is to have a complete water quality analysis by a qualified laboratory. It is advisable to install a particle filter in the make-up and flushing water lines to trap dirt, sand, rust, or other solid particles prior to entering the water tank and contaminating the ice.

  • Page 24: Suction Pressure Regulator

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE Suction Pressure Regulator When a P18AL is attached to a central system a pressure regulator will be required (see Figures 3-3 for location). This regulator (usually furnished by the purchaser) must be a combination back pressure regulating and stop type valve. The usual minimum pressure drop across this type valve is 2 psig, therefore the valve must be set to maintain a freezer pressure at least 2 psi above the maximum general suction pressure.

  • Page 25: Spacing And Connection Diagram, Figure 3-1

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE FIGURE 3-1 Spacing and Connection Diagram 3/6/07...

  • Page 26: Piping Schematic (Dedicated High Side), Figure 3-2

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE FIGURE 3-2 Piping Schematic (Dedicated High Side) 3/6/07...

  • Page 27: Piping Schematic (Central High Side), Figure 3-3

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE FIGURE 3-3 Piping Schematic (Central High Side) 3/6/07...

  • Page 28: Wiring And Electrical Connection, Figure 3-4

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE Wiring and Electrical Connection WARNING Only service personnel experienced in refrigeration and qualified to work with high voltage ® electrical equipment should be allowed to install or work on the Tube-Ice machine. WARNING Refer to TABLE 3-2 to properly size wiring connections.

  • Page 29: Electrical Specifications, Table 3-2

    P18AL Service Manual ® INSTALLING YOUR TUBE-ICE MACHINE FIGURE 3-5 Control Panel Field Connections (Detail) Standard F.L.A. Minimum Maximum Voltages Ampacity Fuse 208/230, 3ph, 60 Hz 460, 3ph, 60 Hz 220, 3ph, 50 Hz 400, 3ph, 50 Hz TABLE 3-2 Electrical Specifications Note: Refer to Chapter 6 for a wiring schematic and electrical component layout and description.

  • Page 30: Phase Check

    P18AL Service Manual 3-10 ® INSTALLING YOUR TUBE-ICE MACHINE Phase Check CAUTION DO NOT attempt to start machine without priming pump and insuring proper rotation of both cutter and pump. CAUTION Cutter and pump motor rotation are factory synchronized but must be checked at installation. For ice production, the cutter disc, as viewed at the ice discharge opening should turn from left to right (crushed rotation should be from right to left).

  • Page 31: Startup Checklist

    P18AL Service Manual 3-11 ® INSTALLING YOUR TUBE-ICE MACHINE Startup Checklist IMPORTANT Be sure to follow the wiring schematic when incorporating overloads. This is necessary to provide proper ® protection for the Tube-Ice machine and its component parts. IMPORTANT Installation Review: A Checklist. Make a visual check to be sure these steps have been taken BEFORE continuing.

  • Page 32: How Your Tube-Ice Machine Works

    P18AL Service Manual HOW YOUR TUBE-ICE MACHINE WORKS ® 4. How Your Tube-Ice Machine Works Principle Of Operation For a detailed description of the functions of each control panel component, see Section 6. Operation of the machine is controlled by “Clean/Off/Ice”, “Start” and “Stop” switches located in the control panel of the freezing unit.

  • Page 33: Freeze Period

    P18AL Service Manual HOW YOUR TUBE-ICE MACHINE WORKS The freezing period is completed by action of the freeze timer in the control panel (or an optional freezer pressure switch). The water pump (5) is stopped and solenoid valve “A” (25) is closed. The thawing period then begins.
  • Page 34 P18AL Service Manual HOW YOUR TUBE-ICE MACHINE WORKS FIGURE 4-1 P18AL Piping Schematic (Dedicated High-Side) 3/6/2007...
  • Page 35 P18AL Service Manual HOW YOUR TUBE-ICE MACHINE WORKS FIGURE 4-2 P18AL Piping Schematic (Central System) 3/6/2007...

