AEM NETWORK SERVICE ASSISTANT User Manual page 5

NSA
User Manual
5. STATUS LED
6. MICRO USB INPUT
7. USB TYPE A
8. RJ4510/100/1G
9. DC INPUT
10. TEST ADAPTER
11. STYLUS
12. STAND
Red : battery charging (when unit is off)
•
Amber : battery charging (when unit is on)
•
Green : battery not charging (when unit is on)
•
Establishes a USB-based wired link between the NSA unit and a personal
•
computer.
Test results can be transferred to PC software (TestDataPro) via this
connection.
USB flash drive connection to store test results and for software updates.
•
• For validation testing of cables up to 1G (functionality is built into the basic
NSA kit).
• Connection for 5V DC supply (WARNING : Do not connect to any power
supply other than the power adapter supplied by AEM).
• A variety of plug and play adapters can be used to change the function of
the NSA modular platform.
• Alternative method of using the touchscreen.
• Retract stand to place it on a table or any other flat surface, freeing you to
perform other tasks while keeping an eye on the screen.
WWW.AEM-TEST.COM
CUSTOMERCARE@AEM-TEST.COM
VER # : 1.0 / PART # : 2201-0011
