NSA
User Manual
Note : The [Power Off Timer] function is only available
•
when the NSA is in battery mode. It is not available
when the unit is attached to a power supply.
Select the preferred time duration of inactivity after
which the NSA should power off.
Select
to save the setting.
•
iv. Display/Audio
•
Select [Display/Audio].
Adjust the display brightness or audio volume by
•
pressing [+] or [-]. To mute, continue to press [-]
until it shows [Mute]
•
Select
to save the setting.
d. Certifier/Validator Settings
i. Plot Y-Axis Direction
•
Select
on the home screen, then [Certifier/
Validator Settings] and then [Plot Y-Axis Direction].
•
Select [Up] or [Down].
Select
to save the changes made to the settings.
•
ii. Autosave Results
[Autosave Result], when set to [YES] will save the
test results according to the next available label name.
•
Select [AutoSave Result].
•
Select [Yes] or [No]. If [Yes], after Autotest, the
test results will be automatically saved using the
available label scheme.
•
Select [Autosave with PASS result only] to
autosave the pass results only.
Select
•
iii. Auto Start
Auto Start when enabled will automatically start the
Autotest when a connection is detected in any of the test
ports.
•
Select [Auto Start].
Select [Yes] or [No]. If [Yes], NSA willl automatically
•
start the Autotest when the cable under test is
connected to the NSA. When [Do Autotest if
Wiremap Failed] is enabled, in the event that any
of the 4 pairs falls the wiremap, an Autotest will be
trigereed instead of cable diagnostic
•
Select [Autosave with PASS result only] to
autosave the pass results only.
Select
•
WWW.AEM-TEST.COM
CUSTOMERCARE@AEM-TEST.COM
VER # : 1.0 / PART # : 2201-0011
7
to save the settings.
to save the settings.