  • Page 36: Start-Up And Operation

    P18AL Service Manual START-UP AND OPERATION 5. Start-Up and Operation Refrigeration System Review The refrigeration system uses anhydrous ammonia (R-717) refrigerant. Following the piping schematic (Figure 3-2 or 3-3), you will see that during the machine’s freeze cycle, the compressor discharge gas goes through the oil separator to remove any oil present in the discharge gas and return the oil to the compressor crankcase.

  • Page 37: Refrigerant Charge

    P18AL Service Manual STAR-UP AND OPERATION Refrigerant Charge Prior to charging the machine with anhydrous ammonia (R-717) make sure the system is leak tight and free of non-condensables or other contaminants. The machine will require a full charge of pure anhydrous ammonia. Make sure it is from a reputable supplier who can and will furnish quality ammonia of Refrigeration or Federal Technical grade.

  • Page 38: Charging From Cylinders (Dedicated High Side Only)

    P18AL Service Manual START-UP AND OPERATION Charging From Cylinders (dedicated high side only). The machine may also be charged from refrigerant cylinders. To charge from cylinders, the compressor will have to operate to transfer the ammonia from the freezer to the receiver. Again, make sure all the necessary valves are opened for operation and the compressor crankcase heater has been energized for a minimum of four (4) hours.
  • Page 39 P18AL Service Manual STAR-UP AND OPERATION Transferring refrigerant from a refrigeration system into a cylinder can be very dangerous and is not recommended. As the machine is being charged, continually observe the following operating characteristics: a) Discharge pressure - 175 psi to 200 psi maximum b) Compressor oil pressure - Mycom W-Series,18-27 psi, Vilter 450-Series, 35-50 psi.
  • Page 40 P18AL Service Manual START-UP AND OPERATION Start-up CAUTION The crankcase heater should be energized for a MINIMUM of 4 hours and the crankcase must be free of liquid before attempting to operate the compressor. CAUTION FIGURE 5-1 Bottom Of Control Panel Starting the machine in freeze mode: (NOTE: machine will always start in the harvest mode when the “Clean/Off/Ice”...

  • Page 41: Shut-Down Procedure

    P18AL Service Manual STAR-UP AND OPERATION Thaw Gas Regulating and Suction Regulating Valve Adjustment. The following is the procedure for regulating valve adjustment. On dedicated compressor systems the suction regulating valve is not required. However the compressor must unload by 50% or greater during the harvest or a hot gas bypass must be installed.

  • Page 42: Operating Tips

    P18AL Service Manual START-UP AND OPERATION Operating Tips • If the operation of your machine is not controlled by a timer, bin level control or some other mechanism to automatically start and stop ice production, you should use ONLY the “Clean/Off/Ice”...
  • Page 43 P18AL Service Manual ELECTRICAL CONTROLS 6. Electrical Controls ® Your packaged Tube-Ice machine is equipped with cutter and pump motor starters (CU and P) and a transformer (if required) for the control circuit power. The control panel and transformer are mounted on the machine front side (see Figure 1-1).

  • Page 44: Control Panel (Door Closed), Figure 6-1

    P18AL Service Manual ELECTRICAL CONTROLS FIGURE 6-1 Control Panel (Door Closed) Symbol Vogt Part# Component Description 12A7500E57 Push Button, Momentary, Red 12A7500E56 Push Button, Momentary, Green 12A7500E61 Selector Switch, 3 Position 12A7503E52 Timer, Digital, Multi-function, 24-240V AC TABLE 6-1 Control Panel Components and Part Numbers (External)

  • Page 45: Control Panel (Door Opened), Figure 6-2

    P18AL Service Manual ELECTRICAL CONTROLS FIGURE 6-2 Control Panel (Door Opened) Symbol Vogt Part# Component Description 12A7517E28 Relay, 10A, 3 NO/1NC, 208/240V Coil 12A7515E21 Circuit Breaker, 3A, 2 Pole 12A7530E54 Cutter Manual Motor Starter, 1.6-2.5A (200/208/230V Only) 12A7530E52 Cutter Manual Motor Starter, 0.63-1.0A (460V Only) 12A7530E53 Cutter Manual Motor Starter, 1.0-1.6A (400V Only)

