USP DURAMAX Foundation Kit Owner's Manual

Pent roof metal garden shed foundation kit
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
A L L
P U R P O S E
M E T A L
S T O R A G E
Foundation Kit
OWNER'S MANUAL /
Instructions for Assembly
Size 8 Ft x 4 Ft / 2.4 m. x 1.2 m.
Ver : 1.0
TOOLS YOU WILL NEED
Cordless Drill - Philips Head
S H E D S
Rubber mallet
Hand Gloves
Pent Roof Metal Garden Shed
(Approx.)
Carpenters Square
Goggles
Customer
Service Hotline
(800) 483-4674
www.duramaxbp.com
Call us for any missing or damaged parts.
Do not return to the store.
Level - 3ft.

Advertisement

loading

Related Manuals for USP DURAMAX Foundation Kit

Summary of Contents for USP DURAMAX Foundation Kit

  • Page 1 A L L P U R P O S E M E T A L S T O R A G E S H E D S Pent Roof Metal Garden Shed Foundation Kit OWNER’S MANUAL / Instructions for Assembly Size 8 Ft x 4 Ft / 2.4 m.

  • Page 2: Parts List

    . Assemble the channel (FC1B) & (FC2B) together using (S2) screws. Make 2 sets. Parts List FC2B Note: Check all parts prior to installation. CODE DESCRIPTION FC1B FC1B FOUNDATION ‘U’ CHANNEL FC2B FOUNDATION ‘U’ CHANNEL ‘U’ CHANNEL FC3C FOUNDATION‘U’ CHANNEL FC4C FOUNDATION ‘U’...
  • Page 3 . Fix the channel (FCC) to all the four corners to make a perfect frame. See Fig. . Fix the channel (FC4C) into the main frame as shown. See Fig. Note Make sure while assembling, the channel position should be as FC4C shown.
  • Page 4 . Assemble base bar back left (BLB) and base bar back right (BRB) with four (S1) screws. See fig. 1 & 2. Step 1 Step 2 1 & 2 Fig.1 Fig.2 . Place the base bar assembly on top of the foundation.
  • Page 5 . Line up the holes with foundation and secure with (S2) screws. Step 1 Fig.1 Step 2 Fig.2 . Place the base bar (BBF) on top of (BSC) on both sides. Secure with (S1) screw to (BSC) on both corners. See fig. 1 & 2. Step 1 1&2 Fig.1...
  • Page 6 . Secure the base (BBF) to the foundation with (S2) screws. Fig.1 OPTION - 1 . Place exterior grade CDX 3/4” (19mm) plywood inside the foundation. See fig. IMPORTANT: USE HAND GLOVES TO PREVENT INJURY.
  • Page 7 . Place the entrance taper channel (ECB) on top of the (BBF). Secure with (S2) screws to the foundation. See fig. 1 & 2. Step 1 Step 2 Fig.1 Fig.2 OPTION - 2 . After completing the assembly of the base bar fill the concrete upto the foundation top surface.
  • Page 8 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, United States of America SKU#--------- RD-1.0 2015-07-07...
