- Page 1 store Clovelly away Assembly Instructions revised 0620 - 1.0...
- Page 2 It is strongly recommended to have two persons present when assembling this item. We advise that you unpack the boxes in the order shown in these instructions and follow the assembly instructions carefully. Please be careful during construction as section of the cupboard may be unstable until construction is complete.
- Page 3 Your hardware pack should contain the following: CONNECTING BOLT (CB1) X 37 CONNECTING LOCK (CL1) X 37 HOOK (AH1) SHELF PEG (SP1) X 48 SHELF CLIP (SR1) X 24 SCREW (35-17D) X 16 BLACK CASTOR With Brake (C3)
- Page 4 STEP 1 CLOVELLY & CLOVELLY You will need to open box - (BOX 1) (BOX 3) Insert CL1 Locks into the holes as indicated with a blue circle CLOV-SMSIDE screw in to this point Screw CB1 Bolts into all the holes marked with a red circle...
- Page 5 STEP 2 Insert CL1 Locks into the holes as indicated with a blue circle CLOV-SMLBACK CLOV-LGEBACK...
- Page 6 STEP 4 CLOV-TCD Insert CL1 Locks into the holes as indicated with a blue circle screw in to this point Screw CB1 Bolts into all the holes marked with a red circle CLOV-MIDSH (SIDE 1 BOTTOM)
- Page 7 STEP 5 screw in to this point Screw CB1 Bolts into all the holes marked with a red circle CLOV-MIDSH (SIDE 2 TOP)
- Page 8 STEP 6 Connect together the CLOV-LGEBACK and the CLOV-SMSIDE by slotting the panels together and turning the connecting locks in the LGEBACK to tighten STEP 7 Connect together the CLOV-SMLBACK and the CLOV-TCD by slotting the panels together and turning the connecting locks in the SMLBACK to tighten STEP 8 Connect the two sections you have ust made to the CLOV-MIDSH as shown below and tighten the connecting...
- Page 9 STEP 9 CLOV-LGESIDE Insert CL1 Locks into the holes as indicated with a blue circle screw in to this point Screw CB1 Bolts into all the holes marked with a red circle...
- Page 10 STEP 10 Connect the section you constructed in STEP 8 to the CLOV-LGESIDE as shown below and tighten the connecting locks in the CLOV-LGEBACK, CLOV-SMLBACK and the CLOV-MIDSH CLOV SMLBACK CLOV-LGEBACK...
- Page 11 STEP 11 Insert CL1 Locks into the holes as indicated with a blue circle CLOV-LGERS...
- Page 12 STEP 12 Fit the 2 x CLOV-LGERS as shown below and tighten the connecting locks. CLOV-LGERS...
- Page 13 STEP 13 CLOV-TOP screw in to this point Screw CB1 Bolts into all the holes marked with a red circle...
- Page 14 STEP 14 Attach the CLOV-TOP to the section that you have already constructed and tighgten all of the connecting locks.
- Page 15 STEP 15 CLOV-BASE screw in to this point (top) Screw CB1 Bolts into all the holes marked with a red circle CLOV-BASE (underneath) Attach the four castors to base as indicated...
- Page 16 STEP 16 Attach the CLOV-BASE to the section that you have already constructed and tighgten all of the connecting locks.
- Page 17 STEP 17 CLOV-SMLSH Fit the CLOV-LGESH and the CLOV-SML-SH as shown - the back of the shelf is supported on an SP1 peg and the front of the shelf is xed using an SP1 and a SR1 clip. & CLOV-LGESH...
- Page 18 STEP 18 Fit the CLOV-LGERSH and the CLOV-SML-RSH as shown - the CLOV-LGERSH back of the shelf is supported on an SP1 peg and the front of the shelf is xed using an SP1 and a SR1 clip. Fit acrylic into slots in the shelves and the base as required Fit Hooks to the...
- Page 20 Clovelly away The Storeaway Clovelly unit is designed and manufactured in the UK by: storage C R A F T S www.storage4crafts.co.uk...