  • Page 46: Description Of Control Panel Component Function, Table 6-3

    P18AL Service Manual ELECTRICAL CONTROLS Symbol Component Description Relay for making and breaking various circuits during freezing and thawing. Energized during the thaw period. Relay for making and breaking various circuits during freezing and thawing. Energized during all operational modes. Relay stops the machine when there is a power failure or interruption and must be manually re-energized by hitting the start button.

  • Page 47: Electrical Schematic All Voltages 50-60 Hz, Figure 6-3

    P18AL Service Manual ELECTRICAL CONTROLS FIGURE 6-3 Electrical Schematic, All Voltages, 50-60 Hz. 3/6/07...
  • Page 48 P18AL Service Manual ELECTRICAL CONTROLS 3/6/07...

  • Page 49: Maintenance

    P18AL Service Manual MAINTENANCE 7. Maintenance ® Preventive Maintenance A careful inspection of the Tube-Ice machines refrigeration system for leaks and correct operational functions at time of installation will start its long satisfactory life of service. In order to insure this degree of dependability, a systematic maintenance program is recommended.

  • Page 50: Ice-Making Section

    P18AL Service Manual MAINTENANCE PREVENTATIVE MAINTENANCE FORM This form can be removed and duplicated for record keeping. Date: ______________ Model #: ________________________ Serial #: ___________________ The following service performed and checked: Hour meter reading _______________ , Ambient temperature (inside)_______ °F Make-Up water float valve adjusted properly Water distributors clean and in place All drains freely draining...

  • Page 51: Cleaning Procedure

    P18AL Service Manual MAINTENANCE grade ice machine cleaner. The water pump is used to circulate the cleaner through the system by setting the “Clean/Off/Ice” selector switch to “Clean" to start the water pump and to “Off” to stop the water pump. For complete instructions, refer to the “Cleaning Procedure” attached to the equipment and duplicated here.

  • Page 52: Water Distribution System

    P18AL Service Manual MAINTENANCE Water Distribution System Water Distributors. The water distributors are located under the freezer cover at the top of the freezer. These distributors may require occasional or periodic cleaning to remove solids and foreign particles accumulated from the make-up water. The frequency of this cleaning operation will depend on the characteristics of the water supply.

  • Page 53: Other Maintenance Operations

    P18AL Service Manual MAINTENANCE Other Maintenance Operations Cutter Gear Reducer. The oil level of the gear reducer should be checked monthly or when there is any evidence of leakage. The correct level is indicated by the pipe plug in the side of the gear housing.
  • Page 54 P18AL Service Manual MAINTENANCE 1. Bleed off valve. The bleed off valve should be checked monthly to assure that is not blocked and that water is flowing as required. If the unit is controlled by a water treatment system, the bleed off valve may not be required.

  • Page 55: Compressor

    P18AL Service Manual MAINTENANCE Compressor (optional). This section is only a guide; consult the compressor manual for manufacturers recommended maintenance. In starting and charging the unit, the oil sight glass should be continually checked to make sure an adequate oil level is maintained. The oil level should be 1/4-3/4 of the sight glass. If the oil level drops below 1/4 of the glass, add refrigeration oil as per the compressor manufacturer recommendations.
  • Page 56 P18AL Service Manual MAINTENANCE 3/6/07...

