- Page 1 store Hartland away Allstore Assembly Instructions revised 0520 - 1.0...
- Page 2 Your hardware pack should contain the following: CONNECTING CABLE BOLT (CB1) OUTLET X 32 CONNECTING ANGLE BRACKET LOCK (CL1) (AB1) X 8 X 32 MINI AXIMAT HINGE CONNECTING (AXI-HINGE) LOCK (CB2) HANDLE SHELF PEG (SP1) X 76 SCREW BLACK (S30) X 3 CASTOR (C2} SCREW (35-15S} SCREW (35-17D}...
- Page 3 STEP 1 SA-HART-1S You will need to open box - Insert CL1 Locks into the holes as indicated Screw CB2 Bolts into all the holes marked with a red circle screw in to this point Screw CB1 Bolts into all the holes marked with a red circle SA-HART...
- Page 4 STEP 2 SA-HART You will need to open box - TCBB&SH From this box you will require panel SA-HART-BASE Insert CL1 Locks into the holes as indicated SA-HART BASE BACK EDGE Attach Castor C2 to the base using 35-17D Screws to all positions marked with a red circle STEP 3...
- Page 5 STEP 5 With the SA-HART-LHS laying on the solid flat clean surface (we recommend the floor) attach the three back panels and the base. Secure by turning all of the connecting locks in the backs and the base approx one half turn. Then screw the remaining 35-17D screws into the angle brackets to secure the side to the base. SA-HART-MB3 SA-HART SA-HART-MB2...
- Page 6 STEP 6 With the unit still laying on the floor place the SA-HART-RHS onto the top and secure all the connecting locks and angle brackets. Then carefully stand the unit onto its wheels. IT IS HIGHLY RECOMMENDED TO HAVE TWO PEOPLE TO COMPLETE THIS STEP TO AVOID INJURY OR DAMAGE TO THE PRODUCT. SA-LYD MBACK SA2B...
- Page 7 SA-2BT STEP 7 You will need box - Remove the SA-HART-TOP from the box and fit the CB1 bolts as shown below SA-HART screw in to SA-HART-TOP this point Screw CB1 Bolts into all the holes marked with a red circle Once you have screwed the bolts into the panel place it carefully to one side.
- Page 8 STEP 8 screw in to this point Screw CB1 Bolts into all the holes marked with a red circle BACK EDGE S A - L Y D - M R H S Y D - M S A - L L H S...
- Page 9 STEP 9 SA-HART You will need to open box - BCD&SH From this box you will require panels SA-HART-BCD Fit the bottom centre dividers as shown below using connectiing locks and the bolts you have already fitted to the base. SA-LYD MBACK SA2B...
- Page 10 STEP 10 You will require SA-HART-MSH from box SA-HART-TCBB&SH you have already opened. Fit the connecting bolts as shown below. screw in to this point Screw CB1 Bolts into all the holes marked with a red circle OTHER SIDE OF PANEL...
- Page 11 STEP 11 Fit the main shelf and tighten all of the connecting locks including those pre-fitted into the underside of the desk shelf. BACK EDGE S A - L Y D - M R H S Y D - M S A - L L H S...
- Page 12 STEP 12 You will require SA-HART-TCD from box SA-HART-TCBB&SH you have already opened. Fit the top centre divider as shown below using connectiing locks and the bolts you have already fitted to the main shelf. BACK EDGE S A - L Y D - M R H S Y D - M...
- Page 13 STEP 13 Fit the SA-HART-TOP to the unit by tightening all of the connecting locks. BACK EDGE S A - L Y D - M R H S Y D - M S A - L L H S...
- Page 14 STEP 14 Now attach the doors handles using the screws provided to your doors and then attach the doors to unit. This is done by sliding the hinge part which is pre attached to the door on to the hinge which you have xed to the side.
- Page 15 STEP 21 A standard layout of boxes is shown below. The best way to fit the boxes is to start at the bottom of each section, insert a box then add shelf pegs (SP1) and a shelf above then continue until the section is full. Use shelves as indicated below and SP1 shelf pegs as supplied.
- Page 16 store Hartland away Allstore The Storeaway Hartland Allstore unit is designed and manufactured in the UK by: storage C R A F T S www.storage4crafts.co.uk...