  • Page 57: Troubleshooting

    P18AL Service Manual TROUBLESHOOTING 8.Troubleshooting Your machine’s electrical system has several built-in safety and overload protection features Note: to stop operation when a single component fails or there is a problem from an outside source such a power supply. Make sure all auxiliary equipment is connected to incorporate safety and overload circuits and protect all related equipment.
  • Page 58 P18AL Service Manual TROUBLESHOOTING Symptom: Machine Stopped Possible Cause Possible Remedy Power failure or interruption Check fused disconnect or circuit breaker supplying power to the machine. If power has been off, make sure the crankcase heater is energized and there is no liquid refrigerant in the compressor crankcase prior to restarting the compressor.
  • Page 59 P18AL Service Manual TROUBLESHOOTING Symptom: Freeze-up due to extended freeze period Possible Cause Possible Remedy Freeze timer (T2) set to long Adjust timer or replace if defective. See FIGURE 9-2. Freezer pressure switch (FPS) set too low or defective Adjust switch or replace if defective. (optional) Water tank drain valve, make-up water float valve or flushing Close, repair, or replace valve as needed.
  • Page 60 P18AL Service Manual TROUBLESHOOTING Symptom: Low ice capacity. Suspicions of low ice capacity should be confirmed by accurate calculations of actual ice product. Significant losses can occur due to melting and off fall through augers and other ice handling equipment. Time the total cycle (freeze time + thaw time).
  • Page 61 P18AL Service Manual TROUBLESHOOTING Symptom: Poor ice quality Possible Cause Possible Remedy Excessive concentration of solids in the water tank usually Perform a cleaning procedure as well as removing the freezer indicated by a build-up of mineral deposit on the sides and cover and cleaning the water distributors.
  • Page 62 P18AL Service Manual TROUBLESHOOTING Symptom: High suction pressure (check gage accuracy) Possible Cause Possible Remedy Compressor running unloaded or not pumping efficiently Check compressor motor amp. If the compressor is running unloaded, the amperage will only be approximately 60% of normal amp draw.
  • Page 63 P18AL Service Manual TROUBLESHOOTING Symptom: Machine short cycles (using freeze pressure switch (FPS) only) Possible Cause Possible Remedy Freezer pressure switch (FPS) set too low or defective Adjust switch or replace if defective. Freeze-up See “Freeze-up due to extended freezer period” and “Freeze- up due to ice failing to discharge”.
  • Page 64 P18AL Service Manual TROUBLESHOOTING 3/6/07...

  • Page 65: Freeze Timer (T2)

    P18AL Service Manual SERVICE OPERATIONS 9. Service Operations Thawing Timer (T). The thawing timer governs the ice thawing period. It is located inside the control panel (FIGURE 6-1). It is started by action of the freeze timer (T2), which energizes the “1CR”...

  • Page 66: Conveyor Timer (T3)

    P18AL Service Manual SERVICE OPERATIONS The freezing time can be such that a small percentage of the ice is frozen solid. If so, some ice from the top and bottom of the freezer should have a small hole in the center to insure that the freezing time has not been extended to where a loss in capacity would result.

  • Page 67: Make-Up Water Float Valve (37A)

    P18AL Service Manual SERVICE OPERATIONS Make-up Water Float Valve (37A). The make-up float valve maintains the proper level in the water tank for ice making. The valve should be set to maintain a water level in the water tank during the freezing period so that there will be a quantity of blowdown only during the thaw mode.

  • Page 68: Pumpdown

    P18AL Service Manual SERVICE OPERATIONS housing to prevent cavitation or loss of prime. The pump is equipped with a mechanical seal which is self-adjusting and requires no lubrication. However, the pump should not be operated unless circulating water. The pump manufacturer recommends that a mechanical seal be kept as a spare. When ordering a seal, specify pump size, type, serial number, and manufacturer’s name as indicated on the nameplate.

  • Page 69: Removal Of Ammonia Refrigerant

    P18AL Service Manual SERVICE OPERATIONS Removal of Ammonia Refrigerant from the Machine. Liquid ammonia can be removed from the machine through the receiver drain valve. Refer to Sections 1, 2 and Appendix A for special warnings and instructions regarding the handling of ammonia. Make sure you are familiar with and technically qualified to handle anhydrous-ammonia refrigerant.

  • Page 70: Non-Condensable Gases

    P18AL Service Manual SERVICE OPERATIONS Non-condensable Gases. Satisfactory operation of the machine is not possible if non-condensable gases (usually air) are present in the system. Excessive condensing pressure is an indication of such gases. Excessive condensing pressure in water cooled condensers may also be due to the accumulation of scale in the cooling coil or due to insufficient cooling water or excessive water temperature.

  • Page 71: Draining The Oil Trap

    P18AL Service Manual SERVICE OPERATIONS Draining the Oil Trap. After many hours of operation, the oil which escapes the oil separator will pass through the receiver and to the freezer where it will settle in the oil trap (22). Indication of oil in the trap will be evident by the frost line.
  • Page 72 P18AL Service Manual SERVICE OPERATIONS 6. Close the compressor discharge stop valve and the oil return valve. Make sure the power is disconnected and locked-out. 7. Drain the compressor oil, remove the compressor side cover and clean the inside of all oil and foreign matter, and reinstall the side cover.

  • Page 73: Cutter Motor Removal/Replacement

    P18AL Service Manual SERVICE OPERATIONS Cutter Motor Removal/Replacement. The cutter motor’s bearings are prelubricated and sealed and require no further lubrication. If the motor needs replacing, proceed as follows: 1. Turn power off and lock out disconnect. 2. Check terminals with volt meter to confirm power is off. 3.

  • Page 74: Cutter And Bearing Removal/Installation

    P18AL Service Manual 9-10 SERVICE OPERATIONS Cutter And Bearing Removal/Installation. Refer to FIGURES 9-3 & 9-4 for parts identification and location. 1. Turn off and lock out power to the machine. 2. Remove the cutter motor from the reducer. 3. Remove the water tank assembly and then the cutter assembly. 4.

  • Page 75: Cutter/Water Tank Parts List, Table 9-1

    P18AL Service Manual 9-11 SERVICE OPERATIONS ITEM NO. QTY. PART NO. DESCRIPTION 12A2160H0101 HUB, CUTTER DRIVE GEAR 12A2215F1107 CAP SCREW, 1/4"-20 UNC X 5/8" SS HEX HEAD 12A2215F1112 CAP SCREW, 1/4"-20 UNC X 1 1/4" SS HEX HEAD 12A2215G111 SCREW, 5/16-18 UNC X 1" SS HEX HEAD CAP 12A2215H111 SCREW, 3/8"-16 UNC X 1"...

  • Page 76: Cutter/Water Tank Assembly, Figure 9-3

    P18AL Service Manual 9-12 SERVICE OPERATIONS FIGURE 9-3 Cutter/Water Tank Assembly 3/6/07...

  • Page 77: Cutter/Tank Parts, Figure 9-4

    SERVICE OPERATIONS FIGURE 9-4 Cutter/Tank Parts ® Crushed Ice Production. Your P18AL Tube-Ice machine is capable of producing crushed ice with no loss of capacity. However, there are certain changes to be made in order to convert to crushed ice production: Add: 1.

  • Page 78: Tables And Charts

    P18AL Service Manual 10-1 TABLES & CHARTS 10. Tables & Charts 3/6/07...
  • Page 79 (70.7) (51.3) Vogt reserves the right to change designs and specifications without notice. (1) Refrigerant charge is for low side unit only. Additional refrigerant required for high side and piping. (2) Compressor requirement is based on 70°F makeup water, 14°F suction temperature, 100°F condensing temperature, 70°F ambient, and 25 gal/cycle blowdown. Compressor rpm’s vary.
  • Page 80 P18AL Service Manual 10-3 TABLES & CHARTS P18AL Capacity Ratings (7/8” Diameter Ice) Suction Pressure (psig) 21.4 20.0 16.6 15.0 11.3 10.0 Suction Temp. ( 14.7 16.2 19.6 21.1 24.3 25.4 28.9 29.2 32.7 *Avg. Ref. Required (tons) 17.3 19.4 24.5 26.9 32.4...
  • Page 81 P18AL Service Manual 10-4 TABLES & CHARTS P18AL Capacity Ratings (1 3/8” Diameter Ice) Suction Pressure (psig) 21.4 20.0 16.6 15.0 11.3 10.0 Suction Temp. ( 10.0 10.9 12.9 13.5 15.7 16.0 18.3 *Avg. Ref. Required (tons) 11.2 12.2 14.8 15.6 18.7 19.0...

  • Page 82: Recommended Spare Parts List

    10.1 1 1/2" 16.2 15.3 14.5 13.7 12.7 Table 10-6 Usual Operating Conditions RECOMMENDED SPARE PARTS LIST ® Vogt Model P18AL Tube-Ice Machine QTY PART NUMBER DESCRIPTION 12A-7503E52 Freeze Timer 12A-7503E22 Thawing Timer 12A-7517E28 CR Relay, 208/230V, 50/60 Hz. 12A-7516E23 Starter Contactor, 208/230V, 50/60 Hz.
  • Page 83 P18AL Service Manual 10-6 TABLES & CHARTS TEMPERATURE - PRESSURE CHART FOR COMMON REFRIGERANTS DegF R-12 R-22 R-502 R-134a R-404A R-717 MP-39 DegF R-12 R-22 R-502 R-134a R-404A R-717 MP-39 -7.6 -3.0 -9.0 -7.0 -9.1 46.7 84.0 97.4 45.5 102.9 74.2 45.3 -7.2...

  • Page 84: Conversion Factors: English To Metric, Table 10-8

    P18AL Service Manual 10-7 TABLES & CHARTS REFERENCE INFORMATION CONVERSION FACTORS: English to Metric To Convert From Multiply by Area 9.2903e-2 6.416 e-4 Energy Joule (J) 1054.48 BTU/Hr 2546.2 1.34 Length 0.3048 0.0254 Pressure lbf/ft Paschals 47.88 lbf/in (psi) Paschals 6894.76 in.
  • Page 85 P18AL Service Manual 11-1 INDEX 11. Index A-Valve ----------------------------------------------------------- 4-1, 5-1 D Valve (Thawing Gas ) -------------------------------------- 4-1, 4-2 Accumulator ----------------------------------------------------- 4-1, 5-1 Daily Check List------------------------------------------------------- 7-1 Adding Refrigerant --------------------------------------------------- 5-2 Drive gear ------------------------------------------------------------ 9-11 Ammonia - Specification by Grade ------------------------------ 5-2 Ammonia –...
  • Page 86 Suction Cut-Off Unloader----------------------------------------- 9-14 Make-Up Water ----------------------------------------3-2 – 3-3, 10-4 Symptoms, Troubleshooting--------------------------------------- 8-1 Manual Harvest Push Button-------------------------------- 5-7, 6-4 Metric Conversion ---------------------------------------------------10-7 Telephone Number, Vogt------------------------------------------- 1-1 Temperature-Pressure Chart------------------------------------ 10-6 NEMA ------------------------------------------------------------------- 3-1 Thawing, Chamber --------------------------------------------------- 4-1 Nomenclature, Piping Schematic -------------------------------- 4-2...
  • Page 87 P18FXT Service Manual TABLE OF CONTENTS ® ® Vogt Tube-Ice Machine MID & LARGE MACHINE WARRANTY REGISTRATION/START-UP REPORT MUST COMPLETE AND RETURN TO INITIATE WARRANTY Machine Model No. ________________________________ Serial No. ____________________________________________ Installed at: ____________________________________________________________( )_______________________________________ Company Name Phone _______________________________________________________________________________________________________...
  • Page 88 P18FXT Service Manual TABLE OF CONTENTS Installer signature ____________________________________________ End user signature _________________________________ Please return to: Tube-Ice Division, Henry Vogt Machine Co., P.O. Box 1918, Louisville, KY 40201...
